APC Galaxy 300

APC Galaxy 300

Model Galaxy 300Part no. G3HT60KHB4SEAN 731304325338

41 specifications
  • TypeTower
  • Weight1.42 kg
  • ColourGrey
  • UPS topologyDouble-conversion (Online)
  • Power plugTerminal
  • Battery technologySealed Lead Acid (VRLA)
See all specifications

Overview

Type
Tower
Weight
1.42 kg
Colour
Grey
UPS topology
Double-conversion (Online)
Power plug
Terminal
Battery technology
Sealed Lead Acid (VRLA)
Brand
APC
Model
Galaxy 300
Part numbers
G3HT60KHB4S, G3HT60KHB3S, G3HT60KHB1S, G3HT60KHB2S, G3HT60KHLS, G3HT80KHLS +5 more
EAN / UPC
731304325338
Also known as
APC Galaxy 300 uninterruptible power supply (UPS) Double-conversion (Online) 60 kVA 48000 W

Specifications

41 specifications in 9 groups

Features

UPS topologyDouble-conversion (Online)
Output power capacity60 kVA
Output power48000 W
Input operation voltage (min)340 V
Input operation voltage (max)477 V
Input frequency45/65 Hz
Maximum current228 A
Number of input phases3
Number of output phases3
Efficiency93.5%
Crest factor3:1
Input current Total Harmonic Distortion (THD)5%
Power protection featuresOverload, Short circuit

Ports & interfaces

Power plugTerminal
Emergency Power Off (EPO) connectorYes

Battery

Battery technologySealed Lead Acid (VRLA)
Battery voltage192 V

Design

Form factorTower
Product colourGrey
Display typeLCD
LED indicatorsYes
International Protection (IP) codeIP20

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 45 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 900 m
Non-operating altitude0 - 4500 m

Certificates

Compliance certificatesRoHS
CertificationCE, EAC, EN/IEC 62040-1-1, EN/IEC 62040-2, EN/IEC 62040-3, ISTA 2B

Weight & dimensions

Width1412 mm
Depth950 mm
Height1900 mm
Weight1.42 kg

Packaging data

Package width1649 mm
Package depth1120 mm
Package height1978 mm
Package weight1.44 kg

Other features

Number of phases3
Nominal input voltage400 V
Nominal output voltage400 V
