Contrast (lighter/darker), resolution copy quality (draft, text, mixed, film photo and picture), reduce/enlarge 25 to 400%, copy collation, number of copies, paper size
Copy resolution (black graphics)
Up to 600 x 600 dpi
Copy speed (black, best, letter)
Up to 19 cpm (single sheet on flatbed, multiple copies, ADF copy speed is up to 13 cpm)
Left metric copy margin
4 mm
Maximum copy speed (black, A4)
18 cpm
Right metric copy margin
4 mm
Top metric copy margin
4 mm
Scanning
Specification
Value
Scanning
Colour scanning
Optical scanning resolution
600 x 600 DPI
Maximum scan area
216 x 381 mm
Input colour depth
24 bit
TWAIN version
Version 1.9
Minimum scan size
7.4 x 10.5 cm
Scan input modes
Front control panel scan, copy or fax buttons, scanning via HP LaserJet Scan (Windows), HP Director (Macintosh) or TWAIN-compliant or WIA-compliant software
Scan speed (black, normal quality)
Up to 4 ppm
Scan speed (colour, normal quality)
Up to 2 ppm
Scanner features
Intuitive device front control panel with Scan-to button for direct walk-up scan to folder and e-mail capability (pre-configuration of walk-up capability required via software provided); Software; 30-page automatic document feeder
Via HP Jetdirect external print servers (print only): TCP/IP (IP Direct Mode, LPD, FTP, IPP, Telnet, SLP, Bonjour, BOOTP/ DHCP/ AutoIP, WINS, HTTP), IPX/SPX NDS, Bindery, DLC/LLC, AppleTalk, SNMP (v 1, 2c, 3)
Performance
Specification
Value
Internal memory
64 MB
Built-in processor
Yes
Processor family
NXP ColdFire V4e
Processor frequency
264 MHz
Minimum system requirements
Microsoft Windows 2000, XP Home, XP Professional): any Pentium II processor (Pentium III or greater recommended), 128 MB RAM, 250 MB hard disk space, SVGA 800 x 600 with 16-bit colour display, Internet Explorer 5.5 or higher (full install), CD-ROM drive, USB port
Design
Specification
Value
Market positioning
Home & office
Power
Specification
Value
Power consumption (PowerSave)
5 W
Power consumption (off)
1 W
Operational conditions
Specification
Value
Operating relative humidity (H-H)
10 - 80%
Operating temperature (T-T)
15 - 32.5 °C
Operating temperature (T-T)
59 - 90.5 °F
Storage relative humidity (H-H)
0 - 95%
Storage temperature (T-T)
-20 - 40 °C
Operating altitude (imperial)
10000 ft
Recommended operating temperature range (T-T)
15 - 32.5 °C
Sustainability
Specification
Value
Sustainability certificates
Blue Angel, ENERGY STAR
Weight & dimensions
Specification
Value
Weight
10 kg
Packaging data
Specification
Value
Package weight
12.2 kg
Packaging content
Specification
Value
Bundled software
HP Toolbox FX, HP LaserJet Scan, TWAIN 1.9 or WIA scan drivers, HP LaserJet Fax, HP Fax Setup Wizard, Readiris PRO text recognition software (not installed with other software, separate installation required), printer drivers (HP PCL 6, HP PCL 5e, HP Postscript Level 3 emulation), installer/uninstal
Logistics data
Specification
Value
Pallet gross weight
380 kg
Layers per pallet
6 pc(s)
Products per pallet
30 pc(s)
Other features
Specification
Value
Standard input trays
2
Networking features
Via optional HP Jetdirect External Print Servers (print only): HP Jetdirect en3700, ew2400
Dimensions (WxDxH)
429 x 443 x 459 mm
Browser supported
IE 5.5 or higher (Windows); Netscape 7.x (Windows); Netscape 7.0 (Solaris); Mozilla 1.4 and 1.7 or higher (Solaris)
Colour all-in-one functions
Scan
Compatible operating systems
Windows XP 64-bit, UNIX, Linux, OS/2 (print functionality available via Web) Microsoft Windows 2000, XP Home, XP Professional, Server 2003; Windows Vista Ready; Mac OS X v 10.3 or higher
Compatible products
Arrays: HP StorageWorks XP disk arrays (XP12000, XP1024, XP512, XP128, XP48); HP StorageWorks Enterprise Virtual Array (EVA) EVA3000/4000/5000/6000/8000; HP Modular Storage Array (MSA) MSA1000, MSA1500; HP EMA 12000, EMA16000; EMC DMX800, 1000, 2000; EMC Clariion CX 100, 300, 400, 600, 700; EMC Clar
Downloadable software
Installer, print drivers, HP Send Fax, HP Scan software, HP ToolboxFX for management and support, Readiris PRO text recognition software, HP Software Update
Functions
Black-and-white printing, black-and-white copying, black-and-white faxing, black-and-white and colour scanning
Media types supported
