InstaView™ GSXE81PYBD American Style Smart Fridge Freezer - Prime Silver - D Rated
Model GSXE81PYBDEAN 8806096052037
183 specifications
- Capacity628 L
- Energy classD
- Noise35 dB
- Weight139 kg
- ColourSilver
- Appliance placementFreestanding
Overview
- Capacity
- 628 L
- Energy class
- D
- Noise
- 35 dB
- Weight
- 139 kg
- Colour
- Silver
- Appliance placement
- Freestanding
- Brand
- LG
- Category
- Side-By-Side Fridge-Freezer
- Model
- GSXE81PYBD
- Part number
- GSXE81PYBD
- EAN / UPC
- 8806096052037, 8806096071984
- Also known as
- LG InstaView™ GSXE81PYBD American Style Smart Fridge Freezer - Prime Silver - D Rated
Specifications
183 specifications in 16 groups
Design
| Specification | Value |
|---|---|
| Appliance placement | Freestanding |
| Product design | American door |
| Product colour | Silver |
| Colour name | Prime Silver |
| Number of doors | 3 door(s) |
| Custom panel-ready | No |
| Door-in-Door function | Yes |
| Child lock | Yes |
| Control type | Touch |
| Built-in display | Yes |
| Display placement | Inside |
| Display type | LED |
| Touchscreen | No |
| Refrigerating medium | R600a |
| Adjustable shelves | No |
| Shelves material | Tempered glass/Plastic |
| Adjustable humidity drawer | No |
| Shelf finish type | White frame |
| Door balconies material | Plastic |
| Number of compressors | 1 |
| Chrome wire wine rack | Yes |
| Door handle(s) note | |
| Counter depth | No |
| Door gasket type | Push-in gasket |
| Door hinge | Left/right |
| Door hinge type | Fixed hinge |
| Flame-retardant back | Yes |
| Recessed handle(s) | Yes |
| Ventilation | Yes |
Performance
| Specification | Value |
|---|---|
| Total net capacity | 628 L |
| Cooling system | Dynamic (fan-assisted) |
| Climate class | T |
| Noise emission class | B |
| Noise level | 35 dB |
| Dispenser placement | Thru the door |
| Water dispenser | Yes |
| Water supply type | Water tank |
| Water tank capacity | 4.3 L |
| Water filter | No |
| Ice dispenser | Yes |
| Icemaker | Yes |
| Ice crushing | Yes |
| Air filter | No |
| Anti-odor filter | No |
| Holiday function | Yes |
| Triple Cooling system | No |
| Inverter technology | Yes |
| Ionizer | No |
| Minimum operating temperature | 16 °C |
| Maximum operating temperature | 43 °C |
| Twin Cooling System | No |
Fridge
| Specification | Value |
|---|---|
| Fridge net capacity | 407 L |
| No Frost (fridge) | Yes |
| Automatic defrost (fridge) | Yes |
| No Frost+ (fridge) | No |
| Multi-Airflow system (fridge) | Yes |
| Fridge number of shelves/baskets | 5 |
| Number of vegetable drawers | 2 |
| Telescopic drawer | No |
| Fridge door balconies | 4 |
| Egg tray | No |
| Number of egg trays | 0 |
| Bottle rack | Yes |
| Door bottle balcony | No |
| Door bottle retainer | No |
| Can drawer | No |
| Can rack | No |
| Anti-bacterial coating | No |
| Fridge temperature range | 1 - 7 °C |
| Anti-bacterial compartment | No |
| Anti-bacterial seal | No |
| Blue light technology | No |
| HarvestFresh technology | No |
| Fullfresh+ technology | No |
| Fast Cooling function | Yes |
| Super Cool function | Yes |
| Fridge number of compressors | 1 |
| Internal metal backwall design (fridge) | No |
| Fridge interior light | Yes |
| Lamp type | LED |
Freezer
| Specification | Value |
|---|---|
| Freezer net capacity | 221 L |
| Freezer position | Side-placed |
| Freezing capacity | 12 kg/24h |
| Storage time during power failure | 2 h |
| Star rating | 4* |
| No Frost (freezer) | Yes |
| Automatic defrost (freezer) | Yes |
| No Frost+ (freezer) | No |
| Freezer interior light | Yes |
| Freezer drawers quantity | 2 |
| Freezer number of shelves/baskets | 4 |
| Freezer door balconies | 2 |
| Freezer temperature (min) | -23 °C |
| Fast freeze function | Yes |
| Multi-Airflow system (freezer) | Yes |
| Ice cube tray | No |
