HP LaserJet M1522n Laser A4

600 x 600 DPI 23 ppm

Model M1522nPart no. CC372A#ABHEAN 883585238576

173 specifications

ProcessorNXP ColdFire V5e
Memory64 MB
Weight11 kg
ColourBlack, Grey
Print technologyLaser
CopyingMono copying

See all specifications

Overview

Processor: NXP ColdFire V5e
Memory: 64 MB
Weight: 11 kg
Colour: Black, Grey
Print technology: Laser
Copying: Mono copying

Brand: HP
Category: Multifunction Printer
Model: M1522n
Part numbers: CC372A#ABH, CC372A
EAN / UPC: 883585238576, 883585238385, 883585238392, 883585238408 +16 more
Also known as: HP LaserJet M1522n Laser A4 600 x 600 DPI 23 ppm

Specifications

173 specifications in 20 groups

Printing

Specification	Value
Print technology	Laser
Printing	No
Duplex printing	No
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	23 ppm
Warm-up time	48 s
Time to first page (black, normal)	9.5 s
Print speed (black, best quality, A4)	23 ppm
Print speed (black, best quality, letter)	Up to 24 ppm

Copying

Specification	Value
Copying	Mono copying
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	23 cpm
Maximum number of copies	99 copies
Time to first copy (letter)	9.5 sec (Flatbed copies)
Bottom copy margin	4 mm
Copier settings	Contrast (lighter/darker), resolution copy quality (text, mixed, film photo and picture), draft quality (on/off), multipage (on/off), reduce/enlarge 25 to 400%, copy collation, number of copies, paper size, paper type, restore default.
Copy resolution (black graphics)	Up to 600 x 600 dpi
Copy speed (black, best, letter)	Up to 24 cpm (single sheet on flatbed, multiple copies, ADF copy speed is up to 15.5 cpm)
Left metric copy margin	4 mm
Right metric copy margin	4 mm
Top metric copy margin	4 mm

Scanning

Specification	Value
Scanning	Colour scanning
Optical scanning resolution	1200 x 1200 DPI
Maximum scan area	216 x 297 mm
Scanner type	Flatbed scanner
Image formats supported	BMP, GIF, PNG, TIF
Input colour depth	24 bit
Greyscale levels	256
TWAIN version	Version 1.9
Minimum scan size	No minimum
Scan input modes	Front control panel scan, Copy buttons, scanning via HP LaserJet Scan (Windows), HP Director (Macintosh) or TWAIN-compliant or WIA-compliant software.
Scan speed (black, normal quality)	Up to 3 ppm
Scan speed (colour, normal quality)	Up to 3 ppm
Scanner features	Instant on scanner, Device front control panel with Scan-to-folder and e-mail options for direct walk-up scan capability (pre-configuration of walk-up capability required via software provided), software, 50-page Automatic Document Feeder (ADF)

Fax

Specification	Value
Faxing	No

Features

Specification	Value
Digital sender	No
Number of print cartridges	1
All-In-One-multitasking	Yes

Input & output capacity

Specification	Value
Total input capacity	260 sheets
Total output capacity	125 sheets
Maximum output capacity	125 sheets
Maximum input capacity for envelopes	10
Standard output capacity for envelopes	10 sheets

Paper handling

Specification	Value
Maximum ISO A-series paper size	A4
Maximum print size	206 x 344 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Auto Document Feeder (ADF) media weight	60 - 90 g/m²
Media weight (tray 1)	60 to 163 g/m²
Envelope feeder	No
Maximum paper trays	2
Media handling	Sheetfed
Media type and capacity (tray 2)	sheets: 10, transparencies: 10, envelopes: 10
Paper handling standard/input	250-sheet media input tray, 10-sheet priority input tray, 50-sheet Automatic Document Feeder (ADF)
Paper handling standard/output	125-sheet face-down output bin
Recommended media weight	Tray 1, Priority input tray, Output bin: 60 - 163; Au-matic Document Feeder (ADF): 60 - 90
Paper handling	250-sheet media input tray, 10-sheet priority input tray, 50-sheet Automatic Document Feeder, 125-sheet face-down output bin

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	1

Network

Specification	Value
Wi-Fi	No
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10,100 Mbit/s
Supported network protocols (IPv4)	TCP/IP: IPv4, IPv6, IP Direct Mode, LPD, SLP, Bonjour, BOOTP/ DHCP/ AutoIP, WINS, SNMP v 1, and HTTP

