APC Smart-UPS Li-ion SMTL2200RMI2UC - 8xC13 & 1xC19, Rackmount 2U, SmartConnect, 2200VA
APC

Smart-UPS Li-ion SMTL2200RMI2UC - 8xC13 & 1xC19, Rackmount 2U, SmartConnect, 2200VA

Model SMTL2200RMI2UCEAN 731304643197

65 specifications
  • Noise55 dB
  • TypeRackmount/Tower
  • Weight42.3 kg
  • ColourBlack, Grey
  • UPS topologyLine-Interactive
  • AC outlet typesC13 coupler, C19 coupler
See all specifications

Overview

Noise
55 dB
Type
Rackmount/Tower
Weight
42.3 kg
Colour
Black, Grey
UPS topology
Line-Interactive
AC outlet types
C13 coupler, C19 coupler
Brand
APC
Model
SMTL2200RMI2UC
Part number
SMTL2200RMI2UC
EAN / UPC
731304643197
Also known as
APC Smart-UPS Li-ion SMTL2200RMI2UC - 8xC13 & 1xC19, Rackmount 2U, SmartConnect, 2200VA

Specifications

65 specifications in 11 groups

Features

UPS topologyLine-Interactive
Output power capacity2.2 kVA
Output power1980 W
WaveformSine
Input operation voltage (min)151 V
Input operation voltage (max)302 V
Input frequency50/60 Hz
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Output frequency50/60 Hz
Automatic Voltage Regulation (AVR)Yes
Surge energy rating375 J
Response time6 ms
Heat dissipation215 BTU/h
Number of input phases1
Number of output phases1
Output voltage Total Harmonic Distortion (THD)5%
Noise level55 dB
Audible alarm(s)Yes
Auto-restartYes
Power source typeAC

Ports & interfaces

AC outlet typesC13 coupler, C19 coupler
AC outlets quantity10 AC outlet(s)
Number of output IEC jumpers3
USB portYes
Serial interfaceYes
Serial interface typeRJ-45
Ethernet LAN (RJ-45) ports1
SmartSlotYes
SmartConnect portYes

Battery

Battery technologySealed Lead Acid (VRLA)
Battery life (max)5 year(s)
Battery recharge time3 h
Hot-swap batteryYes
Automatic battery testYes
Cold startYes

Design

Form factorRackmount/Tower
Product colourBlack, Grey
Rack capacity2U
Cable length2 m
Display typeLCD
LED indicatorsYes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3048 m
Non-operating altitude0 - 15240 m

Packaging content

Rack mount kitYes
Cables includedUSB cable
Management card includedNo

Certificates

Compliance certificatesCE, GS mark, RoHS, VDE
CertificationIRAM, RCM

Sustainability

Sustainability complianceYes

Weight & dimensions

Width432 mm
Depth683 mm
Height86 mm
Weight42.3 kg

Packaging data

Package width980 mm
Package depth600 mm
Package height254 mm
Package weight49.7 kg

Other features

Input connection typeBS1363A British, IEC 320 C20, Schuko CEE 7 / EU1-16P
Nominal input voltage230 V
Nominal output voltage230 V
