Samsung Series 9 TQ77S95DAT

Series 9 TQ77S95DAT

195.6 cm (77") 4K Ultra HD Smart TV Wi-Fi Black

Model TQ77S95DATPart no. TQ77S95DATXXCEAN 8806095486086

119 specifications Checked today

Display195.6 cm (77")
Resolution3840 x 2160 pixels
Energy classF
OSTizen
ColourBlack
Tuner typeAnalog & digital

See all specifications

Overview

Display: 195.6 cm (77")
Resolution: 3840 x 2160 pixels
Energy class: F
OS: Tizen
Colour: Black
Tuner type: Analog & digital

Brand: Samsung
Category: TV
Model: TQ77S95DAT
Part number: TQ77S95DATXXC
EAN / UPC: 8806095486086
Also known as: Samsung Series 9 TQ77S95DAT 195.6 cm (77") 4K Ultra HD Smart TV Wi-Fi Black

Specifications

119 specifications in 15 groups

Display

Specification	Value
Display diagonal	195.6 cm (77")
HD type	4K Ultra HD
Display resolution	3840 x 2160 pixels
Display technology	OLED
LED backlight	Yes
Screen shape	Flat
Native aspect ratio	16:9
Motion interpolation technology	Motion Xcelerator
Native refresh rate	100 Hz
Display refresh rates supported	100 Hz, 144 Hz
Display number of colours	1 billion colours
Display diagonal (metric)	195 cm

TV tuner

Specification	Value
Tuner type	Analog & digital
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Number of tuners	2 tuner(s)
Auto channel search	Yes

Smart TV

Specification	Value
Smart TV	Yes
Internet TV	Yes
Operating system installed	Tizen
Operating system version	Tizen™ Smart TV
Sound mirroring	Yes
Hybrid Broadcast Broadband TV (HbbTV)	Yes
Hybrid Broadcast Broadband TV (HbbTV) version	2.0.3
Universal guide	Yes
Video apps	Samsung TV Plus

Audio

Specification	Value
Audio output channels	4.2.2 channels
RMS rated power	70 W
Audio decoders	Dolby Atmos, Dolby Digital Plus
Active voice amplifier (AVA)	Yes
Adaptive sound	Yes
Audio pre-selection descriptor	Yes
Q-Symphony	Yes
Enhanced Audio Return Channel (eARC)	Yes
Object Tracking Sound+ (OTS+)	Yes

Network

Specification	Value
Wi-Fi	Yes
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth	Yes
Bluetooth version	5.2
Ethernet LAN	Yes
Bluetooth Low Energy (BLE)	Yes
Web browser	Yes

Design

Specification	Value
Product colour	Black
VESA mounting	Yes
Panel mounting interface	400 x 400 mm
Bezel type	3 Bezel-less
Stand type	Center stand
Stand colour	Black

Performance

Specification	Value
High Dynamic Range (HDR) supported	Yes
High Dynamic Range (HDR) technology	Filmmaker Mode, High Dynamic Range 10 Pro (HDR10 Pro), High Dynamic Range 10+ (HDR10 Plus), OLED HDR Pro, Quantum HDR
Game mode	Yes
Teletext function	Yes
Ambient mode	Yes
Eco sensor	Yes
Backlight dimming technology	UHD Dimming
Picture processing technology	Neural Quantum Processor 4K
Picture processor	NQ4 AI Gen2
AMD FreeSync	Yes
AMD FreeSync type	FreeSync Premium Pro
Game features	Auto Low Latency Mode (ALLM), Dynamic Black EQ, Game Motion Plus, Gaming Hub, HGiG, Mini Map Zoom, Surround Sound, Variable Refresh Rate (VRR)
4K Ultra HD upscaling	Yes
Multi View	Yes
Plug and Play	Yes
SmartThings app support	Yes
Tap view	Yes
MBR support	Yes

Ports & interfaces

Specification	Value
HDMI ports quantity	4
Audio Return Channel (ARC)	Yes
PC in (D-Sub)	No
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
Digital audio optical out	1
RF ports quantity	4
Common interface (CI)	Yes
Common interface Plus (CI+)	Yes
Common interface Plus (CI+) version	1.4
Consumer Electronics Control (CEC)	Anynet+

Management features

Specification	Value
Voice guide	Yes
Electronic Programme Guide (EPG)	Yes
On Screen Display (OSD)	Yes
Number of OSD languages	27
Auto power off	Yes
Works with Samsung Bixby	Yes

Power

Specification	Value
Power consumption (standby)	0.5 W
Power consumption (max)	600 W
Energy efficiency class (SDR)	F
Energy efficiency class (HDR)	G
Energy consumption (SDR) per 1000 hours	128 kWh
Energy consumption (HDR) per 1000 hours	309 kWh
AC input voltage	220 - 240 V
AC input frequency	50/60 Hz
Energy saving mode	Yes
Energy efficiency scale	A to G

Brand-specific features

Specification	Value
Samsung technologies (AV/TV)	4K AI Upscaling, Active Voice Amplifier Pro, Adaptive Sound Pro, Buds Auto Switch, Contrast Enhancer, Expert Calibration, Q-Symphony

Weight & dimensions

Specification	Value
Width (with stand)	1716.6 mm
Depth (with stand)	286.4 mm
Height (with stand)	1048.1 mm
Weight (with stand)	40 kg
Width (without stand)	1716.6 mm
Depth (without stand)	11.2 mm
Height (without stand)	984.1 mm
Weight (without stand)	28.2 kg
Stand width	36 cm
Stand depth	28.6 cm

Packaging data

Specification	Value
User guide	Yes
Manual	Yes
Package width	1893 mm
Package depth	185 mm
Package height	1153 mm
Package weight	54 kg
Package type	Box

Packaging content

Specification	Value
Desktop stand	Yes
Cables included	AC
Remote control included	Yes
Remote control type	TM2360E
E-manual	Yes

Other features

Specification	Value
Built-in processor	Yes
One Connect port	Yes
