133 MHz processor or higher, 64 MB RAM, 40 MB available hard disk space, USB or network port
Design
Specification
Value
Market positioning
Business
Display diagonal
43.2 cm (17")
Operational conditions
Specification
Value
Operating relative humidity (H-H)
10 - 80%
Operating temperature (T-T)
10 - 32.5 °C
Storage relative humidity (H-H)
10 - 80%
Storage temperature (T-T)
0 - 35 °C
Operating altitude (imperial)
10000 ft
Recommended operating temperature range (T-T)
10 - 32.5 °C
Sustainability
Specification
Value
Sustainability certificates
Blue Angel
Weight & dimensions
Specification
Value
Weight
99.4 kg
Packaging data
Specification
Value
Package weight
171 kg
Logistics data
Specification
Value
Pallet gross weight
171 kg
Products per pallet
1 pc(s)
Other features
Specification
Value
Standard input trays
3
Networking features
Via HP Jetdirect Embedded Network Print Server, HP Jetdirect internal print servers, HP Jetdirect external print servers, HP wireless print servers, HP connectivity cards
Dimensions (WxDxH)
914 x 483 x 1110 mm
All-in-one functions
Fax, Scan
Colour all-in-one functions
Scan, No
Compatible operating systems
Windows 2000, XP Home, XP Professional, XP Professional x64 Edition, Server 2003; Mac OS 10.2 and higher Microsoft Windows 2000, XP Home, XP Professional, XP Professional x64, Server 2003; Windows Vista supported soon (visit www.hp.com/go/windowsvista
Downloadable software
Printing system, PCL 6 driver only, PCL 5 driver only, PostScript driver only, WJA applet, UPD PCL 5, UPD PostScript, HP Easy Printer Care Software, PC fax driver
Mac OS 10.2 and higher, 128 MB RAM, 25 MB available hard disk space, network or USB port
Modem type
33.6 Kbps
Network ready
Yes
Power requirements
Input voltage 220 to 240 VAC (+/- 10%), 50/60 Hz (+/-2 Hz), recommended circuit capacity 8 amps
Printer management
HP Web Jetadmin, HP Easy Printer Care Software (neither is shipped in box)
Safety
Argentina (TUV S Mark-Rs.92/98/Ds.1009/98), Australia (AS/NZ 3260), Canada (cUL-CAN/CSA C22.2 No.60950-00), China (GB4943), EU (CE Mark-Low Voltage Directive 73/23/EEC), Germany (TÜV- EN60950-IEC 60825-1), Russia (GOST- R50377), USA (UL-UL 60950; FDA-21 C
Scan file formats
JPG, PDF, TIFF
Size (imperial)
102.1 cm (40.2")
Media size (tray 1)
A4, A5, B5 (JIS), executive (JIS), 16K, D postcard (JIS), letter, legal, executive, statement, 8.5 x 13 in, envelopes (DL, C5, B5, No. 10, Commercial), custom 76 x 127 to 216 x 356 mm
Package dimensions (WxDxH)
1200 x 1000 x 1440 mm
Electromagnetic compatibility
CISPR 22: 1993/EN 55022: 1994 Class B, EN 61000-3-2: 2000, EN 61000-3-3: 1995, EN 55024: 1998, FCC Title 47 CFR, Part 15 Class B/ICES-003, Issue 4/GB9254-1998, GB17625.1-2003, EMC Directive 89/336/EEC and the Low Voltage Directive 73/23/EEC, and carries t
I/O ports
1x USB 1x 10/100 Ethernet (RJ-45) 1x FIH 1x FAX 1x Open EIO slot 1x Jetlink
Acoustic power emissions
6.9 B(A) (printing at 45 ppm)
Acoustic power emissions (active, print, copy or scan)
72 dB
Acoustic power emissions (ready)
Inaudible
Acoustic pressure emissions bystander (active, print, copy or scan)
56 dB(A) 54 dB(A)
Acoustic pressure emissions bystander (ready)
Inaudible
Auto document feeder: supported media types and capacity
