HP LaserJet M9040 A3

600 x 600 DPI 40 ppm

Model M9040Part no. CC394AEAN 883585404193

154 specifications

ProcessorMIPS
Memory384 MB
Storage80 GB
Weight143 kg
PrintingNo
CopyingMono copying

See all specifications

Overview

Processor: MIPS
Memory: 384 MB
Storage: 80 GB
Weight: 143 kg
Printing: No
Copying: Mono copying

Brand: HP
Category: Multifunction Printer
Model: M9040
Part number: CC394A
EAN / UPC: 883585404193, 088358544155, 883585404018, 883585404025 +16 more
Also known as: HP LaserJet M9040 A3 600 x 600 DPI 40 ppm

Specifications

154 specifications in 17 groups

Printing

Specification	Value
Printing	No
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (black, normal quality, A3)	28 ppm
Time to first page (black, normal)	9.5 s
Print speed (black, best quality, A4)	40 ppm
Print speed (black, best quality, letter)	Up to 40 ppm

Copying

Specification	Value
Copying	Mono copying
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	40 cpm
Maximum number of copies	999 copies
Bottom copy margin	4.2 (A4)
Copier settings	Scalability, Contrast, N-up, Auto/text/graphic, One pass duplex scanning, Change size, Change orientation, Crop, Move, Hide
Copy resolution (black graphics)	Up to 600 x 600 dpi
Copy speed (black, best, letter)	Up to 40 cpm
Left metric copy margin	4.2 (A4)
Maximum copy speed (black, A4)	40 cpm
Right metric copy margin	4.2 (A4)
Top metric copy margin	4.2 (A4)

Scanning

Specification	Value
Scanning	Colour scanning
Optical scanning resolution	600 x 600 DPI
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Input colour depth	30 bit
Greyscale levels	256
Minimum scan size	No minimum
Scan input modes	Front-panel scan, copy, fax (optional), e-mail

Fax

Specification	Value
Faxing	Mono faxing
Auto-redialing	Yes
Fax speed dialing (max numbers)	100
Fax forwarding	Yes
Distinctive ring	No
Fax broadcasting	100 locations
Fax delayed sending	No

Features

Specification	Value
Maximum duty cycle	300000 pages per month
Digital sender	No
Number of print cartridges	1
All-In-One-multitasking	Yes

Input & output capacity

Specification	Value
Total input capacity	3100 sheets
Maximum input capacity	3100 sheets
Maximum input capacity for envelopes	Up to 10 envelopes
Standard output capacity for envelopes	10 sheets

Paper handling

Specification	Value
Maximum ISO A-series paper size	A3
Maximum print size	303.4 x 468 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Photo paper, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A3, A4, A5
Non-ISO print media sizes	Executive
JIS B-series sizes (B0...B9)	B4, B5
Envelopes sizes	C5, DL
Auto Document Feeder (ADF) media weight	Multipurpose tray 1: 64 to 227 g/m2; Tray 2, 3 and 4: 64 to 199 g/m2
Media weight (tray 1)	64 to 227 g/m²
Envelope feeder	No
Maximum paper trays	4
Media handling	Sheetfed, multi-position stapling, sorter/collator/job separator; booklet making, folding, collating (with the multi-function finisher) multi-position stapler, stacking, collating (with the 3,000 sheet stapler/stacker), stacking/collating (with 3,000 sheet stacker), mailbox functionality (with 8 bin
Media type and capacity (tray 2)	sheets: 500
Paper handling standard/input	100-sheet multipurpose tray, two 500-sheet input trays, 2000-sheet input tray, 100-sheet automatic document feeder, automatic two-sided printing
Paper handling standard/output	Choose one finishing output solution: 3000-sheet stacker, 3000-sheet stapler/stacker, multifunction finisher, 2000-sheet 8-bin mailbox
Recommended media weight	64 - 227 g/m²
Paper handling	100-sheet multipurpose tray, two 500-sheet input trays, 2000-sheet input tray, 100-sheet automatic document feeder, automatic two-sided printing; choose one finishing output solution: 3000-sheet stacker, 3000-sheet stapler/stacker, multifunction finisher, 2000-sheet 8-bin mailbox

Network

Specification	Value
Supported network protocols (IPv4)	Via HP Jetdirect print servers: TCP/IP (IP Direct mode; may require software from the NOS vendor or third party vendor: LPD, FTP, IPP), IPX/SPX, DLC/LLC, AppleTalk, Auto-IP, Apple Rendezvous compatible, NDS, Bindery, NCP, Telnet, SLP, IGMP, BOOTP/DHCP, WINS, SNMP (v 1, 2c, 3), HTTP Compatible Networ

