IB-125CH USB 3.2 Gen 1 (3.1 Gen 1) Type-B Black
Model IB-125CHPart no. 20927EAN 4250078162384
39 specifications
- Speed5 Gbit/s
- Weight525 g
- ColourBlack
- Storage media typeHDD, SSD
- Host interfaceUSB 3.2 Gen 1 (3.1 Gen 1) Type-B
- AC input voltage100-240 V
Overview
- Speed
- 5 Gbit/s
- Weight
- 525 g
- Colour
- Black
- Storage media type
- HDD, SSD
- Host interface
- USB 3.2 Gen 1 (3.1 Gen 1) Type-B
- AC input voltage
- 100-240 V
- Brand
- ICY BOX
- Category
- Storage Drive Docking Station
- Model
- IB-125CH
- Part number
- 20927
- EAN / UPC
- 4250078162384
- Also known as
- ICY BOX IB-125CH USB 3.2 Gen 1 (3.1 Gen 1) Type-B Black
Specifications
39 specifications in 9 groups
Hard drive
| Specification | Value |
|---|---|
| Storage media type | HDD, SSD |
| Storage drive interface | Serial ATA III |
| Storage drive sizes supported | 2.5,3.5" |
| Number of storage drives supported | 1 |
Ports & interfaces
| Specification | Value |
|---|---|
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-B |
| USB 3.2 Gen 1 (3.1 Gen 1) ports quantity | 4 |
| DC-in jack | Yes |
Features
| Specification | Value |
|---|---|
| Product colour | Black |
| Material | Aluminium, Plastic |
| Maximum data transfer rate | 5 Gbit/s |
| Backup function | Yes |
| Hot-swap | Yes |
| Plug and Play | Yes |
| LED indicators | Activity, Charging, Power, USB |
| On/off switch | Yes |
| UASP support | Yes |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 1.5 A |
| Output voltage | 12 V |
| Output current | 3 A |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Mac compatibility | Yes |
| Mac operating systems supported | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 102 mm |
| Depth | 142 mm |
| Height | 81 mm |
| Weight | 525 g |
Packaging data
| Specification | Value |
|---|---|
| Package dimensions (WxDxH) | 140 x 180 x 148 mm |
| Package weight | 744 g |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | USB |
| Manual | Yes |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | China |
| Master (outer) case width | 450 mm |
| Master (outer) case length | 380 mm |
| Master (outer) case height | 310 mm |
| Master (outer) case gross weight | 10 kg |
| Products per master (outer) case | 12 pc(s) |
