Lenovo ThinkPad X220 Intel® Core™ i5

160 GB 31.8 cm (12.5") 4 GB Windows 7 Professional Black

Model X220Part no. NYN2PMLEAN 645743286252

116 specifications Checked 3 days ago

Display31.8 cm (12.5")
Resolution1366 x 768 pixels
ProcessorIntel® Core™ i5
Memory4 GB
Storage160 GB
OSWindows 7 Professional

See all specifications

Overview

Display: 31.8 cm (12.5")
Resolution: 1366 x 768 pixels
Processor: Intel® Core™ i5
Memory: 4 GB
Storage: 160 GB
OS: Windows 7 Professional

Brand: Lenovo
Category: Tablet
Model: X220
Part numbers: NYN2PML, NYN2PDK, NYN2PMZ
EAN / UPC: 645743286252, 645743286450
Also known as: Lenovo ThinkPad X220 Intel® Core™ i5 160 GB 31.8 cm (12.5") 4 GB Windows 7 Professional Black

Specifications

116 specifications in 17 groups

Display

Specification	Value
Display diagonal	31.8 cm (12.5")
Display resolution	1366 x 768 pixels
LED backlight	Yes
Display brightness	300 cd/m²
Touch technology	Multi-touch
Native aspect ratio	16:9

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i5
Processor generation	2nd gen Intel® Core™ i5
Processor model	i5-2520M
Processor cores	2
Processor threads	4
Processor boost frequency	3.2 GHz
Processor frequency	2.5 GHz
Processor cache	3 MB
Processor cache type	Smart Cache
Motherboard chipset	Intel QM67
Bus type	DMI
CPU multiplier (bus/core ratio)	25
Conflict-Free processor	No
Graphics & IMC lithography	32 nm
Integrated 4G WiMAX	Yes
PCI Express configurations	1x16, 2x8, 1x8+2x4
Processor code	SR048
Processor codename	Sandy Bridge
Processor lithography	32 nm
Processor operating modes	64-bit
Processor package size	37.5 x 37.5 (rPGA988B); 31 x 24 (BGA1023)
Stepping	J1
Supported instruction sets	AVX
System bus rate	5 GT/s
Thermal Design Power (TDP)	35 W
Thermal Monitoring Technologies	Yes
Tjunction	100 °C

Memory

Specification	Value
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory clock speed	1333 MHz

Storage

Specification	Value
Internal storage capacity	160 GB
Storage media	SSD
Card reader integrated	Yes
Compatible memory cards	MMC, SD, SDHC, SDXC

Graphics

Specification	Value
Graphics card family	Intel
Graphics card	HD Graphics 3000

Audio

Specification	Value
Built-in microphone	Yes
Number of built-in speakers	2

Camera

Specification	Value
Built-in camera	Yes
Video recording	No
Second camera	No

Network

Specification	Value
Bluetooth	Yes
Bluetooth version	3.0+HS
Data network	Not supported

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	1
Microphone in	Yes
Headphone out	Yes
DC-in jack	Yes

Design

Specification	Value
Product colour	Black
Device type	Tablet PC

Performance

Specification	Value
Position location	No
GPS (satellite)	No
Trusted Platform Module (TPM)	Yes

Security

Specification	Value
Fingerprint reader	Yes
Cable lock slot	Yes
Cable lock slot type	Kensington

Software

Specification	Value
Platform	Windows
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Operating system version	Professional

Processor special features

Specification	Value
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	Yes
Intel Enhanced Halt State	Yes
Intel FDI Technology	Yes
Intel Fast Memory Access	Yes
Intel Flex Memory Access	Yes
Intel Identity Protection Technology version	1.00
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Anti-Theft Technology (Intel® AT)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® InTru™ 3D Technology	Yes
Intel® My WiFi Technology (Intel® MWT)	Yes
Intel® Quick Sync Video Technology	Yes
Intel® Smart Cache	Yes
Intel® Turbo Boost Technology	2.0
Intel® Wireless Display (Intel® WiDi)	Yes

Battery

Specification	Value
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	6
Battery life (max)	8.8 h

Weight & dimensions

Specification	Value
Width	305 mm
Depth	228.7 mm
Height	31.3 mm
Weight	1.8 kg

Other features

Specification	Value
Height (front)	2.7 cm
Height (rear)	3.13 cm
Contrast ratio (typical)	500:1
DisplayPorts quantity	1
ExpressCard slot	Yes
HDD user password	Yes
Memory slots	2 SODIMM
Networking features	Gigabit Ethernet
Processor socket	Socket 988
SSD capacity	160 GB
VGA (D-Sub) ports quantity	1
Wi-Fi	Yes
Processor ARK ID	52229