Performance

Specification	Value
Internal memory	384 MB
Internal storage capacity	80 GB
Built-in processor	Yes
Processor family	MIPS
Processor frequency	533 MHz
Minimum system requirements	Microsoft Windows 2000: 300 MHz processor, 64 MB RAM; Microsoft Windows XP Home and XP Professional: 233 MHz processor, 64 MB RAM; 180 MB of free hard disk space for Windows, CD-ROM drive or Internet connection

Design

Specification	Value
Market positioning	Business

Operational conditions

Specification	Value
Operating relative humidity (H-H)	20 - 80%
Operating temperature (T-T)	15 - 32.5 °C
Storage relative humidity (H-H)	15 - 90%
Storage temperature (T-T)	0 - 35 °C
Operating altitude (imperial)	Up to 10,000 ft
Recommended operating temperature range (T-T)	17.5 - 25 °C

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

Weight & dimensions

Specification	Value
Weight	143 kg

Packaging data

Specification	Value
Package weight	181.4 kg

Packaging content

Specification	Value
Bundled software	Print drivers and installation software on CD-ROM: remote hardcopy management, HP disk management utility, HP common installer, HP Internet installer, HP disk image utility, HP common drivers, HP resource manager for Macintosh, HP common installer for Macintosh, HP Internet installer for Macintosh,

Logistics data

Specification	Value
Pallet gross weight	27.4 kg
Products per pallet	1 pc(s)

