LaserJet CM1015 Laser

600 x 600 DPI 8 ppm

Model CM1015Part no. CB394AEAN 882780579699

128 specifications

ProcessorNXP ColdFire V5e
Memory96 MB
Weight22.2 kg
ColourWhite
Print technologyLaser
CopyingNo

See all specifications

Overview

Processor: NXP ColdFire V5e
Memory: 96 MB
Weight: 22.2 kg
Colour: White
Print technology: Laser
Copying: No

Brand: HP
Category: Multifunction Printer
Model: CM1015
Part number: CB394A
EAN / UPC: 882780579699, 882780579507, 882780579514, 882780579521 +16 more
Also known as: HP LaserJet CM1015 Laser 600 x 600 DPI 8 ppm

Specifications

128 specifications in 18 groups

Printing

Specification	Value
Print technology	Laser
Printing	Colour printing
Duplex printing	No
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	8 ppm
Print speed (colour, normal quality, A4/US Letter)	8 ppm
Print speed (black, draft quality, A4/US Letter)	8 ppm
Print speed (colour, draft quality, A4/US Letter)	8 ppm
Time to first page (black, normal)	20 s
Time to first page (colour, normal)	20 s
Print speed (black, best quality, A4)	8 ppm
Print speed (colour, best quality, A4)	8 ppm

Copying

Specification	Value
Copying	No
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	8 cpm
Maximum number of copies	99 copies
Bottom copy margin	4 mm
Copy resolution (black graphics)	600 x 600 dpi
Copy resolution (colour text and graphics)	600 DPI
Left metric copy margin	4 mm
Maximum copy speed (black, A4)	8 cpm
Maximum copy speed (colour, A4)	8 cpm
Right metric copy margin	4 mm
Top metric copy margin	4 mm

Scanning

Specification	Value
Scanning	Colour scanning
Optical scanning resolution	1200 x 1200 DPI
Maximum scan area	216 x 356 mm
Scanner type	Flatbed scanner
Input colour depth	24 bit
Greyscale levels	256
TWAIN version	Version 1.9
Scan input modes	Walk-up initiated scanning via front control panel (preconfiguration via software required); remote initiated scanning via HP Director, TWAIN-compliant or WIA-compliant software, HP Image Zone software
Scanner features	Intuitive device front control panel with direct scan-to folder and e-mail capability (pre-configuration of walk-up capability required via software provided); Software

Fax

Specification	Value
Faxing	No

Features

Specification	Value
Maximum duty cycle	35000 pages per month
Digital sender	No

Input & output capacity

Specification	Value
Total input capacity	250 sheets
Total output capacity	125 sheets
Maximum output capacity	125 sheets
Standard output capacity for envelopes	10 sheets

Paper handling

Specification	Value
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Letterhead, Plain paper, Pre-printed, Recycled paper, Rough paper, Transparencies
Media weight (tray 1)	60 to 176 g/m² (up to 220 g/m² HP Photo Laser Paper)
Maximum paper trays	3
Media type and capacity (tray 2)	sheets: 250, transparencies: 50, envelopes: 10
Paper handling optional/input	250-sheet media input tray
Paper handling standard/input	1-sheet multipurpose tray, 250-sheet input tray
Paper handling standard/output	125-sheet output tray
Recommended media weight	Tray 1, 2: 60 - 176 (up - 220 HP Pho- Laser Paper); optional 250-sheet input tray: 60 - 163
Paper handling	1-sheet multipurpose tray, 250-sheet input tray, optional 250-sheet input tray

Ports & interfaces

Specification	Value
Standard interfaces	USB 2.0
USB port	Yes

Network

Specification	Value
Wi-Fi	No
Ethernet LAN	No

Performance

Specification	Value
Internal memory	96 MB
Compatible memory cards	SmartMedia
Built-in processor	Yes
Processor family	NXP ColdFire V5e
Processor frequency	300 MHz
Minimum system requirements	Windows Server 2003: any Pentium II processor or greater, 64 MB RAM, 50 MB available hard disk space, SVGA 800 x 600 monitor with 16-bit colour (print driver, scan driver only); Windows 2000, XP Home, XP Professional: any Pentium II processor (Pentium III

Design

Specification	Value
Product colour	White
Market positioning	Business

System requirements

Specification	Value
Windows operating systems supported	Windows 2000, Windows Vista, Windows XP Home, Windows XP Professional
Mac operating systems supported	Mac OS X 10.3 Panther
Linux operating systems supported	Yes
Server operating systems supported	Windows Server 2003

Operational conditions

Specification	Value
Operating relative humidity (H-H)	15 - 80%
Operating temperature (T-T)	15 - 32.5 °C
Storage relative humidity (H-H)	0 - 85%
Storage temperature (T-T)	-20 - 40 °C
Recommended operating temperature range (T-T)	20 - 27 °C

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

Weight & dimensions

Specification	Value
Width	437 mm
Depth	508 mm
Height	525 mm
Weight	22.2 kg

Packaging data

Specification	Value
Package width	600 mm
Package depth	500 mm
Package height	585 mm
Package weight	25.3 kg

