APC Galaxy VM 160 kVA UPS Parallel 400-400 V with Backfeed protection, Start up

APC Galaxy VM 160 kVA UPS Parallel 400-400 V with Backfeed protection, Start up

5x8

Model GVMPB160KHS

43 specifications
  • Noise65 dB
  • TypeTower
  • Weight699 kg
  • ColourWhite
  • UPS topologyDouble-conversion (Online)
  • Power plugTerminal
See all specifications

Overview

Noise
65 dB
Type
Tower
Weight
699 kg
Colour
White
UPS topology
Double-conversion (Online)
Power plug
Terminal
Brand
APC
Model
GVMPB160KHS
Part number
GVMPB160KHS
Also known as
APC Galaxy VM 160 kVA UPS Parallel 400-400 V with Backfeed protection, Start up 5x8

Specifications

43 specifications in 10 groups

Features

UPS topologyDouble-conversion (Online)
Output power capacity160 kVA
Output power144000 W
WaveformSine
Input operation voltage (min)250 V
Input operation voltage (max)600 V
Input frequency40 - 70 Hz
Output operation voltage (min)380 V
Output operation voltage (max)415 V
Output frequency50/60 Hz
Maximum current262 A
Input power factor1
Output voltage Total Harmonic Distortion (THD)3%
Noise level65 dB
Audible alarm(s)Yes
Web-based managementYes

Ports & interfaces

AC outlet typesHard Wire 4-wire (3PH + G), Hard Wire 5-wire (3PH + N + G)
Power plugTerminal
AC outlets quantity2 AC outlet(s)
Emergency Power Off (EPO) connectorYes
SmartSlotYes

Battery

Battery voltage480 V

Design

Form factorTower
Product colourWhite
Display typeLCD
LED indicatorsYes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-25 - 55 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 1000 m
Non-operating altitude0 - 14763.6 m

Sustainability

Sustainability certificatesENERGY STAR

Certificates

CertificationC-Tick, CE, EN/IEC 62040-1, EN/IEC 62040-2, EN/IEC 62040-3, IBC 2012 and CBC2013 to Sds=2.02g, OSHPD, RCM, UL 1778, VFI-SS-111

Weight & dimensions

Width1052 mm
Depth854 mm
Height1970 mm
Weight699 kg

Packaging data

Package width1490 mm
Package depth1060 mm
Package height2156 mm
Package weight744.5 kg

Logistics data

Harmonized System (HS) code85078000
