MSI PM8M-V, Micro-ATX motherboard
Model PM8M-V, Micro-ATX motherboardPart no. 7104-010REAN 4719072031022
26 specifications
- Processor manufacturerIntel
- Number of memory slots2
- USB 2.0 ports quantity4
- Motherboard form factormicro ATX
- Width245 mm
Overview
- Processor manufacturer
- Intel
- Number of memory slots
- 2
- USB 2.0 ports quantity
- 4
- Motherboard form factor
- micro ATX
- Width
- 245 mm
- Brand
- MSI
- Category
- Motherboard
- Model
- PM8M-V, Micro-ATX motherboard
- Part number
- 7104-010R
- EAN / UPC
- 4719072031022
- Also known as
- MSI PM8M-V, Micro-ATX motherboard VIA P4M800 Socket 478 micro ATX
Specifications
26 specifications in 8 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor socket | Socket 478 |
Memory
| Specification | Value |
|---|---|
| Number of memory slots | 2 |
| Maximum internal memory | 2 GB |
Internal I/O
| Specification | Value |
|---|---|
| USB 2.0 connectors | 2 |
| Number of SATA connectors | 2 |
| S/PDIF out connector | Yes |
| Front panel audio connector | Yes |
| CD/AUX audio in | Yes |
| ATX Power connector (24-pin) | Yes |
| CPU fan connector | Yes |
| Chassis intrusion connector | Yes |
| Number of COM connectors | 1 |
Rear panel I/O ports
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 1 |
| PS/2 ports quantity | 2 |
| Parallel ports quantity | 1 |
| Serial ports quantity | 1 |
Features
| Specification | Value |
|---|---|
| Motherboard form factor | micro ATX |
| Motherboard chipset | VIA P4M800 |
| Power source type | ATX |
Expansion slots
| Specification | Value |
|---|---|
| Expansion slots | 1 x AGP 8x/4X 3 x PCI 2.2 32-bit PCI |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 245 mm |
| Depth | 190 mm |
Other features
| Specification | Value |
|---|---|
| Audio output | Realtek ALC655 |
| Floppy disk drive connector | Yes |
