Samsung The Frame 2024
Samsung

The Frame 2024

75" QLED 4K TV with S801D Ultra Slim Soundbar and Music Frame Wireless Smart Speaker

Model F-75LS0380160D

118 specifications Checked today
  • Display190.5 cm (75")
  • Resolution3840 x 2160 pixels
  • Energy classF
  • OSTizen
  • ColourBlack
  • Tuner typeAnalog & digital
See all specifications

Overview

Display
190.5 cm (75")
Resolution
3840 x 2160 pixels
Energy class
F
OS
Tizen
Colour
Black
Tuner type
Analog & digital
Brand
Samsung
Category
TV
Model
F-75LS0380160D
Part number
F-75LS0380160D
Also known as
Samsung The Frame 2024 75" QLED 4K TV with S801D Ultra Slim Soundbar and Music Frame Wireless Smart Speaker

Specifications

118 specifications in 16 groups

Display

Display diagonal190.5 cm (75")
HD type4K Ultra HD
Display resolution3840 x 2160 pixels
Display technologyQLED
LED backlightYes
LED backlighting typeDual LED
Backlight marketing nameDual LED
Screen shapeFlat
Native aspect ratio16:9
Motion interpolation technologyMotion Xcelerator
Native refresh rate100 Hz
Display refresh rates supported120 Hz
Anti-glare screenYes
Display diagonal (metric)189 cm

TV tuner

Tuner typeAnalog & digital
Digital signal format systemDVB-C, DVB-S2, DVB-T2

Smart TV

Smart TVYes
Internet TVYes
Operating system installedTizen
Apple AirPlay 2 supportYes
Sound mirroringYes
Hybrid Broadcast Broadband TV (HbbTV)Yes
Hybrid Broadcast Broadband TV (HbbTV) version2.0.3
Smart modesFilmmaker
TV initiate mirroringYes

Audio

Audio output channels2.0.2 channels
RMS rated power40 W
Audio decodersDolby Atmos
Sound modesAdaptive Sound Pro
Adaptive soundYes
Audio pre-selection descriptorYes
Enhanced Audio Return Channel (eARC)Yes

Network

Wi-FiYes
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
BluetoothYes
Bluetooth version5.2
Ethernet LANYes
Web browserYes

Design

Product colourBlack
VESA mountingYes
Panel mounting interface400 x 400 mm
Customizable frameYes
Introduction year2024
Bezel typeVNB (Very Narrow Bezel)
FrameYes
Slim fit wall mount supportYes
Stand typeLegs stand
Stand colourBlack

Performance

High Dynamic Range (HDR) supportedYes
High Dynamic Range (HDR) technologyHigh Dynamic Range 10+ (HDR10 Plus), Quantum HDR
Ambient modeYes
Eco sensorYes
AI UpscaleYes
TV key supportYes
Backlight dimming technologySupreme UHD Dimming
Picture processing technologyQuantum Processor 4K, Samsung Real Depth Enhancer
AMD FreeSyncYes
AMD FreeSync typeFreeSync Premium
Game featuresAuto Low Latency Mode (ALLM), Dynamic Black EQ, Game Motion Plus, Gaming Hub, HGiG, Mini Map Zoom, Super Ultra Wide Game View, Surround Sound, Variable Refresh Rate (VRR)
Multi ViewYes
SmartThings app supportYes
Tap viewYes
Smartphone/tablet remote supportYes

Ports & interfaces

HDMI ports quantity4
Ethernet LAN (RJ-45) ports1
USB 2.0 ports quantity2
Digital audio optical out1
RS-232C ports1
RF ports quantity2
RF connector typeF, IEC
Common interface (CI)Yes
Common interface Plus (CI+)Yes
Common interface Plus (CI+) version1.4
Consumer Electronics Control (CEC)Anynet+

Management features

Voice guideYes
Electronic Programme Guide (EPG)Yes
On Screen Display (OSD)Yes
Number of OSD languages27
ECO modeYes
Auto power offYes
Works with Amazon AlexaYes
Works with Samsung BixbyYes
Works with the Google AssistantYes
Universal Browse & PlayYes

Power

Power consumption (typical)129 W
Power consumption (standby)0.5 W
Power consumption (max)290 W
Energy efficiency class (SDR)F
Energy efficiency class (HDR)G
Energy consumption (SDR) per 1000 hours129 kWh
Energy consumption (HDR) per 1000 hours264 kWh
AC input voltage220 - 240 V
AC input frequency50/60 Hz
Energy efficiency scaleA to G

Brand-specific features

Samsung technologies (AV/TV)AI Scaling, Active Voice Amplifier Pro, AirPlay 2, Contrast Enhancer, Dolby Atmos®, Dual LED, HDR10+, Matte Display, Motion Xcelerator, Object Tracking Sound, Q-Symphony, Quantum Dot Display, Quantum HDR, Quantum Processor 4K, Samsung Health, Samsung TV Plus, Smart Calibration, Supreme UHD Dimming,

Technical details

Screen TV transmission to mobile deviceYes

Weight & dimensions

Width (with stand)1682.3 mm
Depth (with stand)315.8 mm
Height (with stand)998.5 mm
Weight (with stand)35.9 kg
Width (without stand)1682.3 mm
Depth (without stand)26.9 mm
Height (without stand)960.4 mm
Weight (without stand)35.3 kg
Soundbar dimensions (W x D x H)1160 x 38 x 39.9 mm
Soundbar weight1.4 kg
Stand width104.2 cm
Stand depth31.6 cm

Packaging data

Package width1839 mm
Package depth207 mm
Package height1113 mm
Package weight50.7 kg

Packaging content

Cables includedAC
Remote control includedYes
Remote control typeTM2361E
Soundbar includedYes

Other features

One Connect boxYes
One Connect box typeOne Connect (Y22 4K)
