Dell B1165nfw Laser A4

1200 x 1200 DPI 21 ppm Wi-Fi

Model B1165nfwPart no. 210-AAYSEAN 5397063223428

86 specifications

ProcessorARM
Memory128 MB
Weight7.6 kg
ColourBlack
Print technologyLaser
CopyingMono copying

See all specifications

Overview

Processor: ARM
Memory: 128 MB
Weight: 7.6 kg
Colour: Black
Print technology: Laser
Copying: Mono copying

Brand: Dell
Category: Multifunction Printer
Model: B1165nfw
Part numbers: 210-AAYS, LAB1165NFW
EAN / UPC: 5397063223428, 5397063538027
Also known as: DELL B1165nfw Laser A4 1200 x 1200 DPI 21 ppm Wi-Fi

Specifications

86 specifications in 18 groups

Printing

Specification	Value
Print technology	Laser
Printing	Mono printing
Duplex printing	No
Duplex printing mode	Manual
Maximum resolution	1200 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)	21 ppm
Time to first page (black, normal)	8.5 s

Copying

Specification	Value
Copying	Mono copying
Duplex copying	No
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	20 cpm
Maximum number of copies	99 copies
Copier resize	25 - 400%

Scanning

Specification	Value
Scanning	Colour scanning
Duplex scanning	No
Optical scanning resolution	1200 x 1200 DPI
Maximum scan resolution	4800 x 4800 DPI
Maximum scan area	208 x 356 mm
Scanner type	Flatbed & ADF scanner
Image formats supported	BMP, JPG, PNG, TIF
Document formats supported	PDF

Fax

Specification	Value
Faxing	Mono faxing
Duplex faxing	No
Modem speed	33.6 Kbit/s
Fax memory	7 MB
Fax forwarding	Yes

Features

Specification	Value
Maximum duty cycle	20000 pages per month
Recommended duty cycle	150 - 700 pages per month
Number of print cartridges	1
Printing colours	Black
Page description languages	SPL

Input & output capacity

Specification	Value
Total input capacity	150 sheets
Total output capacity	100 sheets
Paper input type	Cassette
Maximum input capacity	150 sheets
Maximum output capacity	100 sheets

Paper handling

Specification	Value
Maximum ISO A-series paper size	A4
Maximum print size	216 x 356 mm
Paper tray media types	Plain paper, Pre-printed, Recycled paper, Thin paper
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Non-ISO print media sizes	Executive, Folio, Legal, Oficio
JIS B-series sizes (B0...B9)	B5

Ports & interfaces

Specification	Value
Standard interfaces	USB 2.0
Direct printing	Yes
USB port	Yes

Network

Specification	Value
Wi-Fi	Yes
Ethernet LAN	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Mobile printing technologies	Apple AirPrint, Dell Mobile Print, Google Cloud Print

Performance

Specification	Value
Internal memory	128 MB
Maximum internal memory	128 MB
Card reader integrated	No
Processor family	ARM
Processor frequency	433 MHz
Sound pressure level (copying)	50 dB
Sound power level (standby)	26 dB

Design

Specification	Value
Product colour	Black
Market positioning	Business
Built-in display	Yes
Display	LCD
Display number of lines	2 lines
Display number of characters	16

Power

Specification	Value
Power consumption (PowerSave)	2.1 W
Power consumption (standby)	30 W
AC input frequency	50 - 60 Hz
AC input voltage	100 - 120 V

System requirements

Specification	Value
Windows operating systems supported	Windows 2000, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enter
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Linux operating systems supported	Yes
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2008 R2
Other operating systems supported	Android, Novell NetWare 5.x, Novell NetWare 6.x

Operational conditions

Specification	Value
Operating relative humidity (H-H)	20 - 80%
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	20 - 95%
Storage temperature (T-T)	-20 - 40 °C

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

Weight & dimensions

Specification	Value
Width	402 mm
Depth	293 mm
Height	296 mm
Weight	7.6 kg

Packaging data

Specification	Value
Package width	469 mm
Package depth	360 mm
Package height	365 mm
Package weight	10.1 kg

Technical details

Specification	Value
Compliance certificates	RoHS