A4, A5, 148 x 105 to 216 x 381 mm Paper (bond, colour, glossy, heavy, letterhead, light, plain, preprinted, prepunched, recycled, rough), envelopes, transparencies, labels, cardstock
Minimum system requirements for Macintosh
Mac OS X v 10.3.x; G3, G4 or G5 processor, 32 MB RAM, 30 MB disk space, Hi-Speed USB (compatible with USB 2.0 specifications) port, CD-ROM drive
Modem type
V34, Super G3 fax (<33 Kbps) & 2x RJ-11
Network ready
No
Power requirements
Input voltage 220 to 240 VAC (+/- 10%), 50/60 Hz (+/- 2 Hz), 2.3 amp
Printer management
HP Toolbox FX, HP Web Jetadmin, HP Embedded Web Server (Mac only)
A4, A5, B5, C5, C6, DL (ISO), postcard, 76 x 127 to 216 x 356 mm
Package dimensions (WxDxH)
600 x 333 x 440 mm
Electromagnetic compatibility
CISPR 22: 1993 +A1+A2/EN 55022: 1994+A1+A2 - Class B; EN 61000-3-2: 1995/A14: 2000; EN 61000-3-3: 1995+A1; EN 55024: 1998+A1+A2; FCC Title 47 CFR, Part 15 Class B 2/ICES-003, Issue 3; GB9254-1998
I/O ports
1 Hi-Speed USB
Acoustic power emissions
6.3 B(A)
Acoustic power emissions (active, print, copy or scan)
65 dB
Acoustic power emissions (ready)
Inaudible
Acoustic pressure emissions bystander (active, print, copy or scan)
51 dB(A) 49 dB(A)
Acoustic pressure emissions bystander (ready)
Inaudible
Auto document feeder: supported media types and capacity
Up to 30 sheets
Auto fax reduction supported
Yes
Case or master carton quantity
20 pc(s)
Control panel
Intuitive control panel with 2-line, 16-character back lit display, alphanumeric buttons, menu and cancel controls, fax, copy and scan controls, speed-dial keys
Copier scaling (Auto Document Feeder)
25 to 400%
Copier smart software features
Up to 99 multiple copies, collation, reduce/enlarge from 25 to 400% (with page size presets), fit to page, 2 or 4 pages to 1 page, contrast (lighter/darker), resolution (copy quality)
Custom media sizes
Media input tray and priority slot: 76 x 127 to 216 x 356 mm; automatic document feeder (ADF): 148 x 105 to 216 x 381 mm
Driver updates
Latest drivers available from http://
Duplex binding
No
Duplex print options
Manual (driver support provided)
First page out (black&white, A4, ready)
8 s
First page out (black&white, letter, ready)
8 s
First page out (black&white, letter, sleep)
8 s
Junk barrier supported
Yes
Maximum scan area (ADF) (imperial)
215.9 x 355.6 mm (8.5 x 14")
Media size (tray 2)
A4, A5, B5, 147 x 211 to 216 x 356 mm
Media sizes supported (imperial)
Media input tray and priority slot: letter, legal, envelopes (No. 5 1/2 Baronial through No. 11), index cards, postcards; automatic document feeder (ADF): letter, legal
Media weight (tray 2)
60 to 105 g/m²
Media weights by paper path
Media input tray, priority slot, output bin: 60 to 163 g/m2; automatic document feeder (ADF): 60 to 105 g/m2
Memory technology
Memory Enhancement technology (MEt)
Memory upgrade
No
Minimum scan area (Auto Document Feeder)
73.7 x 104.1 mm (2.9 x 4.1")
Package dimensions (W x D x H)
600.2 x 333.2 x 440.2 mm (23.6 x 13.1 x 17.3")
Package weight (imperial)
12.2 kg (26.8 lbs)
Pallet dimensions (W x D x H)
1200 x 1000 x 2340 mm
Pallet dimensions (W x D x H) (imperial)
1219.2 x 1016 x 2339.3 mm (48 x 40 x 92.1")
Pallet weight (imperial)
379.2 kg (836 lbs)
Print margin bottom (A4)
4 mm
Print margin left (A4)
4 mm
Print margin right (A4)
4 mm
Print margin top (A4)
4 mm
Print quality (black, best quality)
1200 x 1200 DPI
Print quality (black, draft quality)
1200 DPI
Print quality (black, normal quality)
1200 DPI
Printer smart software features
Manual duplex and booklet printing, N-up printing, collation, watermarks, install printer driver only, Economode for toner savings, accepts a variety of paper sizes and types
Security management description
Via optional, supported HP Jetdirect external print server: SNMP v 3, SSL/TLS (HTTPS); wireless network security: WPA (Wi-Fi Protected Access), WEP encryption (40-/64- and 128-bit), 802.1x authentication (EAP-PEAP, LEAP, EAP-TTLS, EAP-TLS, EAP-MD5) with RADIUS servers; security-lock slot for securin
Service & support
HP Websites, HP Customer Support Centre, HP Care Pack
Integration with OpenView software via Smart Plug-In (SPI). Delivers integrated IT Services management in areas like provisioning, operations, reporting and charge back. Backup management. Single view of backup activities. Identify unprotected applications, servers and files. Root cause analysis of
