APC BX950U-MS uninterruptible power supply (UPS) Line-Interactive 0.95 kVA
APC

BX950U-MS uninterruptible power supply (UPS) Line-Interactive 0.95 kVA

480 W 6 AC outlet(s)

Model BX950U-MSEAN 731304315995

59 specifications
  • Battery9 Ah
  • Noise45 dB
  • TypeTower
  • Weight8 kg
  • ColourBlack
  • UPS topologyLine-Interactive
See all specifications

Overview

Battery
9 Ah
Noise
45 dB
Type
Tower
Weight
8 kg
Colour
Black
UPS topology
Line-Interactive
Brand
APC
Model
BX950U-MS
Part number
BX950U-MS
EAN / UPC
731304315995
Also known as
APC BX950U-MS uninterruptible power supply (UPS) Line-Interactive 0.95 kVA 480 W 6 AC outlet(s)

Specifications

59 specifications in 11 groups

Features

UPS topologyLine-Interactive
Output power capacity0.95 kVA
Output power480 W
WaveformSine
Input operation voltage (min)150 V
Input operation voltage (max)280 V
Input frequency50/60 Hz
Automatic Voltage Regulation (AVR)Yes
Maximum current4 A
Surge energy rating273 J
Hold time (max)10 ms
Hold time (min)8 ms
Efficiency97.1%
Noise level45 dB
Surge protectionYes
Surge protection featuresFax, Modem
Audible alarm(s)Yes
Audible alarm modesLow battery alarm, Overload alarm

Ports & interfaces

AC outlet typesC13 coupler
Power plugC14 coupler
AC outlets quantity6 AC outlet(s)
Number of output IEC jumpers1
USB portYes

Battery

Battery technologySealed Lead Acid (VRLA)
Battery capacity9 Ah
Battery capacity76 VAh
Battery voltage12 V
Number of batteries supported1
Typical backup time at full load1.3 min
Typical backup time at half load7.5 min
Battery life (max)5 year(s)
Battery recharge time8 h
Automatic battery testYes

Design

Form factorTower
Product colourBlack
Cable length1.22 m
LED indicatorsYes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 9000 m

Packaging content

ManualYes

Certificates

Compliance certificatesRoHS
CertificationA-tick, C-tick, CE, IEC 62040-1-1, RCM, TelePermit, REACH

Weight & dimensions

Width130 mm
Depth336 mm
Height215 mm
Weight8 kg

Packaging data

Bundled softwarePowerChute Personal Edition
Package width245 mm
Package depth440 mm
Package height295 mm
Package weight8.99 kg

Logistics data

Harmonized System (HS) code85078000

Other features

Nominal input voltage230 V
Nominal output voltage230 V
Type of input protection required3-pole circuit breaker
