Kyocera FS -6530MFP/KL3 Laser A3

600 x 600 DPI 30 ppm

Model FS-6530MFP/KL3Part no. 870B61102MW3NL0EAN 632983932131

96 specifications

ProcessorPowerPC
Memory1024 MB
Weight52.2 kg
ColourBlack, White
Print technologyLaser
CopyingMono copying

See all specifications

Overview

Processor: PowerPC
Memory: 1024 MB
Weight: 52.2 kg
Colour: Black, White
Print technology: Laser
Copying: Mono copying

Brand: Kyocera
Category: Multifunction Printer
Model: FS-6530MFP/KL3
Part number: 870B61102MW3NL0
EAN / UPC: 632983932131
Also known as: KYOCERA FS -6530MFP/KL3 Laser A3 600 x 600 DPI 30 ppm

Specifications

96 specifications in 16 groups

Printing

Specification	Value
Print technology	Laser
Printing	Mono printing
Duplex printing	Yes
Duplex printing mode	Auto
Maximum resolution	600 x 600 DPI
Print resolution black	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	30 ppm
Print speed (black, normal quality, A3)	15 ppm
Warm-up time	20 s
Time to first page (black, normal)	8 s

Copying

Specification	Value
Copying	Mono copying
Duplex copying	Yes
Maximum copy resolution	600 x 600 DPI
Time to first copy (black, normal)	7.8 s
Maximum number of copies	999 copies
Copier resize	25 - 400%
N-in-1 copy function (N=)	2, 4
PC free copying	Yes

Scanning

Specification	Value
Scanning	Colour scanning
Duplex scanning	Yes
Optical scanning resolution	600 x 600 DPI
Maximum scan area	A3 (297 x 420)
Scanner type	ADF scanner
Scan to	E-mail, File, FTP, Image, OCR, USB
Scan speed (black)	40 inch/min
Scan speed (colour)	20 inch/min
Image formats supported	JPG, TIF
Document formats supported	PDF
Greyscale levels	256
Scan drivers	TWAIN, WIA

Fax

Specification	Value
Faxing	No

Features

Specification	Value
Number of print cartridges	1
Printing colours	Black
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PCL XL, PostScript 3

Input & output capacity

Specification	Value
Total number of input trays	3
Total input capacity	650 sheets
Total output capacity	300 sheets
Multi-Purpose tray	Yes
Multi-Purpose tray input capacity	100 sheets
Paper input type	Cassette, Paper tray, Sheetfed
Auto document feeder (ADF)	Yes
Auto document feeder (ADF) input capacity	50 sheets
Auto document feeder (ADF) output capacity	50 sheets
Maximum number of input trays	5
Maximum input capacity	1650 sheets
Maximum output capacity	300 sheets

Paper handling

Specification	Value
Maximum ISO A-series paper size	A3
Maximum print size	297 x 432 mm
Paper tray media types	Plain paper
Multi-purpose tray media types	Envelopes
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Non-ISO print media sizes	Folio
Custom media length	148 - 432 mm
Custom media width	98 - 297 mm
Paper tray media weight	60 - 163 g/m²
Multi-Purpose Tray media weight	45 - 256 g/m²
Auto Document Feeder (ADF) media weight	50 - 120 g/m²
Duplex media weight	60 - 163 g/m²
Media thickness (min)	0.11 mm

Ports & interfaces

Specification	Value
Standard interfaces	Ethernet, USB 2.0
Direct printing	Yes
USB port	Yes

Network

Specification	Value
Wi-Fi	No
Ethernet LAN	Yes
Mobile printing technologies	Not supported

Performance

Specification	Value
Internal memory	1024 MB
Maximum internal memory	2048 MB
Card reader integrated	Yes
Compatible memory cards	CF
Built-in processor	Yes
Processor family	PowerPC
Processor model	464
Processor frequency	800 MHz
Sound pressure level (printing)	47.1 dB
Sound pressure level (copying)	47.1 dB
Sound power level (standby)	27.1 dB

Design

Specification	Value
Product colour	Black, White
Market positioning	Business
Built-in display	Yes
Display	LCD

Power

Specification	Value
Power consumption (average operating)	560 W
Power consumption (PowerSave)	0.9 W
Power consumption (standby)	114 W
AC input frequency	50 - 60 Hz
AC input voltage	220 - 240 V

System requirements

Specification	Value
Windows operating systems supported	Yes
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Linux operating systems supported	Yes
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows MultiPoint Server 2011, Windows SBS 2011 Essentials, Windows SBS 2011 Standard, Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012

Certificates

Specification	Value
Certification	TÜV/GS, CE

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

Weight & dimensions

Specification	Value
Width	590 mm
Depth	590 mm
Height	694 mm
Weight	52.2 kg
