Epson WorkForce Pro WF-M5690DWF

Epson WorkForce Pro WF-M5690DWF

Model WF-M5690DWFPart no. C11CE37403EAN 8715946547763

126 specifications
  • Display10.9 cm (4.29")
  • Noise51 dB
  • Weight14.1 kg
  • Print technologyInkjet
  • CopyingMono copying
  • ScanningColour scanning
See all specifications

Overview

Display
10.9 cm (4.29")
Noise
51 dB
Weight
14.1 kg
Print technology
Inkjet
Copying
Mono copying
Scanning
Colour scanning
Brand
Epson
Model
WF-M5690DWF
Part numbers
C11CE37403, C11CE37401BY, C11CE37402
EAN / UPC
8715946547763, 5057103097517, 8715946543741, 4053162877986 +1 more
Also known as
Epson WorkForce Pro WF-M5690DWF

Specifications

126 specifications in 19 groups

Printing

Print technologyInkjet
PrintingMono printing
Duplex printingYes
Duplex printing modeAuto
Maximum resolution1200 x 2400 DPI
Print speed (black, normal quality, A4/US Letter)34 ppm
Print speed (ISO/IEC 24734) black20 ppm
Duplex print speed (black, normal quality, A4/US Letter)11 ppm
Duplex print speed (ISO/IEC 24734, A4) black11 ppm
Time to first page (black, normal)7 s
Secure printingYes

Copying

CopyingMono copying
Maximum copy resolution600 x 1200 DPI
Copy speed (black, normal quality, A4)19 cpm
Maximum number of copies99 copies
Copier resize25 - 400%
Copy speedUp to19 ipm Black, Up to19 ipm Colour; *Simplex ADF 600 x 600 dpi (ISO/ IEC 24735)

Scanning

ScanningColour scanning
Optical scanning resolution1200 x 2400 DPI
Maximum scan resolution2400 x 2400 DPI
Scanner typeFlatbed & ADF scanner
Scan technologyCIS
Scan toE-mail, Network folder, FTP, PC
Scan speed (black)6.3 inch/min
Scan speed (colour)4.5 inch/min
Image formats supportedJPEG, TIFF
Document formats supportedPDF
Scan speed (black, normal quality)300 dpi (with ADF); , 6.3 ipm with ADF scan 200 dpi (flatbed) 5 sec. with flatbed scan
Scan speed (colour, normal quality)300 dpi (with ADF); , 4.5 ipm with ADF scan 200 dpi (flatbed) 14 sec. with flatbed scan

Fax

FaxingColour faxing
Fax transmission speed3 sec/page
Modem speed33.6 Kbit/s
Fax memory550 pages
Fax memory6 MB
Auto-redialingYes
Speed diallingYes
Fax speed dialing (max numbers)200
Fax forwarding toE-mail, PC
Error Correction Mode (ECM)Yes

Features

Maximum duty cycle35000 pages per month
Printing coloursBlack
Page description languagesESC/P-R, PCL 5c, PCL 5e, PCL 6, PDF 1.7, PostScript 3
Country of originIndonesia

Input & output capacity

Total number of input trays2
Total input capacity250 sheets
Total output capacity150 sheets
Multi-Purpose trayYes
Multi-Purpose tray input capacity80 sheets
Paper input typePaper tray
Auto document feeder (ADF)Yes
Auto document feeder (ADF) input capacity35 sheets
Auto document feeder (ADF) output capacity35 sheets
Maximum input capacity580 sheets
Maximum output capacity150 sheets

Paper handling

Maximum ISO A-series paper sizeA4
Paper tray media typesEnvelopes
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5
Non-ISO print media sizesLetter, Legal
Envelopes sizes10, C6, C4
Photo paper sizes10x15,13x18,20x25
Paper tray media weight64 - 256 g/m²
Paper tray media weight (imperial)0.0635 - 0.254 kg (0.14 - 0.56 lbs)
Additional paper trays250-sheet paper tray

Ports & interfaces

Standard interfacesEthernet, USB 2.0, Wireless LAN
Direct printingYes
USB portYes

Network

Wi-FiYes
Ethernet LANYes
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10,100,1000 Mbit/s
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-Enterprise
Management protocolsSNMP, HTTP, DHCP, BOOTP, APIPA, DDNS, mDNS, SNTP, SLP, WSD, LLTD, Ping, IEEE 802.1X
Mobile printing technologiesApple AirPrint, Google Cloud Print
Network printing methodsLPR, FTP, IPP, LDP, Port 9100, WSD, Net BIOS over TCP/IP, TCP/IPv4, TCP/IPv6, IPSec
Security featuresLimit access function with Epson Web Config, Secure confidential printing with PIN code release, LDAP Address Book, IPsec, IEEE802.1x, SSL (Server authentication), Panel Admin Mode

Performance

Sound pressure level (printing)51 dB

Design

Market positioningHome & office
Built-in displayYes
DisplayLCD
Display diagonal10.9 cm (4.29")
TouchscreenYes
Control typeTouch
Colour displayYes

Power

Power consumption (ready)8.9 W
Power consumption (sleep)2.6 W
Power consumption (off)0.4 W
Energy Star Typical Electricity Consumption (TEC)0.596 kWh/week
AC input voltage220 V

System requirements

Windows operating systems supportedYes
Mac operating systems supportedYes
Server operating systems supportedWindows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64

Sustainability

Sustainability certificatesENERGY STAR

Weight & dimensions

Width461 mm
Depth422 mm
Height342 mm
Weight14.1 kg

Packaging data

Package width520 mm
Package depth615 mm
Package height550 mm
Package weight17.6 kg
Quantity per pack1 pc(s)

Logistics data

Pallet gross width80 cm
Pallet gross length120 cm
Pallet gross height73.5 cm
Products per pallet layer2 pc(s)
Products per pallet6 pc(s)
Pallet width (UK)100 cm
Pallet length (UK)120 cm
Pallet height (UK)73.5 cm
Products per pallet layer (UK)2 pc(s)
Products per pallet (UK)6 pc(s)

Technical details

Box contentsDriver and utilities, Ink Cartridge, Main unit, Power cable, Quick Setup Guide, Warranty Documents

Other features

Printing methodEpson PrecisionCore
All-in-one functionsScan, Copy, Fax, Print
Compatible operating systemsLinux, Mac OS 10.5.8 or later, Mac OS 10.6+, Mac OS 10.7.x, Mac OS 10.8.x, Microsoft Windows XP (Home Edition / Prof / Prof X64 / Vista), Windows 10, Windows 7, Windows 8.1, Windows Server 2003 (32/64bit), Windows Server 2008 (32/64bit), Windows Server 2008 R2, Windows Server 2012 (64bit)
DuplexYes
EmulationsPCL6, PCL5c, PCL5e, ESC/P-R, PDF 1.7, PostScript 3
InterfaceHi-Speed USB - compatible with USB 2.0 specification, Ethernet Interface (1000 Base-T/ 100-Base TX/ 10-Base-T), USB host, Wireless LAN IEEE 802.11b/g/n, Wi-Fi Direct, Ethernet 1000, Ethernet interface (100 Base-TX / 10 Base-T)
Noise level51 dB
Colour printing technologyDURABrite™ Ultra
Ink drop6.1 pl, With Variable-Sized Droplet Technology
Print head nozzles1,600 Nozzles Black
Print speed34 pages/min Monochrome (plain paper 75 g/m²)
Printer featuresDirect scan-to-print without PC, Direct print from USB
