Dell RA02260 Intel Core Ultra 5

RA02260 Intel Core Ultra 5

512 GB 30.5 cm (12") 16 GB Wi-Fi 7 (802.11be) Windows 11 Pro Black

Model RA02260Part no. XCTO_RA02260_USX

100 specifications Checked today

Display30.5 cm (12")
Resolution1920 x 1200 pixels
ProcessorIntel Core Ultra 5
Memory16 GB
Storage512 GB
Camera11 MP

See all specifications

Overview

Display: 30.5 cm (12")
Resolution: 1920 x 1200 pixels
Processor: Intel Core Ultra 5
Memory: 16 GB
Storage: 512 GB
Camera: 11 MP

Brand: Dell
Category: Tablet
Model: RA02260
Part numbers: XCTO_RA02260_USX, XCTO_RA02260_CAX, XCTO_RA02260_EMEA
Also known as: DELL RA02260 Intel Core Ultra 5 512 GB 30.5 cm (12") 16 GB Wi-Fi 7 (802.11be) Windows 11 Pro Black

Specifications

100 specifications in 21 groups

Display

Specification	Value
Display diagonal	30.5 cm (12")
Panel type	WVA
Display resolution	1920 x 1200 pixels
Maximum refresh rate	60 Hz
LED backlight	Yes
Display brightness	1200 cd/m²
Anti-glare screen	Yes
HD type	Full HD+
Pixel density	188 ppi
Native aspect ratio	16:10

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Core Ultra 5
Processor generation	Intel Core Ultra (Series 2)
Processor model	236V
Processor cores	8
Processor boost frequency	4.7 GHz
Performance cores	4
Low Power Efficient-cores	4
Performance-core Max Turbo Frequency	4.7 GHz
Low Power Efficient-core Max Turbo Frequency	3.5 GHz
Performance-core base frequency	2.1 GHz
Low Power Efficient-core Base Frequency	2100 MHz
Processor cache	8 MB
Processor cache type	Smart Cache

Neural processor unit (NPU)

Specification	Value
Neural processor unit (NPU)	Intel AI Boost
Sparsity support	Yes
Windows Studio effects support	Yes
AI software frameworks supported by NPU	DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance up to	97 TOPs
NPU performance up to	40 TOPs

Memory

Specification	Value
Internal memory	16 GB
Internal memory type	LPDDR5x-SDRAM
Memory clock speed	8533 MHz

Storage

Specification	Value
Internal storage capacity	512 GB
Storage media	SSD
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)
NVMe	Yes
SSD interface	PCI Express
SSD memory type	TLC

Graphics

Specification	Value
Graphics card family	Intel
Graphics card	Arc Graphics 130V
Ray tracing acceleration	Yes

Audio

Specification	Value
Number of built-in speakers	2
Audio system	High Deﬁnition (HD)
Speaker power	4 W

Camera

Specification	Value
Rear camera type	Single camera
Rear camera resolution (numeric)	11 MP
Rear camera resolution	3976 x 2736 pixels
Maximum video resolution	1920 x 1080 pixels
Video capturing speed	30 fps
Front camera	Yes
Front camera resolution (numeric)	8 MP

Network

Specification	Value
Mobile network connection	No
Bluetooth	Yes
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Wi-Fi data rate (max)	5760 Mbit/s
WLAN controller manufacturer	Intel
WLAN controller model	Intel Wi-Fi 7 BE201
Ethernet LAN	Yes

Ports & interfaces

Specification	Value
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Thunderbolt 4 ports quantity	2
Combo headphone/mic port	Yes

Phone features

Specification	Value
Video call	Yes
Voice call	Yes

Design

Specification	Value
Form factor	Slate
Product colour	Black
Device type	Tablet PC

Sensors

Specification	Value
Accelerometer	Yes
Ambient light sensor	Yes
Proximity sensor	Yes
Hall sensor	Yes
Electronic compass	Yes
Magnetometer	Yes

Security

Specification	Value
Fingerprint reader	Yes

Software

Specification	Value
Platform	Windows
Operating system installed	Windows 11 Pro

Battery

Specification	Value
Battery capacity	35.6 Wh
Number of battery cells	2
Battery voltage	8.96 V
Fast charging	Yes
Battery recharge time	4 h

Power

Specification	Value
AC adapter power	65 W
AC adapter input voltage	100 - 240 V
AC adapter frequency	50/60 Hz
USB Type-C charging port	Yes
USB Type-C required charging power (max)	65 W
USB Type-C required charging power (min)	27 W

Endurance

Specification	Value
International Protection (IP) code	IP66

Weight & dimensions

Specification	Value
Width	301 mm
Depth	208 mm
Height	29.6 mm
Weight	1.31 kg

Packaging content

Specification	Value
AC adapter included	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	-29 - 63 °C
Storage temperature (T-T)	-51 - 71 °C
Operating relative humidity (H-H)	10 - 96%
Storage relative humidity (H-H)	5 - 95%
Operating altitude	0 - 12192 m
