Samsung Galaxy SM-F766BLGGEUE smartphone

Galaxy SM-F766BLGGEUE smartphone

17.5 cm (6.9") Dual SIM 5G USB Type-C 12 GB 256 GB 4300 mAh Mint colour

Model SM-F766BLGGEUEEAN 8806097496168

101 specifications Checked today

Display17.5 cm (6.9")
Resolution2520 x 1080 pixels
Memory12 GB
Storage256 GB
Camera50 MP
Battery4300 mAh

See all specifications

Overview

Display: 17.5 cm (6.9")
Resolution: 2520 x 1080 pixels
Memory: 12 GB
Storage: 256 GB
Camera: 50 MP
Battery: 4300 mAh

Brand: Samsung
Category: Phone
Model: SM-F766BLGGEUE
Part number: SM-F766BLGGEUE
EAN / UPC: 8806097496168
Also known as: Samsung Galaxy SM-F766BLGGEUE smartphone 17.5 cm (6.9") Dual SIM 5G USB Type-C 12 GB 256 GB 4300 mAh Mint colour

Specifications

101 specifications in 17 groups

Display

Specification	Value
Display diagonal	17.5 cm (6.9")
Display resolution	2520 x 1080 pixels
Display technology marketing name	Dynamic AMOLED 2X
Panel type	AMOLED
Display glass type	Gorilla Glass
Gorilla Glass version	Gorilla Glass Victus 2
Display number of colours	16 million colours
Maximum refresh rate	120 Hz
Rounded display corners	Yes
Second display	Yes
Second display diagonal	10.4 cm (4.1")
Second display resolution	1048 x 948 pixels
Second display type	Super AMOLED

Processor

Specification	Value
Processor cores	10
Processor boost frequency	3.3 GHz

Storage

Specification	Value
RAM capacity	12 GB
Internal storage capacity	256 GB
User memory	223.8 GB

Camera

Specification	Value
Rear camera type	Dual camera
Rear camera resolution (numeric)	50 MP
Second rear camera resolution (numeric)	12 MP
Rear camera aperture number	1.8
Second rear camera aperture number	2.2
Optical zoom	2x
Digital zoom	10x
Front camera type	Single camera
Front camera resolution (numeric)	10 MP
Front camera aperture number	2.2
Rear camera flash	Yes
Video capture resolution (max)	3840 x 2160 pixels
Maximum frame rate	240 fps
Resolution at capture speed	3840x2160@60fps
Auto focus	Yes
Image stabilizer	Yes
Image stabilizer type	Optical Image Stabilization (OIS)

Network

Specification	Value
SIM card capability	Dual SIM
Mobile network generation	5G
SIM card type	NanoSIM + eSIM
3G standards	UMTS
4G standard	LTE-TDD & LTE-FDD
5G standard	Sub6 FDD, Sub6 SDL, Sub6 TDD
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Bluetooth	Yes
Bluetooth version	5.4
Frequency band	Tri-band
3G bands supported	850,900,1900,2100 MHz
4G bands supported	700,800,850,900,1500,1800,1900,2100,2300,2500,2600 MHz
5G bands supported	700,800,850,900,1500,1800,1900,2100,2300,2500,2600,3500,3700 MHz
MIMO	Yes
Modulation	4096-QAM
Wi-Fi Direct	Yes
Near Field Communication (NFC)	Yes

Ports & interfaces

Specification	Value
USB connector type	USB Type-C
USB version	3.2 Gen 1 (3.1 Gen 1)
Headphone connectivity	USB Type-C

Design

Specification	Value
Form factor	Flip
Product colour	Mint colour
Colour name	Mint
Housing material	Aluminium

Performance

Specification	Value
Fingerprint reader	Yes

Multimedia

Specification	Value
Speakers	stereo
Audio formats supported	3GA, AAC, AMR, APE, AWB, DFF, DSF, FLAC, IMY, M4A, Mid, MIDI, MP3, MXMF, OGA, OGG, OTA, RTTTL, RTX, WAV, XMF
Video formats supported	3G2, 3GP, AVI, FLV, M4V, MKV, MP4, WEBM

Software

Specification	Value
Platform	Android

Battery

Specification	Value
Battery capacity	4300 mAh
Removable battery	No
Battery endurance in cycles	2000

Power

Specification	Value
USB Type-C charging port	Yes
USB Power Delivery (USB PD)	Yes
USB Type-C required charging power (max)	25 W
USB Type-C required charging power (min)	10 W

Endurance

Specification	Value
Energy efficiency class	B
Energy efficiency scale	A to G
Battery endurance per cycle	2524 min
Repeated free fall reliability class	A
Repairability class	C
Repairability index	2.9
International Protection (IP) code	IP48

Sensors

Specification	Value
Accelerometer	Yes
Ambient light sensor	Yes
Proximity sensor	Yes
Gyroscope	Yes
Barometer	Yes
Geomagnetic sensor	Yes
Hall sensor	Yes

Weight & dimensions

Specification	Value
Weight	188 g
Width	75.2 mm
Depth	6.5 mm
Height	166.7 mm
Folded width	7.52 cm
Folded depth	1.37 cm
Folded height	8.55 cm

Packaging content

Specification	Value
AC adapter included	No
Cables included	USB Type-C
