APC Galaxy VS UPS 100kW
APC

Galaxy VS UPS 100kW

400V with N+1 power module for external batteries, Start-up 5x8

Model GVSUPS100KRHSEAN 731304418320

35 specifications
  • Noise68 dB
  • Weight290 kg
  • ColourWhite
  • UPS topologyDouble-conversion (Online)
  • Battery technologyLithium-Ion (Li-Ion)
  • Operating temperature (T-T)0 - 40 °C
See all specifications

Overview

Noise
68 dB
Weight
290 kg
Colour
White
UPS topology
Double-conversion (Online)
Battery technology
Lithium-Ion (Li-Ion)
Operating temperature (T-T)
0 - 40 °C
Brand
APC
Model
GVSUPS100KRHS
Part number
GVSUPS100KRHS
EAN / UPC
731304418320
Also known as
APC Galaxy VS UPS 100kW 400V with N+1 power module for external batteries, Start-up 5x8

Specifications

35 specifications in 9 groups

Features

UPS topologyDouble-conversion (Online)
Output power capacity100 kVA
Output power100000 W
WaveformSine
Input operation voltage (min)340 V
Input operation voltage (max)460 V
Input frequency40 - 70 Hz
Output operation voltage (min)400 V
Output frequency50/60 Hz
Maximum current180 A
Heat dissipation11373 BTU/h
Crest factor2.5:1
Input current Total Harmonic Distortion (THD)3%
Noise level68 dB
Audible alarm(s)Yes

Battery

Battery technologyLithium-Ion (Li-Ion)
Battery voltage576 V

Design

Product colourWhite
International Protection (IP) codeIP21

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-25 - 55 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)10 - 80%
Operating altitude0 - 1005.84 m

Certificates

Compliance certificatesRoHS

Sustainability

Sustainability complianceYes

Weight & dimensions

Width521 mm
Depth847 mm
Height1485 mm
Weight290 kg

Packaging data

Package width640 mm
Package depth990 mm
Package height1680 mm
Package weight315 kg

Logistics data

Warranty period1 year(s)
