TS-400-248B solar inverter Black
Model TS-400-248B
24 specifications
- Power400 W
- TypeStand-alone inverter
- Weight1.5 kg
- ColourBlack
- Fuse rating20Ax1
- Built-in displayNo
Overview
- Power
- 400 W
- Type
- Stand-alone inverter
- Weight
- 1.5 kg
- Colour
- Black
- Fuse rating
- 20Ax1
- Built-in display
- No
- Brand
- Dahua Technology
- Category
- Solar Inverter
- Model
- TS-400-248B
- Part number
- TS-400-248B
- Also known as
- Dahua Technology TS-400-248B solar inverter Black
Specifications
24 specifications in 8 groups
Features
| Specification | Value |
|---|---|
| Product type | Stand-alone inverter |
| Input operation voltage (min) | 200 V |
| Input operation voltage (max) | 240 V |
| Output frequency | 50/60 Hz |
| Maximum power | 400 W |
| DC input voltage | 42 - 60 V |
| Output current | 10 A |
| Total Harmonic Distortion (THD) | 3% |
| Efficiency | 88.5% |
Battery
| Specification | Value |
|---|---|
| Fuse rating | 20Ax1 |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Power protection features | Over voltage, Overload, Reverse polarity |
| Easy to install | Yes |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -10 - 40 °C |
| Storage temperature (T-T) | -30 - 70 °C |
| Operating relative humidity (H-H) | 20 - 90% |
| Storage relative humidity (H-H) | 10 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 158 mm |
| Depth | 205 mm |
| Height | 67 mm |
| Weight | 1.5 kg |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE |
Sustainability
| Specification | Value |
|---|---|
| Sustainability compliance | Yes |
