HG40NF690GFXZA TV
101.6 cm (40") Full HD Smart TV Black
Model HG40NF690GFXZAEAN 887276227009
97 specifications Checked today
- Display101.6 cm (40")
- Resolution1920 x 1080 pixels
- ColourBlack
- Tuner typeAnalog & digital
- Smart TVYes
- Number of speakers2
Overview
- Display
- 101.6 cm (40")
- Resolution
- 1920 x 1080 pixels
- Colour
- Black
- Tuner type
- Analog & digital
- Smart TV
- Yes
- Number of speakers
- 2
- Brand
- Samsung
- Category
- TV
- Model
- HG40NF690GFXZA
- Part number
- HG40NF690GFXZA
- EAN / UPC
- 887276227009
- Also known as
- Samsung HG40NF690GFXZA TV 101.6 cm (40") Full HD Smart TV Black
Specifications
97 specifications in 15 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 101.6 cm (40") |
| HD type | Full HD |
| Display resolution | 1920 x 1080 pixels |
| Display technology | LED |
| LED backlighting type | Direct-lit LED |
| Backlight marketing name | Direct-lit LED |
| Screen shape | Flat |
| Motion interpolation technology | PQI (Picture Quality Index) 400 |
| Dynamic contrast ratio marketing name | Mega Contrast |
TV tuner
| Specification | Value |
|---|---|
| Tuner type | Analog & digital |
| Digital signal format system | ATSC |
| Auto channel search | Yes |
Smart TV
| Specification | Value |
|---|---|
| Smart TV | Yes |
| Internet TV | Yes |
| Screen mirroring | Yes |
| Smart modes | Movie, Natural |
| Lifestyle apps | Samsung Smart View |
Audio
| Specification | Value |
|---|---|
| Number of speakers | 2 |
| RMS rated power | 20 W |
| Audio decoders | Dolby Digital, Dolby Digital Plus |
Network
| Specification | Value |
|---|---|
| Bluetooth | Yes |
| Ethernet LAN | Yes |
| Bluetooth profiles | HID |
| Web browser | Yes |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Swivel angle range | -90 - 90° |
Performance
| Specification | Value |
|---|---|
| Subtitles function | Yes |
| Picture processing technology | Samsung HyperReal Engine, Samsung Wide Color Enhancer Plus |
| Digital Clean View | Yes |
| Processor cores | 4 |
| Clock back up supply | Yes |
| USB cloning | Yes |
| ConnectShare (HDD) | Yes |
| ConnectShare (USB) | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 3 |
| HDMI Quick Switch | Yes |
| Audio Return Channel (ARC) | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 1 |
| Component video (YPbPr/YCbCr) in | 1 |
| Composite video in | 1 |
| PC Audio in | Yes |
| Digital audio optical out | 1 |
| RS-232C ports | 1 |
| RF ports quantity | 1 |
Management features
| Specification | Value |
|---|---|
| Voice guide | Yes |
| Electronic Programme Guide (EPG) | Yes |
| On Screen Display (OSD) | Yes |
| Number of OSD languages | 3 |
| On Screen Display (OSD) languages | English, Spanish, French |
| Auto power off | Yes |
| Music mode backlight on/off | Yes |
| Smoovie compatibility | Yes |
| On/Off timer | Yes |
Ergonomics
| Specification | Value |
|---|---|
| Multi-code remote control | Yes |
| Screwed battery cover | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 35 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (max) | 98 W |
| AC input voltage | 110 - 120 V |
| AC input frequency | 50 - 60 Hz |
| Energy saving mode | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 922.7 mm |
| Depth (with stand) | 226.4 mm |
| Height (with stand) | 580.4 mm |
| Weight (with stand) | 9.8 kg |
| Width (without stand) | 922.7 mm |
| Depth (without stand) | 72.6 mm |
| Height (without stand) | 531 mm |
| Weight (without stand) | 6.8 kg |
Packaging data
| Specification | Value |
|---|---|
| Quick installation guide | Yes |
| Package width | 1111 mm |
| Package depth | 161 mm |
| Package height | 643 mm |
| Package weight | 13.4 kg |
Packaging content
| Specification | Value |
|---|---|
| Mounting kit | Yes |
| Cables included | AC |
| Remote control included | Yes |
| Remote control type | TM1240A |
Other features
| Specification | Value |
|---|---|
| RJ-12 ports quantity | 1 |
| Batteries included | Yes |
| Built-in speaker(s) | Yes |
| H.Browser compatibility | Yes |
| Swivelling | Yes |
| Content management solution | Samsung LYNK REACH |
| LYNK REACH version | 4.0 |
| LYNK DRM supported | Yes |
| Auto source mode | Yes |
| Digital Living Network Alliance (DLNA) certified | Yes |
| IR pass-through | Yes |
| Power on mode | Yes |
| Logo display with time-out setting (BMP/movie) | Yes |
| My Channel function | Yes |
| Security mode | Yes |
| Soundbar compatibility | Yes |
