USB-C/USB-A to M.2 NVMe and
2.5in/3.5in SATA Adapter, 10Gbps, Tool-Free External SSD Hard Drive Reader, B+M/M-Key
Model USB31CSAT3M2EEAN 065030920575
39 specifications
- Speed10 Gbit/s
- Weight50 g
- ColourBlack
- Storage media typeHDD, SSD
- Host interfaceUSB 3.2 Gen 2 (3.1 Gen 2) Type-C
- Number of fans0 fan(s)
Overview
- Speed
- 10 Gbit/s
- Weight
- 50 g
- Colour
- Black
- Storage media type
- HDD, SSD
- Host interface
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C
- Number of fans
- 0 fan(s)
- Brand
- StarTech.com
- Category
- Storage Drive Docking Station
- Model
- USB31CSAT3M2E
- Part number
- USB31CSAT3M2E
- EAN / UPC
- 065030920575
- Also known as
- StarTech.com USB-C/USB-A to M.2 NVMe and 2.5in/3.5in SATA Adapter, 10Gbps, Tool-Free External SSD Hard Drive Reader, B+M/M-Key
Specifications
39 specifications in 11 groups
Hard drive
| Specification | Value |
|---|---|
| Storage media type | HDD, SSD |
| Storage drive interface | M.2, Serial ATA III |
| Storage drive sizes supported | 2.5,3.5" |
| Number of storage drives supported | 2 |
Ports & interfaces
| Specification | Value |
|---|---|
| Host interface | USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
Features
| Specification | Value |
|---|---|
| Product colour | Black |
| Material | Acrylonitrile butadiene styrene (ABS) |
| Maximum data transfer rate | 10 Gbit/s |
| Hot-swap | Yes |
| TRIM support | Yes |
| LED indicators | Yes |
| UASP support | Yes |
Cooling
| Specification | Value |
|---|---|
| Number of fans | 0 fan(s) |
Power
| Specification | Value |
|---|---|
| AC input voltage | 12 V |
| Input current | 2 A |
| Output voltage | 12 V |
| Output current | 2 A |
| Power plug type | Type H |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 88.4 mm |
| Depth | 360.6 mm |
| Height | 14.1 mm |
| Weight | 50 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 190 mm |
| Package depth | 123 mm |
| Package height | 54 mm |
| Package weight | 330 g |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Included power plug types | ANZ, EU, JP, NA, UK |
| Interface adapters included | USB Type-A male - USB Type-C female |
| Quick installation guide | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 90% |
Other features
| Specification | Value |
|---|---|
| Chipset | JMS581DC |
| Compliance certificates | RoHS, Trade Agreements Act (TAA) |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case width | 400 mm |
| Master (outer) case length | 290 mm |
| Master (outer) case height | 275 mm |
| Products per master (outer) case | 20 pc(s) |
