MSI P4M890M-L motherboard LGA 775 (Socket T) micro ATX
Model P4M890M-L
23 specifications
- Processor manufacturerIntel
- Number of memory slots2
- LAN controllerVIA VT6103L
- Motherboard form factormicro ATX
Overview
- Processor manufacturer
- Intel
- Number of memory slots
- 2
- LAN controller
- VIA VT6103L
- Motherboard form factor
- micro ATX
- Brand
- MSI
- Category
- Motherboard
- Model
- P4M890M-L
- Part numbers
- P4M890M-L, 7255-020, 7255-020R
- Also known as
- MSI P4M890M-L motherboard LGA 775 (Socket T) micro ATX
Specifications
23 specifications in 7 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor socket | LGA 775 (Socket T) |
| Compatible processor series | Intel® Core™2 Duo |
| Processor system buses supported | 1066 MHz |
Memory
| Specification | Value |
|---|---|
| Number of memory slots | 2 |
| Maximum internal memory | 2 GB |
Internal I/O
| Specification | Value |
|---|---|
| USB 2.0 connectors | 2 |
| Number of SATA connectors | 2 |
| S/PDIF out connector | Yes |
| ATX Power connector (24-pin) | Yes |
| Power fan connector | Yes |
| CPU fan connector | Yes |
| Chassis intrusion connector | Yes |
| Number of IEEE1394 connectors | 1 |
Network
| Specification | Value |
|---|---|
| LAN controller | VIA VT6103L |
| Networking features | Ethernet/Fast Ethernet |
Features
| Specification | Value |
|---|---|
| Motherboard form factor | micro ATX |
| Audio output channels | 7.1 channels |
| Power source type | ATX |
Expansion slots
| Specification | Value |
|---|---|
| Expansion slots | - 1 PCI Express x 16 - 2 PCI 2.2 32-bit PCI |
Other features
| Specification | Value |
|---|---|
| Audio output | VIA VT1708 |
| Floppy disk drive connector | Yes |
| I/O ports | - 1 x Parallel - 1 x Serial port (COM 1) - 1 x PS/2 Keyboard - 1 x PS/2 Mouse - 1 x Audio I/O (6 in 1) - 4 x USB 2.0 - 1 x IEEE1394 (optional) - 1 x RJ45 LAN jack - 1 x VGA port |