Packaging content

Specification	Value
Bundled software	HP PCL 6 and postscript level 3 emulation print drivers, HP Toolbox FX, HP Device Configuration Utility (Macintosh), TWAIN 1.9 or WIA scanner drivers, installer/uninstaller, HP Solution Center, HP Director (Macintosh), HP Photosmart Premier, HP Photosmart

Other features

Specification	Value
Standard input trays	2
Dimensions (WxDxH)	525 x 437 x 508 mm
All-in-one functions	Scan
Colour all-in-one functions	Print, Scan
Compatible operating systems	Linux, Mac OS X, UNIX, Windows 2000, Windows Server 2003, Windows XP Home Edition, Windows XP Professional
Downloadable software	Installer, print drivers, scan drivers, HP scan software, HP Photosmart Premier Software, HP Document Viewer Software, HP ToolboxFX for management and support, HP software update
Functions	Colour printing, colour copying, colour scanning, black-and-white printing, black-and-white copying, black-and-white scanning
Maximum internal memory	224 GB
Media types supported	Paper (plain, letterhead, prepunched, bond, colour, rough, preprinted, recycled), HP LaserJet Tough Paper, HP LaserJet Paper, HP Colour Laser Paper, HP Printing Paper, HP Advanced Paper, HP Recycled Paper, HP Copy Paper, HP Office Paper, HP Photo Laser Pa
Minimum system requirements for Macintosh	Mac OS X v10.3.x; G3, G4 or G5 processor; 80 MB RAM; 30 MB available hard disk space; CD-ROM drive; USB Port
Network ready	No
Power requirements	Input voltage: 220 to 240 VAC (+/- 10%), 50 Hz (+/- 3 Hz)
Printer management	HP Toolbox FX, HP Web Jetadmin, HP Embedded Web Server (Mac only)
Safety	IEC 60950-1: 2001/EN 60950-1: 2001+A11; IEC 60825-1: 1993+A1:1997+A2: 2001/EN 60825-1: 1994+A1: 2002+A2: 2001 (Class 1 Laser/LED Product); GB4943-1995
Scan file formats	BMP, FPX, JPG, PCX, PDF, PNG, RTF, TXT
Media size (tray 1)	A4, A5, B5 (ISO, JIS), 76 x 127 to 216 x 356 mm
Package dimensions (WxDxH)	600 x 500 x 585 mm
Electromagnetic compatibility	CISPR 22: 1993 +A1+A2/EN 55022:1994+A1+A2 - Class B; EN 61000-3-2: 1995/A14:2000; EN 61000-3-3: 1995+A1; EN 55024: 1998+A1+A2; FCC Title 47 CFR, Part 15 Class B 2/ICES-003, Issue 3; GB9254-1998
I/O ports	1 Hi-Speed USB (compatible with USB 2.0 specifications)
Acoustic power emissions	6.1 B(A)
Acoustic pressure emissions	47 dB
Colour printing technology	HP ImageREt 2400
Control panel	Intuitive control panel with 2-line, 16-character backlit display, device/supplies status view, copy and scan controls, enter, menu and cancel controls
Copier smart software features	Intuitive control panel for easy replication and optimisation of multiple document types; Letter/A4 Flatbed glass with CCD (Charge Coupled Device) scanner for high-quality copying; One-touch colour or black-and-white single copy, or up to 99 copies; Copy
Custom media sizes	Tray 1, 2, 3: 76 x 127 to 216 x 356 mm
Driver updates	Latest drivers available from http://www.hp.com
Duplex print options	Manual (driver support provided)
Media size (tray 2)	A4, A5, B5 (ISO, JIS), 76 x 127 to 216 x 356 mm
Media weight (tray 2)	60 to 176 g/m² (up to 220 g/m² HP Photo Laser Paper)
Media weight (tray 3)	60 to 163 g/m²
Memory technology	Proprietary grafit compression
Memory upgrade	0.224 GB
Print margin bottom (A4)	4 mm
Print margin left (A4)	4 mm
Print margin right (A4)	4 mm
Print margin top (A4)	4 mm
Print quality (black, best quality)	600 x 600 DPI
Print quality (black, draft quality)	600 DPI
Print quality (black, normal quality)	600 DPI
Print quality (colour, best quality)	600 DPI
Printer smart software features	Manual duplex and booklet printing, N-up printing, Collation, Watermarks, install print driver only, accepts a variety of paper sizes and types
Service & support	HP Websites, HP Customer Support Centre, HP Care Pack
Standard media sizes	A4, A5, B5, Executive, Legal, Letter
Standard output capacity for transparencies	50 sheets
Technical features	Fast, affordable desktop MFP Microbusinesses and small to medium businesses No fax Recommended monthly volume: up to 1,500 pages HP PCL 6/5c, (PS 3 emulation) Print/copy at up to 8 ppm black and colour
Typefaces	PCL 6 and Postscript: 80 internal scalable TrueType fonts
UNSPSC-code	43212110
Upgrade type	Device firmware upgradability via USB direct connection or 10/100 wired Ethernet network connectivity (CLJ CM1017); RAM upgradable from 96 MB of built-in memory up to 226 MB total via a single 100-pin DIMM slot accepting either 64 MB or 128 MB RAM memory
