Kyocera FS -C8520MFP/KL3 Laser A3

600 x 600 DPI 20 ppm

Model FS-C8520MFP/KL3Part no. 870B61102MZ3NL0EAN 632983932308

82 specifications

ProcessorPowerPC
Memory1536 MB
Weight80 kg
ColourBlack, Grey
Print technologyLaser
CopyingColour copying

See all specifications

Overview

Processor: PowerPC
Memory: 1536 MB
Weight: 80 kg
Colour: Black, Grey
Print technology: Laser
Copying: Colour copying

Brand: Kyocera
Category: Multifunction Printer
Model: FS-C8520MFP/KL3
Part number: 870B61102MZ3NL0
EAN / UPC: 632983932308, 4053162312265
Also known as: KYOCERA FS -C8520MFP/KL3 Laser A3 600 x 600 DPI 20 ppm

Specifications

82 specifications in 16 groups

Printing

Specification	Value
Print technology	Laser
Printing	Colour printing
Duplex printing	Yes
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (colour, normal quality, A4/US Letter)	20 ppm
Print speed (black, normal quality, A3)	10 ppm
Print speed (colour, normal quality, A3)	10 ppm
Warm-up time	55 s
Time to first page (black, normal)	11 s
Time to first page (colour, normal)	14 s

Copying

Specification	Value
Copying	Colour copying
Duplex copying	Yes
Time to first copy (black, normal)	11.7 s
Time to first copy (colour, normal)	13.6 s
Maximum number of copies	999 copies
Copier resize	25 - 400%

Scanning

Specification	Value
Scanning	Colour scanning
Duplex scanning	Yes
Optical scanning resolution	600 x 600 DPI
Scan to	E-mail, File, FTP, USB
Scan speed (colour)	40 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF

Fax

Specification	Value
Duplex faxing	Yes
Fax transmission speed	3 sec/page
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR, MR

Features

Specification	Value
Number of print cartridges	4
Printing colours	Black, Cyan, Magenta, Yellow
Page description languages	PCL 6, PostScript 3

Input & output capacity

Specification	Value
Total input capacity	600 sheets
Total output capacity	280 sheets
Multi-Purpose tray	Yes
Multi-Purpose tray input capacity	100 sheets
Maximum input capacity	1600 sheets

Paper handling

Specification	Value
Maximum ISO A-series paper size	A3
Maximum print size	297 x 432 mm
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Non-ISO print media sizes	Folio
Paper tray media weight	60 - 256 g/m²
Multi-Purpose Tray media weight	60 - 256 g/m²
Duplex media weight	60 - 220 g/m²

Ports & interfaces

Specification	Value
Standard interfaces	Ethernet, USB 2.0
Direct printing	Yes
USB port	Yes
USB 2.0 ports quantity	2

Network

Specification	Value
Wi-Fi	No
Ethernet LAN	Yes
Mobile printing technologies	Not supported

Performance

Specification	Value
Internal memory	1536 MB
Maximum internal memory	2048 MB
Card reader integrated	No
Built-in processor	Yes
Processor family	PowerPC
Processor model	464
Processor frequency	800 MHz
Sound pressure level (printing)	47 dB
Sound pressure level (copying)	47 dB
Sound power level (standby)	35 dB

Design

Specification	Value
Product colour	Black, Grey
Market positioning	Business
Built-in display	Yes
Display	LCD
Touchscreen	Yes
Control type	Touch

Power

Specification	Value
Power consumption (average operating)	557 W
Power consumption (standby)	121 W
Power consumption (off)	0.9 W
AC input frequency	50 - 60 Hz
AC input voltage	220 - 240 V

System requirements

Specification	Value
Windows operating systems supported	Yes
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Linux operating systems supported	Yes

Certificates

Specification	Value
Certification	TÜV/GS, CE

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

Weight & dimensions

Specification	Value
Width	590 mm
Depth	590 mm
Height	748 mm
Weight	80 kg