Performance

Specification	Value
Internal memory	64 MB
Built-in processor	Yes
Processor family	NXP ColdFire V5e
Processor frequency	450 MHz
Mac compatibility	Yes
Minimum system requirements	Microsoft Windows 2000, Server 2003: any Pentium II processor or higher, 64 MB RAM, 250 MB hard disk space, SVGA 800 x 600 with 16-bit colour display, Internet Explorer 5.5 or higher (full install), CD-ROM drive, USB port (print driver, scan driver only); Microsoft Windows XP-32 Home, XP-32 Professi

Design

Specification	Value
Product colour	Black, Grey
Market positioning	Home & office
Built-in display	Yes
Display	LCD

Power

Specification	Value
Power consumption (average operating)	410 W

System requirements

Specification	Value
Windows operating systems supported	Windows 2000, Windows Vista, Windows XP
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Linux operating systems supported	Yes
Server operating systems supported	Windows Server 2003
Minimum RAM	64 MB
Minimum storage drive space	250 MB

Operational conditions

Specification	Value
Operating relative humidity (H-H)	10 - 80%
Operating temperature (T-T)	15 - 32.5 °C
Storage relative humidity (H-H)	0 - 95%
Storage temperature (T-T)	-20 - 40 °C
Operating altitude (imperial)	Up to 10,000 ft
Recommended operating temperature range (T-T)	15 - 32.5 °C

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

Weight & dimensions

Specification	Value
Width	496 mm
Depth	406 mm
Height	402 mm
Weight	11 kg

Packaging data

Specification	Value
Package width	600 mm
Package depth	500 mm
Package height	505 mm
Package weight	15.6 kg

Packaging content

Specification	Value
Bundled software	HP Toolbox FX, HP LaserJet Scan, TWAIN 1.9 or WIA scanner drivers, Readiris PRO text recognition software (not installed with other software, separate installation required), printer drivers (HP PCL 6, HP PCL 5e, HP Postscript Level 3 emulation), installer/uninstaller, HP Director (Macintosh)

Logistics data

Specification	Value
Pallet gross weight	272.3 kg
Products per pallet	16 pc(s)

