APC GVMSB225KG65S uninterruptible power supply (UPS) 225 kVA
APC

GVMSB225KG65S uninterruptible power supply (UPS) 225 kVA

202500 W

Model GVMSB225KG65SEAN 731304326571

43 specifications
  • Noise65 dB
  • Weight704 kg
  • ColourWhite
  • Output power capacity225 kVA
  • Battery technologySealed Lead Acid (VRLA)
  • Operating temperature (T-T)0 - 40 °C
See all specifications

Overview

Noise
65 dB
Weight
704 kg
Colour
White
Output power capacity
225 kVA
Battery technology
Sealed Lead Acid (VRLA)
Operating temperature (T-T)
0 - 40 °C
Brand
APC
Model
GVMSB225KG65S
Part number
GVMSB225KG65S
EAN / UPC
731304326571
Also known as
APC GVMSB225KG65S uninterruptible power supply (UPS) 225 kVA 202500 W

Specifications

43 specifications in 10 groups

Features

Output power capacity225 kVA
Output power202500 W
WaveformSine
Input operation voltage (min)360 V
Input operation voltage (max)576 V
Input frequency40 - 70 Hz
Output operation voltage (min)480 V
Output operation voltage (max)480 V
Output frequency50/60 Hz
Output voltage regulation1%
Maximum current347 A
Heat dissipation27670 BTU/h
Number of input phases3
Number of output phases3
Efficiency95.5%
Power factor0.5
Output voltage Total Harmonic Distortion (THD)3%
Input current Total Harmonic Distortion (THD)3%
Noise level65 dB

Battery

Battery technologySealed Lead Acid (VRLA)
Battery life (max)10 year(s)

Design

Product colourWhite
Control typeTouch
Display typeLCD
International Protection (IP) codeIP20

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 40 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)10 - 80%
Operating altitude0 - 1000 m

Packaging content

ManualYes

Power

Input current (max)347 A

Technical details

Battery includedNo
Minimum order quantity1 pc(s)

Weight & dimensions

Width1002 mm
Depth854 mm
Height1970 mm
Weight704 kg

Packaging data

Package width1060 mm
Package depth1490 mm
Package height2156 mm
Package weight745 kg

Logistics data

Warranty period1 year(s)

Energy efficiency

ENERGY STAR certified

Uninterruptible power supplies · model GVMSB225KG65S · certified Feb 26, 2019 · United States, Canada

Average efficiency97 %
