Acer Iconia B1-730HD-18CN Intel Atom®

16 GB 17.8 cm (7") 1 GB Wi-Fi 4 (802.11n) Android Blue

Model B1-730HD-18CNPart no. NT.L4XAL.001

100 specifications Checked 3 days ago

Display17.8 cm (7")
Resolution1280 x 800 pixels
ProcessorIntel Atom®
Memory1 GB
Storage16 GB
Camera2 MP

See all specifications

Overview

Display: 17.8 cm (7")
Resolution: 1280 x 800 pixels
Processor: Intel Atom®
Memory: 1 GB
Storage: 16 GB
Camera: 2 MP

Brand: Acer
Category: Tablet
Model: B1-730HD-18CN
Part number: NT.L4XAL.001
Also known as: Acer Iconia B1-730HD-18CN Intel Atom® 16 GB 17.8 cm (7") 1 GB Wi-Fi 4 (802.11n) Android Blue

Specifications

100 specifications in 20 groups

Display

Specification	Value
Display diagonal	17.8 cm (7")
Display resolution	1280 x 800 pixels
Display technology	LCD
LED backlight	Yes
Touch technology	Multi-touch

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Atom®
Processor model	Z2560
Processor cores	2
Processor threads	4
Processor boost frequency	1.6 GHz
Processor cache	1 MB
Processor cache type	Smart Cache
Conflict-Free processor	Yes
Graphics & IMC lithography	32 nm
Processor code	SR145
Processor lithography	32 nm
Processor operating modes	32-bit
Processor package size	14 x 14 mm
Stepping	B1
Supported instruction sets	SSE2, SSE3, SSSE3
Thermal Monitoring Technologies	Yes
Tjunction	90 °C
UART	Yes

Memory

Specification	Value
Internal memory	1 GB
Internal memory type	LPDDR2-SDRAM

Storage

Specification	Value
Internal storage capacity	16 GB
Storage media	Flash
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Maximum memory card size	32 GB

Graphics

Specification	Value
Graphics card family	Intel

Audio

Specification	Value
Built-in speaker(s)	Yes
Built-in microphone	Yes
Number of built-in speakers	2

Camera

Specification	Value
Rear camera type	Single camera
Rear camera	Yes
Rear camera resolution (numeric)	2 MP
Rear camera resolution	1600 x 1200 pixels
Maximum video resolution	1280 x 720 pixels
Video recording	Yes
Front camera	Yes
Front camera resolution (numeric)	0.3 MP

Network

Specification	Value
Bluetooth	Yes
Bluetooth version	3.0+HS
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
Micro-USB 2.0 ports quantity	1
Mobile High-Definition Link (MHL)	No
HDMI ports quantity	0
Microphone in	No
Headphone out	Yes
Headphone connectivity	3.5 mm

Design

Specification	Value
Form factor	Slate
Product colour	Blue
Device type	Mobile tablet

Performance

Specification	Value
Position location	No
GPS (satellite)	No

Software

Specification	Value
Platform	Android
Operating system installed	Android
Operating system version	Android 4.2 (Jelly Bean)

Processor special features

Specification	Value
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Idle States	Yes
Intel Enhanced Halt State	Yes
Intel Smart Connect Technology	No
Intel Smart Idle Technology	Yes
Intel Smart Idle Technology version	1.00
Intel Virtualization Technology (VT-x)	Yes
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Identity Protection Technology (Intel® IPT)	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Rapid Start Technology	No
Intel® Small Business Advantage (Intel® SBA)	No
Intel® Smart Response Technology	No
Intel® Turbo Boost Technology	No
Intel® Wireless Display (Intel® WiDi)	No
Physical Address Extension (PAE)	32 bit
Physical Address Extension (PAE)	Yes

Battery

Specification	Value
Battery technology	Lithium Polymer (LiPo)
Battery capacity	3700 mAh
Number of battery cells	1

Power

Specification	Value
AC adapter power	10 W

Media formats

Specification	Value
Audio formats supported	MP3
Image formats supported	JPG
Video compression formats	MP4

Weight & dimensions

Specification	Value
Width	120 mm
Depth	197.5 mm
Height	8.95 mm
Weight	330 g

Packaging content

Specification	Value
Keyboard included	No
Quick start guide	Yes

Certificates

Specification	Value
Compliance certificates	RoHS
Certification	WEEE

Other features

Specification	Value
Processor socket	FC-MB4760
Wi-Fi	Yes
Processor ARK ID	70101
