APC G55TUPSU60HS uninterruptible power supply (UPS) Double-conversion (Online) 60 kVA

APC G55TUPSU60HS uninterruptible power supply (UPS) Double-conversion (Online) 60 kVA

54000 W

Model G55TUPSU60HS

38 specifications
  • Noise55.5 dB
  • Weight400 kg
  • ColourGrey
  • UPS topologyDouble-conversion (Online)
  • Battery voltage432 V
  • Operating temperature (T-T)0 - 40 °C
See all specifications

Overview

Noise
55.5 dB
Weight
400 kg
Colour
Grey
UPS topology
Double-conversion (Online)
Battery voltage
432 V
Operating temperature (T-T)
0 - 40 °C
Brand
APC
Model
G55TUPSU60HS
Part number
G55TUPSU60HS
Also known as
APC G55TUPSU60HS uninterruptible power supply (UPS) Double-conversion (Online) 60 kVA 54000 W

Specifications

38 specifications in 8 groups

Features

UPS topologyDouble-conversion (Online)
Output power capacity60 kVA
Output power54000 W
WaveformSine
Input operation voltage (min)250 V
Input operation voltage (max)470 V
Input frequency45/65 Hz
Output operation voltage (min)380 V
Output operation voltage (max)415 V
Maximum current88 A
Number of input phases3
Efficiency92.5%
Crest factor3:1
Noise level55.5 dB
Power protection featuresOverload

Battery

Battery voltage432 V
Battery recharge time10 h

Design

Product colourGrey
Display typeLCD
International Protection (IP) codeIP20

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 45 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 12000 m

Certificates

CertificationCE, EN/IEC 62040-3, IEC 62040-1-2, IEC 62040-2, ISO 9001, TUV, VDE

Weight & dimensions

Width712 mm
Depth850 mm
Height1900 mm
Weight400 kg

Packaging data

Package width980 mm
Package depth960 mm
Package height2030 mm
Package weight420 kg

Other features

Number of phases3
Input connection typeHard Wire 4-wire (3PH + G)
Nominal output voltage400 V
