ECOSYS 870B61102WF3NL2 multifunction printer Laser A4
1200 x 1200 DPI 60 ppm
Model 870B61102WF3NL2EAN 632983935736
181 specifications
- Display17.8 cm (7")
- ProcessorARM Cortex-A9
- Memory1024 MB
- Weight36.5 kg
- ColourBlack, White
- Print technologyLaser
Overview
- Display
- 17.8 cm (7")
- Processor
- ARM Cortex-A9
- Memory
- 1024 MB
- Weight
- 36.5 kg
- Colour
- Black, White
- Print technology
- Laser
- Brand
- Kyocera
- Category
- Multifunction Printer
- Model
- 870B61102WF3NL2
- Part number
- 870B61102WF3NL2
- EAN / UPC
- 632983935736
- Also known as
- KYOCERA ECOSYS 870B61102WF3NL2 multifunction printer Laser A4 1200 x 1200 DPI 60 ppm
Specifications
181 specifications in 21 groups
Printing
| Specification | Value |
|---|---|
| Print technology | Laser |
| Printing | Mono printing |
| Duplex printing | Yes |
| Duplex printing mode | Auto |
| Maximum resolution | 1200 x 1200 DPI |
| Print speed (black, normal quality, A4/US Letter) | 60 ppm |
| Print speed (black, draft quality, A4/US Letter) | 60 ppm |
| Duplex print speed (black, normal quality, A4/US Letter) | 43 ppm |
| Warm-up time | 25 s |
| Time to first page (black, normal) | 4.5 s |
| Print margin top (min) | 4 mm |
| Print margin bottom (min) | 4 mm |
| Print margin left (min) | 4 mm |
| Print margin right (min) | 4 mm |
| Print margins (top, bottom, right, left) | 4 mm |
| N-in-1 print function | Yes |
| Skip blank page function | Yes |
| N-up printing | 2, 4, 6, 8, 9, 16, 25 |
| Barcode printing | Yes |
| Watermark printing | Yes |
| Economical printing | Yes |
| Secure printing | Yes |
| Poster printing function | Yes |
| Secure PDF printing function | Yes |
Copying
| Specification | Value |
|---|---|
| Copying | Mono copying |
| Duplex copying | Yes |
| Duplex copying mode | Auto |
| Maximum copy resolution | 600 x 600 DPI |
| Copy speed (black, normal quality, A4) | 60 cpm |
| Copy speed (black, draft, A4) | 60 cpm |
| Copy speed (black, normal, US Letter) | 43 cpm |
| Time to first copy (black, normal) | 6 s |
| Maximum number of copies | 999 copies |
| Copier resize | 25 - 400% |
| N-in-1 copy function | Yes |
| N-in-1 copy function (N=) | 2, 4 |
| Copy programming function | Yes |
| Book copy function | Yes |
| ID-card copy function | Yes |
| Background adjustment function | Yes |
| Stamp function | Yes |
| Watermark copying | Yes |
Scanning
| Specification | Value |
|---|---|
| Scanning | Colour scanning |
| Duplex scanning | Yes |
| Duplex scanning mode | Auto |
| Optical scanning resolution | 600 x 600 DPI |
| Optical scanning resolution (black) | 600 x 600 ppi |
| Maximum scan area | 216 x 915 mm |
| Scanner type | Flatbed & ADF scanner |
| Scan technology | CIS/CCD |
| Scan to | E-mail, FTP, SMB, TWAIN, USB, WIA |
| Scan speed (black) | 60 ppm |
| Scan speed (colour) | 40 ppm |
| Duplex scan speed (colour) | 80 ppm |
| Duplex scan speed (black) | 120 ppm |
| Image formats supported | JPEG, MMR, TIFF |
| Document formats supported | PDF, XPS |
| Greyscale levels | 256 |
| Scan drivers | TWAIN, WIA |
Fax
| Specification | Value |
|---|---|
| Faxing | Mono faxing |
| Duplex faxing | Yes |
| Fax resolution (black) | 400 x 400 DPI |
| Fax transmission speed | 3 sec/page |
| Modem speed | 33.6 Kbit/s |
| Speed dialling | Yes |
| Fax coding methods | JPEG, MH, MMR, MR |
Features
| Specification | Value |
|---|---|
| Maximum duty cycle | 300000 pages per month |
| Recommended duty cycle | 5000 - 20000 pages per month |
| Duplex functions | Copy, Fax, Print, Scan |
| Digital sender | Yes |
| Ink tank system | No |
| Number of print cartridges | 1 |
| Printing colours | Black |
| Page description languages | Epson LQ, IBM ProPrinter XL24E, PCL 5c, PCL 6, PCL XL, XPS |
| Replacement cartridges | TK-3160 (toner, 12.500 afdrukken 5% dekking) TK-3170 (toner, 15.500 afdrukken 5% dekking) TK-3190 (toner, 25.000 afdrukken 5% dekking) TK-3200 (toner, 40.000 afdrukken 5% dekking) |
Input & output capacity
| Specification | Value |
|---|---|
| Total number of input trays | 1 |
| Total input capacity | 500 sheets |
| Total output capacity | 500 sheets |
| Paper tray 1 input capacity | 500 sheets |
| Multi-Purpose tray | Yes |
