ASUS ZenPad S 8.0 Z580CA-1A063A Intel Atom®

64 GB 20.3 cm (8") 4 GB Wi-Fi 5 (802.11ac) Android Black

Model Z580CA-1A063APart no. 90NP01M1-M01300EAN 4712900123807

87 specifications Checked 2 days ago

Display20.3 cm (8")
Resolution2048 x 1536 pixels
ProcessorIntel Atom®
Memory4 GB
Storage64 GB
Camera8 MP

See all specifications

Overview

Display: 20.3 cm (8")
Resolution: 2048 x 1536 pixels
Processor: Intel Atom®
Memory: 4 GB
Storage: 64 GB
Camera: 8 MP

Brand: ASUS
Category: Tablet
Model: Z580CA-1A063A
Part number: 90NP01M1-M01300
EAN / UPC: 4712900123807
Also known as: ASUS ZenPad S 8.0 Z580CA-1A063A Intel Atom® 64 GB 20.3 cm (8") 4 GB Wi-Fi 5 (802.11ac) Android Black

Specifications

87 specifications in 18 groups

Display

Specification	Value
Display diagonal	20.3 cm (8")
Panel type	IPS
Display resolution	2048 x 1536 pixels
LED backlight	Yes
Touch technology	Multi-touch
Native aspect ratio	4:3

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Atom®
Processor model	Z3580
Processor cores	4
Processor threads	4
Processor frequency	2.33 GHz
Processor cache	2 MB
Processor cache type	Smart Cache
Conflict-Free processor	Yes
Processor lithography	22 nm
Processor operating modes	32-bit, 64-bit
Processor package size	14 x 14 mm
Supported instruction sets	AES, SSE2, SSE3, SSE4.1, SSE4.2, SSSE3
Thermal Monitoring Technologies	Yes
Tjunction	90 °C
UART	Yes

Memory

Specification	Value
Internal memory	4 GB

Storage

Specification	Value
Internal storage capacity	64 GB
Storage media	Flash
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB

Graphics

Specification	Value
Graphics card	PowerVR G6430

Audio

Specification	Value
Built-in speaker(s)	Yes
Built-in microphone	Yes
Number of built-in speakers	2
Audio system	DTS Sound

Camera

Specification	Value
Rear camera type	Single camera
Rear camera	Yes
Rear camera resolution (numeric)	8 MP
Front camera	Yes
Front camera resolution (numeric)	5 MP

Network

Specification	Value
Bluetooth	Yes
Bluetooth version	4.1
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
Mini-USB 2.0 ports quantity	1
Mobile High-Definition Link (MHL)	No
HDMI ports quantity	0
Microphone in	Yes
Headphone out	Yes
Headphone connectivity	3.5 mm

Design

Specification	Value
Form factor	Slate
Product colour	Black
Device type	Mobile tablet

Performance

Specification	Value
Position location	Yes
GLONASS	Yes
GPS (satellite)	Yes

Sensors

Specification	Value
Ambient light sensor	Yes
Orientation sensor	Yes
Electronic compass	Yes

Software

Specification	Value
Platform	Android
Operating system installed	Android
Operating system version	5.0

Processor special features

Specification	Value
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Smart Idle Technology	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Secure Key	Yes
Intel® Wireless Display (Intel® WiDi)	Yes
Physical Address Extension (PAE)	32 bit
Physical Address Extension (PAE)	Yes

Battery

Specification	Value
Battery technology	Lithium Polymer (LiPo)
Battery capacity	15.2 Wh
Battery life (max)	8 h

Weight & dimensions

Specification	Value
Width	134.5 mm
Depth	203.2 mm
Height	6.6 mm
Weight	298 g

Packaging content

Specification	Value
Keyboard included	No
Cables included	USB
Manual	Yes
Quick start guide	Yes

Other features

Specification	Value
64-bit computing	Yes
Intel® Virtualization Technology (Intel® VT)	VT-x
Processor ARK ID	81195
