APC Service Bypass Panel 200/208/230/240V 125A HW Input/Output

APC Service Bypass Panel 200/208/230/240V 125A HW Input/Output

Model SBP20KPEAN 731304266952

34 specifications
  • TypeTower
  • Weight19.3 kg
  • ColourBlack
  • Output power capacity20 kVA
  • AC outlet typesHard Wire 5-wire (3PH + N + G)
  • Operating temperature (T-T)-20 - 50 °C
See all specifications

Overview

Type
Tower
Weight
19.3 kg
Colour
Black
Output power capacity
20 kVA
AC outlet types
Hard Wire 5-wire (3PH + N + G)
Operating temperature (T-T)
-20 - 50 °C
Brand
APC
Model
SBP20KP
Part number
SBP20KP
EAN / UPC
731304266952, 763615975353, 7313042669528
Also known as
APC Service Bypass Panel 200/208/230/240V 125A HW Input/Output

Specifications

34 specifications in 10 groups

Features

Output power capacity20 kVA
Input operation voltage (min)200 V
Input operation voltage (max)240 V
Input frequency50/60 Hz
Maximum current125 A

Ports & interfaces

AC outlet typesHard Wire 5-wire (3PH + N + G)

Design

Form factorTower
Product colourBlack
Rack capacity4U

Operational conditions

Operating temperature (T-T)-20 - 50 °C
Storage temperature (T-T)-40 - 65 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 4500 m
Non-operating altitude0 - 15000 m

Certificates

Compliance certificatesRoHS, REACH, WEEE
CertificationCSA; GOST

Technical details

Preferred mounting positionlower
Packaging without single use plasticNo
Sustainable packagingNo
Take-back systemNo

Weight & dimensions

Width432 mm
Depth554 mm
Height178 mm
Weight19.3 kg

Packaging data

Package weight31.4 kg

Logistics data

Customs product code (TARIC)8536508000
Harmonized System (HS) code85078000
Country of originChina

Other features

Output connectionshard wire 3-wire (H N + E) for 1 zone(s); hard wire 3-wire (2P + E) for 1 zone(s)
Mountingfront
Operating temperature (T-T)-4 - 122 °F
Overload protectionYes
Package dimensions (WxDxH)610 x 845 x 305 mm
