APC BXS500MI uninterruptible power supply (UPS) Line-Interactive 0.5 kVA
APC

BXS500MI uninterruptible power supply (UPS) Line-Interactive 0.5 kVA

300 W 3 AC outlet(s)

Model BXS500MI

50 specifications
  • Battery7 Ah
  • Noise40 dB
  • TypeTower
  • Weight4.2 kg
  • ColourBlack
  • UPS topologyLine-Interactive
See all specifications

Overview

Battery
7 Ah
Noise
40 dB
Type
Tower
Weight
4.2 kg
Colour
Black
UPS topology
Line-Interactive
Brand
APC
Model
BXS500MI
Part number
BXS500MI
Also known as
APC BXS500MI uninterruptible power supply (UPS) Line-Interactive 0.5 kVA 300 W 3 AC outlet(s)

Specifications

50 specifications in 10 groups

Features

UPS topologyLine-Interactive
Output power capacity0.5 kVA
Output power300 W
WaveformPseudo sine
Input operation voltage (min)140 V
Input operation voltage (max)300 V
Input frequency50/60 Hz
Output frequency50/60 Hz
Automatic Voltage Regulation (AVR)Yes
Surge energy rating273 J
Response time10 ms
Input power factor0.63
Noise level40 dB
Power source typeAC

Ports & interfaces

AC outlet typesC13 coupler
AC outlets quantity3 AC outlet(s)
USB portYes
USB port typeUSB Type-B

Battery

Battery technologySealed Lead Acid (VRLA)
Battery capacity7 Ah
Battery voltage12 V
Typical backup time at full load1 min
Typical backup time at half load7.25 min
Battery life (max)5 year(s)
Battery recharge time8 h

Design

Form factorTower
Product colourBlack
Cable length1.52 m
Control typeButtons
LED indicatorsYes
International Protection (IP) codeIP20

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 40 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 3000 m

Certificates

Compliance certificatesCB, CE, REACH, RoHS
CertificationEN/IEC 62040-1:2019/A11:2021

Sustainability

Doesn't containMercury
Sustainability complianceYes

Weight & dimensions

Width98 mm
Depth310 mm
Height138 mm
Weight4.2 kg

Packaging data

Package width189 mm
Package depth375 mm
Package height225 mm
Package weight4.9 kg

Other features

Nominal input voltage230 V
