HP Managed MFP M680dnm
Model Managed MFP M680dnmPart no. L3U47A-MPS
86 specifications
- Display20.3 cm (8")
- Resolution800 x 600 pixels
- Memory2048 MB
- Storage320 GB
- Weight56.5 kg
- ColourBlack, Grey
Overview
- Display
- 20.3 cm (8")
- Resolution
- 800 x 600 pixels
- Memory
- 2048 MB
- Storage
- 320 GB
- Weight
- 56.5 kg
- Colour
- Black, Grey
- Brand
- HP
- Category
- Multifunction Printer
- Model
- Managed MFP M680dnm
- Part numbers
- L3U47A-MPS, L3U47A/EDF
- Also known as
- HP LaserJet Managed MFP M680dnm Laser A4 1200 x 1200 DPI 42 ppm
Specifications
86 specifications in 16 groups
Printing
| Specification | Value |
|---|---|
| Print technology | Laser |
| Printing | Colour printing |
| Duplex printing | Yes |
| Duplex printing mode | Auto |
| Maximum resolution | 1200 x 1200 DPI |
| Print speed (black, normal quality, A4/US Letter) | 42 ppm |
| Print speed (colour, normal quality, A4/US Letter) | 42 ppm |
| Duplex print speed (ISO/IEC 24734) mono | 38 ipm |
| Duplex print speed (ISO/IEC 24734) colour | 38 ipm |
| Time to first page (black, normal) | 10.5 s |
| Time to first page (colour, normal) | 10.5 s |
| Print margins (top, bottom, right, left) | 4.3 mm |
Copying
| Specification | Value |
|---|---|
| Copying | Colour copying |
| Maximum copy resolution | 600 x 600 DPI |
| Copy speed (black, normal quality, A4) | 42 cpm |
| Copy speed (colour, normal quality, A4) | 42 cpm |
| Maximum number of copies | 9999 copies |
Scanning
| Specification | Value |
|---|---|
| Scanning | Colour scanning |
| Optical scanning resolution | 600 x 600 DPI |
| Maximum scan area | 216 x 356 mm |
| Scanner type | Flatbed & ADF scanner |
| Scan technology | CCD |
| Input colour depth | 24 bit |
| Greyscale levels | 256 |
Fax
| Specification | Value |
|---|---|
| Faxing | No |
Features
| Specification | Value |
|---|---|
| Maximum duty cycle | 180000 pages per month |
| Recommended duty cycle | 3000 - 30000 pages per month |
| Digital sender | No |
| Number of print cartridges | 4 |
| Printing colours | Black, Cyan, Magenta, Yellow |
| Page description languages | PCL 5e, PCL 6, PostScript 3, URF |
Input & output capacity
| Specification | Value |
|---|---|
| Total number of input trays | 2 |
| Total input capacity | 500 sheets |
| Total output capacity | 500 sheets |
| Multi-Purpose tray | Yes |
| Multi-Purpose tray input capacity | 100 sheets |
| Paper input type | Paper tray |
| Maximum number of input trays | 5 |
| Maximum input capacity | 3100 sheets |
Paper handling
| Specification | Value |
|---|---|
| Maximum ISO A-series paper size | A4 |
| Paper tray media types | Bond paper, Card stock, Envelopes, Heavy paper, Labels, Plain paper, Pre-printed, Recycled paper, Rough paper, Transparencies |
| ISO A-series sizes (A0...A9) | A4, A5 |
| JIS B-series sizes (B0...B9) | B5, B6 |
| Envelopes sizes | B5, C5, C6, DL |
Ports & interfaces
| Specification | Value |
|---|---|
| Standard interfaces | Ethernet, USB 2.0 |
| Direct printing | No |
| USB port | Yes |
Network
| Specification | Value |
|---|---|
| Wi-Fi | No |
| Ethernet LAN | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Security algorithms | 256-bit AES |
| Mobile printing technologies | Apple AirPrint, HP ePrint, Mopria Print Service |
Performance
| Specification | Value |
|---|---|
| Internal memory | 2048 MB |
| Maximum internal memory | 3072 MB |
| Internal storage capacity | 320 GB |
| Card reader integrated | No |
| Built-in processor | Yes |
| Processor frequency | 800 MHz |
Design
| Specification | Value |
|---|---|
| Product colour | Black, Grey |
| Market positioning | Business |
| Built-in display | Yes |
| Display | LCD |
| Display diagonal | 20.3 cm (8") |
| Display resolution | 800 x 600 pixels |
| Touchscreen | Yes |
| Control type | Touch |
| Colour display | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (average operating) | 797 W |
| Power consumption (ready) | 83 W |
| Power consumption (sleep) | 7 W |
| Power consumption (off) | 0.07 W |
| Energy Star Typical Electricity Consumption (TEC) | 5.687 kWh/week |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 220 - 240 V |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 30 - 70% |
| Operating temperature (T-T) | 15 - 30 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | 0 - 35 °C |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 840 mm |
| Depth | 632 mm |
| Height | 585 mm |
| Weight | 56.5 kg |