Up to A4 capable copying on the glass, up to legal size through the automatic document feeder, 50 page ADF, duplexing (optional on base unit), reduce/enlarge, contrast adjustments, mixed original support
Custom media sizes
Tray 1, optional 3-bin mailbox or stacker part of stapler/stacker: 76 x 127 to 216 x 356 mm; Tray 2 and optional Tray 3, 4, 5: 148 x 210 to 216 x 356 mm; custom sizes not supported on optional automatic two-sided printing unit, envelope feeder, stapler
Driver updates
The latest software and drivers are available for the HP LaserJet M4345 MFP from the HP Web site at http://www.hp.com/support/ljm4345mfp
Duplex binding
Yes
Duplex print options
Automatic (standard)
Duplex supported media size
A4, A5, B5 (JIS), executive (JIS), 16K
First page out (black&white, A4, ready)
10 s
First page out (black&white, letter, ready)
10 s
Image scaling/enlargement range
25 - 400%
Junk barrier supported
Yes
Maximum dimensions (W x D x H)
925 x 566 x 549 mm
Maximum input capacity (tray 1)
100 sheets
Maximum scan area (ADF) (imperial)
215.9 x 355.6 mm (8.5 x 14")
Maximum scan area (imperial)
22.6 cm (8.9")
Media size (tray 2)
A4, A5, B5 (JIS), executive (JIS), 16K, letter, legal, executive, 8.5 x 13 in, custom 148 x 210 to 216 x 356 mm
Media sizes supported (imperial)
Letter, legal, executive, statement, 8.5 x 13 in, envelopes (No. 10, commercial)
Media weight (tray 2)
60 to 120 g/m²
Media weight (tray 3)
60 to 120 g/m²
Media weights by paper path
Tray 1, optional stacker: 60 to 200 g/m2; Tray 2, optional 500-sheet input tray, optional automatic two-sided printing unit, optional stapler: 60 to 120 g/m2; optional envelope feeder: 75 to 105 g/m2
Memory technology
Memory Enhancement technology (MEt)
Memory upgrade
0.512 GB
Minimum scan area
0 x 0 mm (0 x 0")
Minimum scan area (Auto Document Feeder)
147.3 x 210.8 mm (5.8 x 8.3")
Package dimensions (W x D x H)
1200.2 x 1000.3 x 1440.2 mm (47.2 x 39.4 x 56.7")
Package weight (imperial)
170.6 kg (376.2 lbs)
Pallet dimensions (W x D x H)
1200 x 1000 x 1440 mm
Pallet dimensions (W x D x H) (imperial)
1201.4 x 1000.8 x 1440.2 mm (47.3 x 39.4 x 56.7")
Pallet weight (imperial)
170.6 kg (376.2 lbs)
Print margin bottom (A4)
4.2 mm
Print margin left (A4)
4.2 mm
Print margin right (A4)
4.2 mm
Print margin top (A4)
4.2 mm
Print quality (black, best quality)
1200 x 1200 DPI
Print quality (black, draft quality)
600 DPI
Print quality (black, normal quality)
1200 DPI
Printer smart software features
Up to legal-size capable printing, full LaserJet printing functionality, HP ProRes 1200 at full engine speed, duplexing available, Instant-on Technology, HP Smart printing technology
Security management description
SNMPv3, SSL/TLS (HTTPS), 802.1x authentication, Web Jetadmin
Service & support
HP Web sites, HP Customer Support Centre, HP Care Packs, HP service agreement
Standard input capacity for envelopes
10 sheets
Standard media sizes
Letter, legal, executive, statement, 8.5" x 13", envelopes (No.10, Comm.)
Standard output capacity for transparencies
700 sheets
SureSupply connection type
Direct and Network
SureSupply supported
Yes
Typefaces
28 built in
UNSPSC-code
43212110
Upgrade type
Add additional paper handling capability with a 75-sheet envelope feeder, DSS software
Weight (imperial)
153.03 lb
Wireless option type
Optional, enabled with purchase of a hardware accessory
