MSI PH67S-C43 (B3)

MSI PH67S-C43 (B3)

Model PH67S-C43 (B3)Part no. 7673-041REAN 4719072217389

54 specifications
  • Processor manufacturerIntel
  • Number of memory slots4
  • RAID levels0, 1, 5, 10
  • Parallel processing technology supportNot supported
  • USB 2.0 connectors2
  • USB 2.0 ports quantity10
See all specifications

Overview

Processor manufacturer
Intel
Number of memory slots
4
RAID levels
0, 1, 5, 10
Parallel processing technology support
Not supported
USB 2.0 connectors
2
USB 2.0 ports quantity
10
Brand
MSI
Category
Motherboard
Model
PH67S-C43 (B3)
Part numbers
7673-041R, PH67S-C43 (B3)
EAN / UPC
4719072217389, 816909083316
Also known as
MSI PH67S-C43 (B3) Intel® H67 LGA 1155 (Socket H2) ATX

Specifications

54 specifications in 11 groups

Processor

Processor manufacturerIntel
Processor socketLGA 1155 (Socket H2)
Compatible processor seriesIntel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7

Memory

Number of memory slots4
Memory channelsDual-channel
Memory voltage1.5 V
Supported memory clock speeds1066,1333 MHz
Maximum internal memory32 GB
Supported memory module capacities1GB, 2GB, 4GB, 8GB

Storage controllers

RAID levels0, 1, 5, 10

Graphics

Parallel processing technology supportNot supported
On-board graphics cardNo

Internal I/O

USB 2.0 connectors2
Number of SATA III connectors2
Number of SATA II connectors4
Number of Parallel ATA connectors0
S/PDIF out connectorYes
Front panel audio connectorYes
CD/AUX audio inYes
ATX Power connector (24-pin)Yes
Number of EATX power connectors1
CPU fan connectorYes
Number of chassis fan connectors4
Chassis intrusion connectorYes
TPM connectorYes

Rear panel I/O ports

USB 2.0 ports quantity10
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Ethernet LAN (RJ-45) ports1
eSATA ports quantity0
PS/2 ports quantity1
Firewire (IEEE 1394) ports0
VGA (D-Sub) ports quantity0
HDMI ports quantity0
DVI-D ports quantity0
Headphone outputs1
Microphone inYes
S/PDIF out portYes
Digital audio optical out1

Network

Ethernet interface typeGigabit Ethernet
LAN controllerRealtek RTL8111E

Features

Component forPC
Motherboard form factorATX
Motherboard chipsetIntel® H67
Audio chipRealtek ALC892
Audio output channels7.1 channels
Power source typeATX

Expansion slots

PCI Express x1 slots3
PCI Express x16 slots1
PCI Express slots version2.0
PCI slots3

Weight & dimensions

Width305 mm
Depth215 mm

Other features

Controller 2nd interface typeSATAII 3 Gb/s
Controller interface typeSATAIII 6 Gb/s