| Freezer number of compressors | 1 |
| Freezer number of doors | 1 |
| SuperFrost function | No |
Fresh zone
| Specification | Value |
|---|---|
| Fresh zone compartment | Yes |
| Fresh zone compartment gross capacity | 45 L |
| Fresh zone compartment net capacity | 44 L |
Ergonomics
| Specification | Value |
|---|---|
| Beverage door | Yes |
| Door open alarm | Yes |
| Temperature alarm | Yes |
| Auto-close system | No |
| Castor wheels | Yes |
| Adjustable feet | Yes |
| Defrost water drain | No |
| High temperature indication | Yes |
| Cord length | 1.9 m |
| Bluetooth | No |
| Apps supported | LG ThinQ |
| Wi-Fi | Yes |
| Web browser | No |
| Number of cameras | 0 |
| Hose extender compatible | No |
Power
| Specification | Value |
|---|---|
| Energy efficiency class | D |
| Energy efficiency scale | A to G |
| Annual energy consumption | 276 kWh |
| Energy efficiency index (EEI) | 79 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 913 mm |
| Depth | 735 mm |
| Height | 1790 mm |
| Weight | 139 kg |
| Depth without handle | 73.5 cm |
| Width with door open | 163.5 cm |
| Depth with door open | 118 cm |
| Installation compartment width | 101.3 cm |
| Installation compartment depth | 78.5 cm |
| Installation compartment height | 184 cm |
Packaging data
| Specification | Value |
|---|---|
| Package dimensions (WxDxH) | 972 x 770 x 1891 mm |
| Package volume | 1415300 cm³ |
| Package width | 972 mm |
| Package depth | 770 mm |
| Package height | 1891 mm |
| Package weight | 145 kg |
Brand-specific features
| Specification | Value |
|---|---|
| LG technologies (food storage) | Door-in-Door™, DoorCooling+™, Frost Free Freezer, Ice Dispenser, InstaView™ Door-in-Door™, InstaView™ ThinQ™, NatureFRESH™ with DoorCooling+™, NatureFRESH™ with Linear Cooling™, Slim SpacePlus® Ice System, Smart Inverter Compressor™, ThinQ, Total No Frost, UVNano™ |
Certificates
| Specification | Value |
|---|---|
| Waste Electrical and Electronic Equipment (WEEE) compliance | Yes |
Packaging content
| Specification | Value |
|---|---|
| Batteries included | No |
Supplier features
| Specification | Value |
|---|---|
| Product or Article Information Sheet available? | Yes |
Technical details
| Specification | Value |
|---|---|
| PSTI certified | Yes |
Other features
| Specification | Value |
|---|---|
| No Frost system | Yes |
| Defrost function | No |
| Multi-airflow system | Yes |
| Interior light | Yes |
| Installation compartment dimensions (WxDxH) | 1013 x 785 x 1840 mm |
| Control position | Internal |
| Anti-bacterial function | No |
| Built-in capability | No |
| Built-in freezer | Yes |
| Country of origin | China |
| Dairy compartment | No |
| Dimensions (WxDxH) | 913 x 735 x 1790 mm |
| Door opening angle | 120° |
| Gross weight | 148.7 kg |
| Humidity control | No |
| LED indicators | Temperature, Wi-Fi |
| Model year | 2024 |
| Overall height | 179 cm |
| Reversible doors | No |
| Total capacity | 628 L |
| Operating temperature (T-T) | 16 - 43 °C |
| Feet adjustment type | Front |
| Electronic control | Yes |
| Warranty period | 2 year(s) |
Logistics data
| Specification | Value |
|---|---|
| Commodity code | 8418102099 |
| Expanded Polystyrene (EPS) packaging weight | 1.48 kg |
| Metal packaging weight | 23 g |
| Paper packaging weight | 7.89 kg |
| Plastic packaging weight | 346 g |
| Wood packaging weight | 0 g |
| Harmonized System (HS) code | 84181020 |
| Master (outer) case gross weight | 148.7 kg |
| Master (outer) case height | 1891 mm |
| Master (outer) case length | 770 mm |
| Master (outer) case volume | 1415300 cm³ |
| Master (outer) case width | 972 mm |
| Products per master (outer) case | 1 pc(s) |
| Products per pallet | 1 pc(s) |
| Products per pallet layer | 1 pc(s) |
| Quantity per pack | 1 pc(s) |
| UK Trade Tariff code | 8418102099 |
