Epson WorkForce 520 Inkjet A4

5760 x 1440 DPI 15 ppm Wi-Fi

Model 520Part no. C11CA78241EAN 010343877092

71 specifications

ConnectivityWired & Wireless
Weight7.39 kg
Print technologyInkjet
CopyingColour copying
ScanningColour scanning
FaxingMono faxing

See all specifications

Overview

Connectivity: Wired & Wireless
Weight: 7.39 kg
Print technology: Inkjet
Copying: Colour copying
Scanning: Colour scanning
Faxing: Mono faxing

Brand: Epson
Category: Multifunction Printer
Model: 520
Part number: C11CA78241
EAN / UPC: 010343877092
Also known as: Epson WorkForce 520 Inkjet A4 5760 x 1440 DPI 15 ppm Wi-Fi

Specifications

71 specifications in 17 groups

Printing

Specification	Value
Print technology	Inkjet
Printing	Colour printing
Duplex printing	Yes
Maximum resolution	5760 x 1440 DPI
Print speed (black, normal quality, A4/US Letter)	15 ppm
Print speed (colour, normal quality, A4/US Letter)	5.4 ppm

Copying

Specification	Value
Copying	Colour copying
Copy speed (black, normal quality, A4)	15 cpm
Copy speed (colour, normal quality, A4)	5.4 cpm
Maximum number of copies	99 copies
Copier resize	25 - 400%
PC free copying	Yes

Scanning

Specification	Value
Scanning	Colour scanning
Optical scanning resolution	1200 x 1200 DPI
Maximum scan resolution	9600 x 9600 DPI
Scanner type	Flatbed scanner
Scan technology	CIS
Scan to	E-mail, File, Image
Input colour depth	48 bit
Output colour depth	24 bit

Fax

Specification	Value
Faxing	Mono faxing
Fax transmission speed	3 sec/page
Modem speed	33.6 Kbit/s
Fax memory	180 pages
Fax speed dialing (max numbers)	60

Features

Specification	Value
Digital sender	No
Number of print cartridges	4
Printing colours	Black, Cyan, Magenta, Yellow
All-In-One-multitasking	Yes

Input & output capacity

Specification	Value
Maximum input capacity	100 sheets
Maximum output capacity	30 sheets

Paper handling

Specification	Value
Maximum ISO A-series paper size	A4
Maximum print size	210 x 297 mm
Paper tray media types	Photo paper, Plain paper
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5

Ports & interfaces

Specification	Value
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
Direct printing	Yes
USB port	Yes
USB 2.0 ports quantity	1

Network

Specification	Value
Wi-Fi	Yes
Ethernet LAN	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)

Performance

Specification	Value
Card reader integrated	No
Sound power level (standby)	39 dB
Mac compatibility	Yes

Design

Specification	Value
Market positioning	Home & office
Built-in display	Yes
Display	LCD
Display number of lines	2 lines

Power

Specification	Value
Power consumption (average operating)	15 W
Power consumption (PowerSave)	4 W
AC input frequency	50 - 60 Hz
AC input voltage	100 - 120 V

System requirements

Specification	Value
Windows operating systems supported	Yes
Mac operating systems supported	Yes

Operational conditions

Specification	Value
Operating relative humidity (H-H)	20 - 80%
Operating temperature (T-T)	10 - 35 °C
Operating temperature (T-T)	50 - 95 °F
Storage relative humidity (H-H)	5 - 85%
Storage temperature (T-T)	20 - 40 °C

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

Weight & dimensions

Specification	Value
Weight	7.39 kg

Other features

Specification	Value
Hardware scan resolution	1200 x 2400 DPI
Dimensions (WxDxH)	459 x 541 x 302 mm
All-in-one functions	Copy, Fax, Print, Scan
Colour all-in-one functions	Copy, Print, Scan
Colour scanning	Yes
Compatible operating systems	- Windows 7, Windows Vista, Windows XP, Windows XP x64 - Mac OS X, 10.4.11, 10.5.x and 10.6.x
Connectivity technology	Wired & Wireless
Safety	UL60950, CSA C22.2 No. 60950, EMI FCC Part 15 subpart B class B, CAN / CSA-CEI / IEC CISPR 22 class B