Other features

Specification	Value
Standard input trays	2
Networking features	Via built-in 10/100Base-T TCP/IP networking Built-in 10/100Base-T TCP/IP networking
Dimensions (WxDxH)	496 x 406 x 402 mm
All-in-one functions	Copy, Scan
Colour all-in-one functions	Scan, No
Compatible operating systems	Microsoft Windows 2000, Server 2003; Certified for Windows Vista; Microsoft Windows XP Home, XP Media Center, XP Professional, XP Professional x64; XP Tablet PC; Mac OS X v10.3 or higher; Novell NetWare 3.2, 4.2, 5.x, 6; HP-UX 10.20, 11.x; RED HAT Linux 6.x or higher; SUSE Linux 6.x or higher; Solar
Downloadable software	Installer, print drivers, HP Scan software, HP Toolbox FX for management and support, Readiris PRO text recognition software, HP Software Update, Web Jetadmin, Enterprise Installer
Functions	Print, copy, scan
Maximum scan area (ADF)	216 x 381 mm
Media types supported	Paper (bond, colour, heavy, letterhead, light, plain, preprinted, prepunched, recycled, rough), envelopes, transparencies, labels, cardstock
Minimum scan area (ADF)	127 x 127 mm
Minimum system requirements for Macintosh	Mac OS X v10.3 or higher; G3 (500 MHz), G4, G5, or Intel processors, 512 MB RAM, 100 MB disk space, USB or network port, CD-ROM drive
Multi feed detection	Yes
Network ready	Yes
Power requirements	Input voltage 110 to 127 VAC (+/- 10%), 50/60 Hz (+/- 2 Hz), 4.5 A; 220 to 240 VAC (+/- 10%), 50/60 Hz (+/- 2 Hz), 2.6 A
Printer management	HP Toolbox FX, HP Web Jetadmin, embedded Web server (Mac only)
Safety	IEC 60950-1: 2001/EN 60950-1: 2001+A11; IEC 60825-1: 1993+A1: 1997+A2: 2001/EN 60825-1: 1994+A1: 2002+A2: 2001 (Class 1 Laser/LED Product); GB4943-1995
Scan file formats	BMP, GIF, PDF, PNG
Size (imperial)	49.5 cm (19.5")
Media size (tray 1)	A4, A5, B5, C5, C6, DL, 16K, 76 x 127 to 216 x 356 mm
Package dimensions (WxDxH)	600 x 500 x 505 mm
Electromagnetic compatibility	CISPR 22: 2005 /EN 55022: 2006-Class B; EN 61000-3-2: 2000+A2; EN 61000-3-3: 1995+A1; EN 55024: 1998+A1+A2; FCC Title 47 CFR, Part 15 Class B 2/ICES-003, Issue 3; GB9254-1998
I/O ports	1 Hi-Speed USB (compatible with USB 2.0 specifications) port, 1 Ethernet port
Acoustic power emissions	6.5 B(A) (continuous print at 23 ppm), 6.8 B(A) (ADF copy/print at 23 ppm), inaudible (ready)
Acoustic power emissions (active, print, copy or scan)	68 dB
Acoustic power emissions (ready)	Inaudible
Acoustic pressure emissions bystander (active, print, copy or scan)	53.7 dB(A) 52 dB(A)
Acoustic pressure emissions bystander (ready)	Inaudible
Auto document feeder: supported media types and capacity	sheets: 50
Automatic paper sensor	No
Control panel	2-line LCD text display, alphanumeric buttons, navigational buttons plus 2 LEDs (setup, up, ok, down, back, cancel), copy buttons (start copy, reduce/enlarge, lighter/darker, quality, number of copies), 2 scan buttons (start scan, scan to).
Copier scaling (Auto Document Feeder)	25 to 400%
Copier smart software features	1 to 99 multiple copies, Collation, Reduce/Enlarge from 25 to 400% (with page size presets), Fit to page, 2 or 4 pages to 1 page, Contrast (lighter/darker), Resolution (copy quality), Draft mode
Custom media sizes	Priority input tray and Tray 1: 76 x 127 to 216 x 356 mm; Automatic Document Feeder (ADF): 127 x 127 to 216 x 381 mm
Driver updates	Latest drivers available from http://
Duplex binding	No
Duplex print options	Manual (driver support provided)
First page out (black&white, A4, ready)	9.5 s
First page out (black&white, letter, ready)	9.5 s
First page out (black&white, letter, sleep)	9.5 s
Maximum input capacity (tray 1)	250 sheets
Maximum scan area (ADF) (imperial)	215.9 x 355.6 mm (8.5 x 14")
Maximum scan area (imperial)	21.6 cm (8.5")
Media size (tray 2)	A4, A5, B5, C5, C6, DL, 16K, 76 x 127 to 216 x 356 mm
Media sizes supported (imperial)	Priority input tray and Tray 1: letter, legal, envelopes (No. 5 (1/2 Baronial) through No. 11), index cards, postcards; automatic document feeder (ADF): letter, legal
Media weight (tray 2)	60 to 163 g/m²
Media weights by paper path	Tray 1, Priority input tray, Output bin: 60 to 163 g/m²; automatic document feeder (ADF): 60 to 90 g/m²
Memory technology	Memory Enhancement technology (MEt)
Memory upgrade	No
Minimum scan area	No minimum
Minimum scan area (Auto Document Feeder)	127 x 127 mm (5 x 5")
Package dimensions (W x D x H)	600.2 x 500.1 x 505.2 mm (23.6 x 19.7 x 19.9")
Package weight (imperial)	15.6 kg (34.3 lbs)
Pallet dimensions (W x D x H)	1200 x 1000 x 2160 mm
Pallet dimensions (W x D x H) (imperial)	1219.2 x 1016 x 2160 mm (48 x 40 x 85")
Pallet weight (imperial)	271.7 kg (599 lbs)
Print margin bottom (A4)	4 mm
Print margin left (A4)	4 mm
Print margin right (A4)	4 mm
Print margin top (A4)	4 mm
Print quality (black, best quality)	600 x 600 DPI
Printer smart software features	Manual duplex, booklet printing, N-up printing, Collation, Watermarks, Install printer driver only, Economode for toner savings, accepts a variety of paper sizes and types.
Product dimensions optional (metric)	496 x 406 x 402 mm
Security management description	SNMP v1 (community name); control panel, embedded Web server and HP Toolbox (password-protected)
Standard input capacity for envelopes	10 sheets
Standard media sizes	Priority input tray and Tray 1: A4, A5, B5 (JIS), C5, DL, 16K, European postcard; Automatic Document Feeder (ADF): A4, A5
Standard output capacity for transparencies	10 sheets
SureSupply connection type	Direct and Network
SureSupply supported	Yes
Typefaces	45 scalable TrueType, 35 Postscript
Typical electricity consumption (TEC) number	2.283 kWh/Week
UNSPSC-code	43212110
Upgrade type	Device firmware upgradability via USB direct connection or 10/100 wired Ethernet network connectivity.
Weight (imperial)	24.2 lb
