Lenovo ThinkPad Helix Intel® Core™ M

180 GB 29.5 cm (11.6") 8 GB Wi-Fi 4 (802.11n) Windows 8.1 Pro Black

Model HelixPart no. 20CH0048USEAN 889233521151

132 specifications Checked 3 days ago

Display29.5 cm (11.6")
Resolution1920 x 1080 pixels
ProcessorIntel® Core™ M
Memory8 GB
Storage180 GB
Camera5 MP

See all specifications

Overview

Display: 29.5 cm (11.6")
Resolution: 1920 x 1080 pixels
Processor: Intel® Core™ M
Memory: 8 GB
Storage: 180 GB
Camera: 5 MP

Brand: Lenovo
Category: Tablet
Model: Helix
Part numbers: 20CH0048US, 369723U-RFB, 20CH0021US, 20CH0022US, 20CH0023US, 20CH0024US +5 more
EAN / UPC: 889233521151, 889233521137, 889233521182, 889233521175 +6 more
Also known as: Lenovo ThinkPad Helix Intel® Core™ M 180 GB 29.5 cm (11.6") 8 GB Wi-Fi 4 (802.11n) Windows 8.1 Pro Black

Specifications

132 specifications in 22 groups

Display

Specification	Value
Display diagonal	29.5 cm (11.6")
Panel type	IPS
Display resolution	1920 x 1080 pixels
Touch technology	Multi-touch
Native aspect ratio	16:9

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ M
Processor generation	Intel® Core™ m-5xxx
Processor model	M-5Y71
Processor cores	2
Processor threads	4
Processor boost frequency	2.9 GHz
Processor frequency	1.2 GHz
Processor cache	4 MB
Processor cache type	L3
Configurable TDP-down frequency	0.6 GHz
Conflict-Free processor	Yes
Graphics & IMC lithography	14 nm
Processor code	SR23Q
Processor codename	Broadwell
Processor lithography	14 nm
Processor operating modes	32-bit, 64-bit
Processor package size	30 x 16.5 mm
Processor series	Intel Core M-5Y Mobile series
Scenario Design Power (SDP)	3.5 W
Stepping	F0
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)	4.5 W
Thermal Monitoring Technologies	Yes
Tjunction	95 °C

Memory

Specification	Value
Internal memory	8 GB
Internal memory type	DDR3L-SDRAM
Maximum internal memory	8 GB
Memory clock speed	1333 MHz

Storage

Specification	Value
Internal storage capacity	180 GB
Storage media	SSD
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)

Graphics

Specification	Value
Graphics card family	Intel
Graphics card	HD Graphics 5300

Audio

Specification	Value
Built-in speaker(s)	Yes
Built-in microphone	Yes

Camera

Specification	Value
Rear camera type	Single camera
Rear camera	Yes
Rear camera resolution (numeric)	5 MP
Video recording	Yes
Video recording modes	1080p
Front camera	Yes
Front camera resolution (numeric)	2 MP

Network

Specification	Value
Bluetooth	Yes
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Wi-Fi standards	802.11a, 802.11b, 802.11g
Ethernet LAN	No
Near Field Communication (NFC)	No
Dual SIM support	No

Ports & interfaces

Specification	Value
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
HDMI ports quantity	0
Micro HDMI ports quantity	1
Microphone in	No
Headphone out	Yes
Headphone connectivity	3.5 mm
Combo headphone/mic port	Yes
DC-in jack	Yes

Design

Specification	Value
Form factor	Convertible (Detachable)
Product colour	Black
Device type	Tablet PC

Performance

Specification	Value
Position location	No
GPS (satellite)	No
Trusted Platform Module (TPM)	Yes

Sensors

Specification	Value
Accelerometer	Yes
Ambient light sensor	Yes
Gyroscope	Yes
Electronic compass	Yes

Security

Specification	Value
Fingerprint reader	Yes

Software

Specification	Value
Platform	Windows
Operating system installed	Windows 8.1 Pro

Processor special features

Specification	Value
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Enhanced Halt State	Yes
Intel FDI Technology	Yes
Intel Fast Memory Access	Yes
Intel Flex Memory Access	Yes
Intel Identity Protection Technology version	1.00
Intel Secure Key Technology version	1.00
Intel Small Business Advantage (SBA) version	1.00
Intel Smart Response Technology version	1.00
Intel Stable Image Platform Program (SIPP)	Yes
Intel Stable Image Platform Program (SIPP) version	1.00
Intel TSX-NI	Yes
Intel TSX-NI version	1.00
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® InTru™ 3D Technology	Yes
Intel® Insider™	Yes
Intel® OS Guard	Yes
Intel® Quick Sync Video Technology	Yes
Intel® Secure Key	Yes
Intel® Small Business Advantage (Intel® SBA)	Yes
Intel® Smart Cache	Yes
Intel® Smart Response Technology	Yes
Intel® Turbo Boost Technology	2.0
Intel® Wireless Display (Intel® WiDi)	Yes

Battery

Specification	Value
Battery technology	Lithium Polymer (LiPo)
Battery capacity	35 Wh
Battery life (max)	8 h

Power

Specification	Value
AC adapter power	36 W

Weight & dimensions

Specification	Value
Width	301 mm
Depth	192 mm
Height	9.4 mm
Weight	794 g

Packaging content

Specification	Value
Keyboard included	Yes
Manual	Yes
Quick start guide	Yes
Warranty card	Yes

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

Certificates

Specification	Value
Compliance certificates	RoHS

Other features

Specification	Value
64-bit computing	Yes
Intel segment tagging	Home office, Small Business
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Processor socket	BGA 1234
RAM capacity	8 GB
Processor ARK ID	84672
