APC Galaxy VM 200 kVA UPS Single 400-400 V with Backfeed protection, Start up

APC Galaxy VM 200 kVA UPS Single 400-400 V with Backfeed protection, Start up

5x8

Model GVMSB200KHS

52 specifications
  • Noise65 dB
  • TypeTower
  • Weight724 kg
  • ColourWhite
  • UPS topologyDouble-conversion (Online)
  • AC outlet typesHard Wire 3-wire (3PH + G)
See all specifications

Overview

Noise
65 dB
Type
Tower
Weight
724 kg
Colour
White
UPS topology
Double-conversion (Online)
AC outlet types
Hard Wire 3-wire (3PH + G)
Brand
APC
Model
GVMSB200KHS
Part number
GVMSB200KHS
Also known as
APC Galaxy VM 200 kVA UPS Single 400-400 V with Backfeed protection, Start up 5x8

Specifications

52 specifications in 11 groups

Features

UPS topologyDouble-conversion (Online)
Output power capacity200 kVA
Output power180000 W
WaveformSine
Input operation voltage (min)250 V
Input operation voltage (max)600 V
Input frequency40/70 Hz
Output operation voltage (min)380 V
Output operation voltage (max)415 V
Output frequency50/60 Hz
Maximum current328 A
Heat dissipation24570 BTU/h
Number of input phases3
Number of output phases3
Input power factor1
ECO modeYes
Emergency Power Off (EPO)Yes
Output voltage Total Harmonic Distortion (THD)3%
Input current Total Harmonic Distortion (THD)3%
Noise level65 dB
Power protection featuresOverload
Audible alarm(s)Yes

Ports & interfaces

AC outlet typesHard Wire 3-wire (3PH + G)
Serial interfaceYes
Serial interface typeRS-485
SmartSlotYes

Battery

Battery voltage480 V

Design

Form factorTower
Product colourWhite
Housing materialSteel
Display typeLCD
LED indicatorsYes
International Protection (IP) codeIP20

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-25 - 55 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 1000 m
Non-operating altitude0 - 14763 m

Packaging content

Quick installation guideYes

Sustainability

Sustainability certificatesENERGY STAR

Certificates

CertificationC-tick, CE, EN/IEC 62040-1, EN/IEC 62040-2, EN/IEC 62040-3, IBC 2012 and CBC2013 to Sds=2.02g , ISTA 2B, OSHPD, RCM, UL 1778

Weight & dimensions

Width1052 mm
Depth854 mm
Height1970 mm
Weight724 kg

Packaging data

Package width1490 mm
Package depth1060 mm
Package height2156 mm
Package weight770 kg

Logistics data

Harmonized System (HS) code85078000
Warranty period1 year(s)
