ASUS ZenPad S 8.0 Z580CA-1A065A Intel Atom®

32 GB 20.3 cm (8") 2 GB Wi-Fi 5 (802.11ac) Android Black

Model Z580CA-1A065APart no. 90NP01M1-M01340EAN 4712900126556

86 specifications Checked 2 days ago

Display20.3 cm (8")
Resolution2048 x 1536 pixels
ProcessorIntel Atom®
Memory2 GB
Storage32 GB
Camera8 MP

See all specifications

Overview

Display: 20.3 cm (8")
Resolution: 2048 x 1536 pixels
Processor: Intel Atom®
Memory: 2 GB
Storage: 32 GB
Camera: 8 MP

Brand: ASUS
Category: Tablet
Model: Z580CA-1A065A
Part number: 90NP01M1-M01340
EAN / UPC: 4712900126556
Also known as: ASUS ZenPad S 8.0 Z580CA-1A065A Intel Atom® 32 GB 20.3 cm (8") 2 GB Wi-Fi 5 (802.11ac) Android Black

Specifications

86 specifications in 18 groups

Display

Specification	Value
Display diagonal	20.3 cm (8")
Panel type	IPS
Display resolution	2048 x 1536 pixels
LED backlight	Yes
Touch technology	Multi-touch
Touchscreen type	Capacitive

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Atom®
Processor model	Z3560
Processor cores	4
Processor threads	4
Processor boost frequency	1.83 GHz
Processor frequency	1.83 GHz
Processor cache	2 MB
Processor cache type	Smart Cache
Conflict-Free processor	Yes
Processor lithography	22 nm
Processor operating modes	32-bit, 64-bit
Processor package size	14 x 14 mm
Supported instruction sets	AES, SSE2, SSE3, SSE4.1, SSE4.2, SSSE3
Thermal Monitoring Technologies	Yes
Tjunction	90 °C
UART	Yes

Memory

Specification	Value
Internal memory	2 GB
Internal memory type	LPDDR3-SDRAM
Memory clock speed	1600 MHz

Storage

Specification	Value
Internal storage capacity	32 GB
Storage media	SSD
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash), SDXC
Maximum memory card size	128 GB

Graphics

Specification	Value
Graphics card family	Imagination Technologies

Audio

Specification	Value
Built-in speaker(s)	Yes
Built-in microphone	Yes
Number of built-in speakers	2
Audio system	DTS Sound

Camera

Specification	Value
Rear camera type	Single camera
Rear camera	Yes
Rear camera resolution (numeric)	8 MP
Video recording	Yes
Front camera	Yes
Front camera resolution (numeric)	5 MP

Network

Specification	Value
Bluetooth	Yes
Bluetooth version	4.1
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Near Field Communication (NFC)	No

Ports & interfaces

Specification	Value
Microphone in	No
Headphone out	No
Headphone connectivity	3.5 mm
Combo headphone/mic port	Yes

Design

Specification	Value
Form factor	Slate
Product colour	Black
Device type	Mobile tablet

Performance

Specification	Value
Position location	Yes
GLONASS	Yes
GPS (satellite)	Yes

Sensors

Specification	Value
Ambient light sensor	Yes

Software

Specification	Value
Platform	Android
Operating system installed	Android
Operating system architecture	64-bit
Operating system version	5.0 Lollipop

Processor special features

Specification	Value
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Smart Idle Technology	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Secure Key	Yes
Intel® Wireless Display (Intel® WiDi)	Yes
Physical Address Extension (PAE)	32 bit
Physical Address Extension (PAE)	Yes

Battery

Specification	Value
Battery technology	Lithium Polymer (LiPo)
Battery capacity	15.2 Wh
Battery life (max)	8 h

Weight & dimensions

Specification	Value
Width	203.2 mm
Depth	134.5 mm
Height	6.6 mm
Weight	298 g

Packaging content

Specification	Value
Keyboard included	No

Other features

Specification	Value
64-bit computing	Yes
Intel® Virtualization Technology (Intel® VT)	VT-x
Processor ARK ID	81194
