APC Back-UPS Pro for Gaming, 2200VA/1320W, Tower
APC

Back-UPS Pro for Gaming, 2200VA/1320W, Tower

230V, 2x UK and 2x IEC C13 outlets, RGB Lights, Pure Sine Wave, Arctic (White)

Model BGM2200B-AZEAN 20731304634809

55 specifications
  • Noise45 dB
  • TypeTower
  • Weight12.5 kg
  • ColourBlack
  • UPS topologyLine-Interactive
  • AC outlet typesC13 coupler
See all specifications

Overview

Noise
45 dB
Type
Tower
Weight
12.5 kg
Colour
Black
UPS topology
Line-Interactive
AC outlet types
C13 coupler
Brand
APC
Model
BGM2200B-AZ
Part number
BGM2200B-AZ
EAN / UPC
20731304634809
Also known as
APC Back-UPS Pro for Gaming, 2200VA/1320W, Tower, 230V, 2x UK and 2x IEC C13 outlets, RGB Lights, Pure Sine Wave, Arctic (White)

Specifications

55 specifications in 10 groups

Features

UPS topologyLine-Interactive
Output power capacity2.2 kVA
Output power1320 W
WaveformSine
Input operation voltage (min)168 V
Input operation voltage (max)302 V
Input frequency50/60 Hz
Output operation voltage (max)230 V
Output frequency60 Hz
Automatic Voltage Regulation (AVR)Yes
Maximum current12 A
Surge energy rating1080 J
Response time8 ms
EMI/RFI noise filteringYes
Noise level45 dB
Surge protectionYes
Surge protection featuresNetwork
Audible alarm(s)Yes
Audible alarm modesAlarm when on battery, Low battery alarm, Overload alarm

Ports & interfaces

AC outlet typesC13 coupler
AC outlets quantity6 AC outlet(s)
USB portYes
Serial interface typeRJ-45
Cabling technology10/100/1000Base-T(X)

Battery

Battery technologySealed Lead Acid (VRLA)
Battery voltage24 V
Number of batteries supported1
Battery life (max)5 year(s)
Battery recharge time16 h
Automatic battery testYes
Cold startYes

Design

Form factorTower
Product colourBlack
Rack capacity0U
Cable length1.52 m
Display typeLCD
International Protection (IP) codeIP20

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 40 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3048 m
Non-operating altitude0 - 3048 m

Packaging content

Cables includedUSB cable
ManualYes

Sustainability

Sustainability certificatesGreen Premium

Certificates

CertificationIEC 62040-1-1 IEC 62040-2

Weight & dimensions

Width104.1 mm
Depth408.9 mm
Height292.1 mm
Weight12.5 kg

Packaging data

Package width355 mm
Package depth480 mm
Package height155 mm
Package weight14.4 kg