| Multi-Purpose tray input capacity | 100 sheets |
| Paper input type | Cassette |
| Auto document feeder (ADF) | Yes |
| Auto document feeder (ADF) input capacity | 100 sheets |
| Maximum number of input trays | 6 |
| Maximum input capacity | 2600 sheets |
| Maximum output capacity | 500 sheets |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A4 |
| Maximum print size | 216 x 356 mm |
| Paper tray media types | Plain paper |
| Multi-purpose tray media types | Envelopes, Labels, Legal, Letter, Plain paper, Recycled paper, Thick paper, Thin paper |
| ISO A-series sizes (A0...A9) | A4, A5, A6 |
| ISO B-series sizes (B0...B9) | B5, B6 |
| Non-ISO print media sizes | Folio, Legal, Letter |
| Custom media length | 148 - 356 mm |
| Custom media width | 105 - 216 mm |
| Paper tray media weight | 60 - 120 g/m² |
| Multi-Purpose Tray media weight | 60 - 220 g/m² |
| Auto Document Feeder (ADF) media weight | 50 - 120 g/m² |
| Duplex media weight | 60 - 120 g/m² |
| Scan media weight | 50 - 120 g/m² |
Ports & interfaces
| Specification | Value |
|---|---|
| Direct printing | Yes |
| USB port | Yes |
| USB 2.0 ports quantity | 2 |
| Optional connectivity | Ethernet, Wireless LAN |
Network
| Specification | Value |
|---|---|
| Wi-Fi | No |
| Ethernet LAN | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Bluetooth | No |
| Near Field Communication (NFC) | No |
| Security algorithms | IPSec, SNMPv3 |
| Email protocols | POP3, SMTP |
| Email over SSL | Yes |
| Mobile printing technologies | Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service |
Performance
| Specification | Value |
|---|---|
| Internal memory | 1024 MB |
| Maximum internal memory | 3072 MB |
| Memory slots | 1 |
| Card reader integrated | Yes |
| Compatible memory cards | SD, SDHC |
| Built-in processor | Yes |
| Processor family | ARM Cortex-A9 |
| Processor cores | 2 |
| Processor frequency | 1200 MHz |
| Coprocessor | Yes |
| Coprocessor frequency | 0.1 GHz |
| Sound pressure level (printing) | 55.5 dB |
| Sound pressure level (copying) | 55.5 dB |
| Sound power level (standby) | 23.5 dB |
Design
| Specification | Value |
|---|---|
| Product colour | Black, White |
| Market positioning | Business |
| Built-in display | Yes |
| Display | TFT |
| Display diagonal | 17.8 cm (7") |
| Touchscreen | Yes |
| Control type | Touch |
| Colour display | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (max) | 1415 W |
| Power consumption (average operating) | 773 W |
| Power consumption (PowerSave) | 23 W |
| Power consumption (printing) | 773 W |
| Power consumption (copying) | 798 W |
| Power consumption (ready) | 24 W |
| Power consumption (sleep) | 0.5 W |
| Power consumption (off) | 0.09 W |
| Energy Star Typical Electricity Consumption (TEC) | 3 kWh/week |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 220 - 240 V |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.9 Mavericks |
| Linux operating systems supported | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Non-operating altitude | 0.6 - 15000 m |
| Operating altitude | 0 - 3500 m |
| Operating relative humidity (H-H) | 15 - 80% |
| Operating temperature (T-T) | 10 - 32.5 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -20 - 40 °C |
Certificates
| Specification | Value |
|---|---|
| Certification | TÜV/GS, CE |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | Blue Angel, EPEAT Silver, ENERGY STAR |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 480 mm |
| Depth | 545 mm |
| Height | 740 mm |
| Weight | 36.5 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 700 mm |
| Package depth | 670 mm |
| Package height | 970 mm |
| Package weight | 49 kg |
Packaging content
| Specification | Value |
|---|---|
| Cartridge(s) included | Yes |
| Included cartridge capacity (black) | 11000 pages |
| Imaging unit included | Yes |
| Cables included | AC |
| Drivers included | Yes |
| Manual | Yes |
| Power cord included | Yes |
| Quick installation guide | Yes |
| Warranty card | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Other features
| Specification | Value |
|---|---|
| Documentation CD | Yes |
| Energy saving mode | Yes |
| Software CD | Yes |
| Finishing option | Standard |