Other features

Specification	Value
Standard input trays	4
Networking features	Fast Ethernet, Gigabit Ethernet, 802.11b wireless
Dimensions (WxDxH)	1092 x 838 x 1219 mm
All-in-one functions	Copy, Fax, Scan
Colour all-in-one functions	Scan, No
Compatible operating systems	Microsoft Windows 2000; XP Home, XP Professional; Windows Vista Ready; OS/2 v3.0 or higher; Mac OS X v10.2.8, v10.3, v10.4 or higher; Linux; AutoCAD
Downloadable software	Windows 2000, Windows XP Home, Windows XP Professional, Windows Server 2003, Macintosh OS 9, OS X
Functions	Colour scanning, colour digital sending (Scan to e-mail/Desktop/Network folder, optional: Send to LAN Fax, Send to printer, Send to application/workflow), black-and-white printing, black-and-white copying, optional black-and-white faxing. Standard functionality can be extended with workflow solution
Handset	No
Media types supported	Paper (bond, colour, letterhead, plain, preprinted, prepunched, recycled, rough), labels, cardstock, transparencies A3 (ISO), A4 (ISO), A4-R (ISO), A5 (ISO), B4 (JIS), B5 (JIS), Executive, legal, letter, tabloid
Minimum system requirements for Macintosh	Mac OS X v10.2.8, v10.3, v10.4 or higher with 128 MB RAM, CD-ROM, 160 MB of free hard disk space. For Mac OS v10.4 and higher, PowerPC and Intel Core Processor Macs are supported
Modem type	33.6 Kbps (with optional analog fax accessory)
Multi feed detection	Yes
Network ready	Yes
Power requirements	Input voltage 110 to 127 VAC (+/- 10%), 50/60 Hz (+/- 2 Hz); 220 to 240 VAC (+/- 10%), 50/60 Hz (+/- 2 Hz)
Printer management	Embedded Web server, HP Web Jetadmin
Safety	Argentina (TUV S Mark-Rs.92/98/Ds.1009/98), Australia (AS/NZ 3260), Canada (cULCAN/ CSA C22.2 No.60950-00), China (GB4943), Czech Republic (CSN-IEC 60950-IEC 60825-1), Estonia (EEI-EN60950-IEC 60825-1), EU (CE Mark-Low Voltage Directive 2006/95/EC), Germany (TUV- EN60950-IEC 60825-1), Hungary (MEEI-
Scan file formats	PDF, TIFF
Size (imperial)	109.2 cm (43")
Media size (tray 1)	A3 (ISO), A4 (ISO), A5 (ISO), B4 (JIS), B5 (JIS), letter, legal, executive, tabloid, JPostD, 98 x 191 to 312 x 470 mm
Package dimensions (WxDxH)	978 x 914 x 1448 mm
Electromagnetic compatibility	CISPR 22: 2005/EN 55022: 2006 Class A, EN 61000-3-2: 2000, EN 61000-3-3: 1995, EN 55024: 1998, FCC Title 47 CFR, Part 15 Class A/ICES-003, Issue 4/GB9254-1998, GB17625.1-2003, EMC Directive 2004/108/EC and the Low Voltage Directive 2006/95/EC, and carries the CE-Marking accordingly
I/O ports	1 Hi-Speed USB 2.0, 1 HP Jetdirect Gigabit Ethernet Embedded Print Server, 1 open EIO slot, 1 Jetlink connection for paper handling device, 1 host USB port (compatible with USB 2.0 specifications) for additional functionality, 1 Foreign Interface Harness (FIH)
Acoustic power emissions	7.5 B(A) (active), 5.6 B(A) (ready)
Acoustic power emissions (active, print, copy or scan)	74 dB
Acoustic power emissions (ready)	57 dB
Acoustic pressure emissions bystander (active, print, copy or scan)	58 dB(A)
Acoustic pressure emissions bystander (ready)	41 dB
Auto fax reduction supported	No
Automatic paper sensor	No
Control panel	3 light-emitting device (LED) indicator lights, 10-key numeric pad, graphical touchscreen display (193 x 72 mm)
Copier scaling (Auto Document Feeder)	25 to 200%
Copier smart software features	Scalability, Contrast, N-up, Auto/text/graphic, One pass duplex scanning, Change size, Change orientation, Crop, Move, Hide, Scan to e-mail
Custom media sizes	Multipurpose Tray 1: 98 x 191 to 312 x 470 mm; Trays 2, 3, 4 ADF and flatbed: 148 x 210 to 297 x 432 mm
Dimension note (imperial)	With 8-bin mailbox
Dimension note (metric)	With 8-bin mailbox
Driver updates	Current printer drivers and software for all supported operating systems are available at http:///support. Depending on the configuration of Windows-driven computers, the installation program for the printer software automatically checks the computer for Internet access to obtain the latest software
Duplex binding	Yes
Duplex print options	Automatic (standard)
Duplex supported media size	A3 (ISO), A4 (ISO), A4-R (ISO), A5 (ISO), B4 (JIS), B5 (JIS), B6 (JIS), executive (JIS); letter, letter-R, legal, excecutive, tabloid
Duty cycle letter size (maximum)	300000 pages per month
First page out (black&white, A4, ready)	9.5 s
First page out (black&white, letter, ready)	8 s
Junk barrier supported	No
Maximum dimensions (W x D x H)	1168.4 x 787.4 x 1193.8 mm
Maximum input capacity (tray 1)	100 sheets
Maximum scan area (ADF) (imperial)	279.4 x 431.8 mm (11 x 17")
Maximum scan area (imperial)	27.9 cm (11")
Media size (tray 2)	A3 (ISO), A4 (ISO), A4-R (ISO), A5 (ISO) (except tray 4), B4 (JIS), B5 (JIS), letter, letter-R, legal, executive, tabloid, 148 x 210 to 297 x 432 mm
Media sizes supported (imperial)	Letter, legal, executive, tabloid, JPostD, envelopes (No. 10, Monarch)
Media weight (tray 2)	64 to 199 g/m²
Media weight (tray 3)	64 to 199 g/m²
Memory technology	Memory Enhancement technology (MEt)
Package dimensions (W x D x H)	977.9 x 914.4 x 1447.8 mm (38.5 x 36 x 57")
Package weight (imperial)	181 kg (399 lbs)
Pallet dimensions (W x D x H)	1000 x 915 x 1447 mm
Pallet dimensions (W x D x H) (imperial)	1000.8 x 914.4 x 1447.8 mm (39.4 x 36 x 57")
Pallet weight (imperial)	27.2 kg (60 lbs)
Print margin bottom (A4)	2.9 mm
Print margin left (A4)	3.2 mm
Print margin right (A4)	3.7 mm
Print margin top (A4)	2.1 mm
Print quality (black, best quality)	1200
Print quality (black, normal quality)	600 DPI
Printer smart software features	Printing, copying, faxing, color digital sending, booklet making, folding, collating (with the multi-function finisher) multi-position stapler, stacking, collating (with the 3,000 sheet stapler/stacker), stacking/collating (with 3,000 sheet stacker), mailbox functionality (with 8 bin mailbox
Security management description	Management security: SNMP v 3, SSL/TLS (HTTPS), 802.1x authentication (with 620n and 625n EIO print servers); wireless network security: WPA (Wi-Fi Protected Access), WEP encryption (40-/64- and 128-bit), 802.1x authentication (EAP-PEAP, LEAP, EAP-TTLS, EAP-TLS, EAP-MD5) with RADIUS servers
Standard input capacity for envelopes	10 sheets
Standard media sizes	A3, A4, A5, B4 (JIS), B5 (JIS), B6 (JIS), C5, DL
SureSupply connection type	Direct and Network
SureSupply supported	Yes
Typefaces	80 internal TrueType fonts scalable in HP PCL and HP Postscript level 3 emulation; additional font solutions available
Typical electricity consumption (TEC) number	18.9 kWh/Week
UNSPSC-code	43212110
Weight (imperial)	Without finishing output solution 317 lb
Wireless option type	Yes, through wireless connectivities like Jetdirect 690n wireless print server J8007G
