APC Smart-UPS SRT 5000VA 208V - 120V Step-Down Transformer

APC Smart-UPS SRT 5000VA 208V - 120V Step-Down Transformer

Model Smart-UPS SRT 5000VA 208V - 120V Step-Down TransformerPart no. SRT5KRMXLT-5KTF

60 specifications
  • Battery840 Ah
  • Noise55 dB
  • TypeRackmount/Tower
  • Weight98.9 kg
  • ColourBlack
  • UPS topologyDouble-conversion (Online)
See all specifications

Overview

Battery
840 Ah
Noise
55 dB
Type
Rackmount/Tower
Weight
98.9 kg
Colour
Black
UPS topology
Double-conversion (Online)
Brand
APC
Model
Smart-UPS SRT 5000VA 208V - 120V Step-Down Transformer
Part number
SRT5KRMXLT-5KTF
Also known as
APC Smart-UPS SRT 5000VA 208V - 120V Step-Down Transformer uninterruptible power supply (UPS) Double-conversion (Online) 5 kVA 4.25 W 15 AC outlet(s)

Specifications

60 specifications in 11 groups

Features

UPS topologyDouble-conversion (Online)
Output power capacity5 kVA
Output power4.25 W
WaveformSine
Input operation voltage (min)100 V
Input operation voltage (max)275 V
Input frequency40 - 70 Hz
Output operation voltage (min)120 V
Output operation voltage (max)208 V
Output frequency50/60 Hz
Automatic Voltage Regulation (AVR)Yes
Surge energy rating480 J
Efficiency93.4%
Emergency Power Off (EPO)Yes
Output voltage Total Harmonic Distortion (THD)2%
Noise level55 dB
Surge protectionYes
Power protection featuresOverload
Audible alarm(s)Yes
Auto-restartYes

Ports & interfaces

AC outlet typesNEMA L5-20R, NEMA L6-20R, NEMA L6-30R
Power plugNEMA L6-30P
AC outlets quantity15 AC outlet(s)
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports3

Battery

Battery technologySealed Lead Acid (VRLA)
Battery capacity840 Ah
Typical backup time at full load5 min
Typical backup time at half load14 min
Battery recharge time1.5 h
Hot-swap batteryYes
Automatic battery testYes
Cold startYes

Design

Form factorRackmount/Tower
Product colourBlack
Housing materialSteel
Rack capacity5U
Cable length3.05 m
Display typeLCD
LED indicatorsBattery replacement
International Protection (IP) codeIP20

Operational conditions

Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m

Packaging content

Rack mount kitYes
Cables includedUSB cable
Quick installation guideYes

Certificates

Compliance certificatesRoHS

Sustainability

Sustainability certificatesENERGY STAR

Weight & dimensions

Width432 mm
Depth719 mm
Height218 mm
Weight98.9 kg

Packaging data

BracketYes
Resource CDYes
Package width622 mm
Package depth960 mm
Package height584 mm
Package weight117.9 kg

Logistics data

Products per pallet3 pc(s)
