TC 1100
Model TC 1100Part no. JT-0100AB-2EAN 4025112082450
25 specifications
- ConnectivityUSB 2.0
- Weight75 g
- ColourBlack
- Plug and PlayYes
- Placement supportedIndoor
- Operating temperature (T-T)0 - 50 °C
Overview
- Connectivity
- USB 2.0
- Weight
- 75 g
- Colour
- Black
- Plug and Play
- Yes
- Placement supported
- Indoor
- Operating temperature (T-T)
- 0 - 50 °C
- Brand
- Cherry
- Category
- Smart Card Reader
- Model
- TC 1100
- Part numbers
- JT-0100AB-2, JT-0100WB-2, JT-0100WB-0
- EAN / UPC
- 4025112082450, 2504021509132, 4025112082467, 4025112082481
- Also known as
- CHERRY TC 1100 smart card reader Indoor USB 2.0 Black
Specifications
25 specifications in 9 groups
Features
| Specification | Value |
|---|---|
| Plug and Play | Yes |
| Mean cycles between failures (MCBF) | 100000 |
| Compatible products | PC/SC, CCID, CT-API |
Design
| Specification | Value |
|---|---|
| Placement supported | Indoor |
| Product colour | Black |
| LED indicators | Yes |
| Cable length | 1.75 m |
Ports & interfaces
| Specification | Value |
|---|---|
| Interface | USB 2.0 |
| Supported protocols | T=0, T=1, S=8, S=9, S=10 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 65 °C |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Mac operating systems supported | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 100 mm |
| Height | 12 mm |
| Depth | 65 mm |
| Weight | 75 g |
Sustainability
| Specification | Value |
|---|---|
| Certification | EMV 2000 Level 1, VDE GS, c-tick, UL, CE, FCC, FIPS 201 |
Packaging data
| Specification | Value |
|---|---|
| Package width | 140 mm |
| Package depth | 70 mm |
| Package height | 40 mm |
| Package type | Box |
Logistics data
| Specification | Value |
|---|---|
| Products per pallet | 2400 pc(s) |
| Master (outer) cases per pallet | 20 pc(s) |
