TERRA 1090 Industry

Model 1090 IndustryPart no. 1220429EAN 4039407038565

116 specifications Checked 3 days ago

Display25.6 cm (10.1")
Resolution1920 x 1200 pixels
ProcessorIntel® Core™ i5
Memory4 GB
Storage128 GB
Camera5 MP

See all specifications

Overview

Display: 25.6 cm (10.1")
Resolution: 1920 x 1200 pixels
Processor: Intel® Core™ i5
Memory: 4 GB
Storage: 128 GB
Camera: 5 MP

Brand: TERRA
Category: Tablet
Model: 1090 Industry
Part numbers: 1220429, 1220458, 1220549
EAN / UPC: 4039407038565, 4039407029181, 4039407029686
Also known as: TERRA PAD 1090 Industry 3G Intel® Core™ i5 128 GB 25.6 cm (10.1") 4 GB Wi-Fi 5 (802.11ac) Windows 8 Pro Black

Specifications

116 specifications in 17 groups

Display

Specification	Value
Display diagonal	25.6 cm (10.1")
Display resolution	1920 x 1200 pixels
LED backlight	Yes
Touch technology	Multi-touch
Touchscreen type	Capacitive

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i5
Processor generation	4th gen Intel® Core™ i5
Processor model	i5-4300U
Processor cores	2
Processor threads	4
Processor boost frequency	2.9 GHz
Processor frequency	1.9 GHz
Processor cache	3 MB
Processor cache type	Smart Cache
Bus type	DMI2
Conflict-Free processor	Yes
PCI Express configurations	4x1, 2x4
Processor code	SR1ED
Processor codename	Haswell
Processor lithography	22 nm
Processor operating modes	64-bit
Processor package size	40 x 24 x 1.5 mm
Processor series	Intel Core i5-4300 Mobile series
Stepping	D0
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
System bus rate	5 GT/s
Thermal Design Power (TDP)	15 W
Thermal Monitoring Technologies	Yes
Tjunction	100 °C
UART	Yes

Memory

Specification	Value
Internal memory	4 GB

Storage

Specification	Value
Internal storage capacity	128 GB
Storage media	SSD
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)

Graphics

Specification	Value
Graphics card family	Intel
Graphics card	HD Graphics 4400

Audio

Specification	Value
Built-in speaker(s)	Yes
Built-in microphone	Yes

Camera

Specification	Value
Rear camera type	Single camera
Rear camera	Yes
Rear camera resolution (numeric)	5 MP
Video recording	Yes
Front camera	Yes
Front camera resolution (numeric)	2 MP

Network

Specification	Value
Mobile network connection	Yes
Mobile network generation	3G
Bluetooth	Yes
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN	Yes

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
HDMI ports quantity	0
Ethernet LAN (RJ-45) ports	1
Microphone in	Yes
Headphone out	Yes

Design

Specification	Value
Form factor	Slate
Product colour	Black
Device type	Tablet PC

Performance

Specification	Value
Position location	Yes
GPS (satellite)	Yes

Software

Specification	Value
Platform	Windows
Operating system installed	Windows 8 Pro

Processor special features

Specification	Value
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Enhanced Halt State	Yes
Intel FDI Technology	No
Intel Identity Protection Technology version	1.00
Intel ME Firmware Version	9.5
Intel Rapid Storage Technology	Yes
Intel Secure Key Technology version	1.00
Intel Small Business Advantage (SBA) version	1.00
Intel Smart Connect Technology	Yes
Intel Smart Connect Technology version	1.00
Intel Smart Response Technology version	1.00
Intel Stable Image Platform Program (SIPP)	Yes
Intel Stable Image Platform Program (SIPP) version	1.00
Intel TSX-NI	No
Intel TSX-NI version	0.00
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Anti-Theft Technology (Intel® AT)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® High Definition Audio (Intel® HD Audio)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® InTru™ 3D Technology	Yes
Intel® Insider™	Yes
Intel® Matrix Storage Technology (Intel® MST)	No
Intel® Quick Sync Video Technology	Yes
Intel® Rapid Start Technology	Yes
Intel® Secure Key	Yes
Intel® Small Business Advantage (Intel® SBA)	Yes
Intel® Smart Cache	Yes
Intel® Smart Response Technology	Yes
Intel® Turbo Boost Technology	2.0
Intel® Wireless Display (Intel® WiDi)	Yes

Battery

Specification	Value
Battery technology	Lithium Polymer (LiPo)
Battery life (max)	6 h

Weight & dimensions

Specification	Value
Width	280 mm
Depth	195 mm
Height	23 mm
Weight	1.2 kg

Packaging content

Specification	Value
Keyboard included	No

Other features

Specification	Value
64-bit computing	Yes
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Processor socket	BGA 1168
Processor ARK ID	76308
