Lenovo 10 (2nd Gen)

Model 10 (2nd Gen)Part no. 20E4S01B00EAN 889800640629

119 specifications Checked 5 days ago

Display25.6 cm (10.1")
Resolution1920 x 1200 pixels
ProcessorIntel Atom®
Memory4 GB
Storage128 GB
Camera5 MP

See all specifications

Overview

Display: 25.6 cm (10.1")
Resolution: 1920 x 1200 pixels
Processor: Intel Atom®
Memory: 4 GB
Storage: 128 GB
Camera: 5 MP

Brand: Lenovo
Category: Tablet
Model: 10 (2nd Gen)
Part numbers: 20E4S01B00, 20E4S01900, 20E4S01A00, 20E40007US, 20E40008US, 20E40009US +4 more
EAN / UPC: 889800640629, 889800640704, 889800640766, 889800640810
Also known as: Lenovo ThinkPad 10 (2nd Gen) 4G Intel Atom® LTE 128 GB 25.6 cm (10.1") 4 GB Wi-Fi 5 (802.11ac) Windows 10 Home Black

Specifications

119 specifications in 19 groups

Display

Specification	Value
Display diagonal	25.6 cm (10.1")
Panel type	IPS
Display resolution	1920 x 1200 pixels
LED backlight	Yes
Touch technology	Multi-touch
Touchscreen type	Capacitive
Native aspect ratio	16:10

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Atom®
Processor model	x7-Z8700
Processor cores	4
Processor threads	4
Processor boost frequency	2.4 GHz
Processor frequency	1.6 GHz
Processor cache	2 MB
Processor cache type	L3
Conflict-Free processor	Yes
Number of execution units	16
PCI Express configurations	2x1, 1x2
Processor code	SR27M
Processor codename	Cherry Trail
Processor lithography	14 nm
Processor operating modes	64-bit
Processor package size	17 x 17 mm
Processor series	Intel Atom x7 Series
Scenario Design Power (SDP)	2 W
Stepping	C0
Tjunction	90 °C

Memory

Specification	Value
Internal memory	4 GB
Internal memory type	LPDDR3-SDRAM
Maximum internal memory	4 GB
Memory clock speed	1600 MHz

Storage

Specification	Value
Internal storage capacity	128 GB
Storage media	Flash
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	64 GB

Graphics

Specification	Value
Graphics card family	Intel
Graphics card	HD Graphics

Audio

Specification	Value
Built-in speaker(s)	Yes
Built-in microphone	Yes
Number of built-in speakers	2

Camera

Specification	Value
Rear camera type	Single camera
Rear camera	Yes
Rear camera resolution (numeric)	5 MP
Auto focus	Yes
Rear camera flash	Yes
Flash type	LED
Maximum video resolution	1920 x 1080 pixels
Video recording	Yes
Front camera	Yes
Front camera resolution (numeric)	1.2 MP

Network

Specification	Value
Mobile network connection	Yes
Mobile network generation	4G
4G standard	LTE
Bluetooth	Yes
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Near Field Communication (NFC)	Yes
WWAN	Installed
Wi-Fi Direct	Yes

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	1
Mobile High-Definition Link (MHL)	No
HDMI ports quantity	0
Micro HDMI ports quantity	1
Microphone in	No
Headphone out	No
Headphone connectivity	3.5 mm
Combo headphone/mic port	Yes

Design

Specification	Value
Form factor	Slate
Product colour	Black
Device type	Tablet PC

Performance

Specification	Value
Position location	No
GPS (satellite)	No
Trusted Platform Module (TPM)	Yes

Sensors

Specification	Value
Accelerometer	Yes
Ambient light sensor	Yes
Gyroscope	Yes
Electronic compass	Yes

Software

Specification	Value
Platform	Windows
Operating system installed	Windows 10 Home
Operating system architecture	64-bit

Processor special features

Specification	Value
Embedded options available	No
Intel 64	Yes
Intel Identity Protection Technology version	1.00
Intel Secure Boot	Yes
Intel Secure Boot Technology version	1.00
Intel Smart Connect Technology	No
Intel Virtualization Technology (VT-x)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Rapid Start Technology	No
Intel® Small Business Advantage (Intel® SBA)	No
Intel® Smart Response Technology	No
Intel® Turbo Boost Technology	No
Intel® Wireless Display (Intel® WiDi)	Yes

Battery

Specification	Value
Battery technology	Lithium Polymer (LiPo)
Battery capacity	32 Wh
Number of battery cells	2
Battery life (max)	10 h

Power

Specification	Value
AC adapter power	36 W
AC adapter input voltage	100 - 240 V
AC adapter frequency	50 - 60 Hz

Weight & dimensions

Specification	Value
Width	256.5 mm
Depth	177 mm
Height	8.95 mm
Weight	595 g

Packaging content

Specification	Value
AC adapter included	Yes
Keyboard included	Yes
Stylus pen	Yes
Manual	Yes
Quick start guide	Yes

Other features

Specification	Value
64-bit computing	Yes
Processor socket	BGA 1380
Processor ARK ID	85475
