MSI K8NGM2-L motherboard Socket 939 micro ATX
Model K8NGM2-L
25 specifications
- Memory0.125 GB
- Processor manufacturerAMD
- RAID levels0, 1
- USB 2.0 connectors4
- USB 2.0 ports quantity3
- Networking featuresEthernet/Fast-Ethernet
Overview
- Memory
- 0.125 GB
- Processor manufacturer
- AMD
- RAID levels
- 0, 1
- USB 2.0 connectors
- 4
- USB 2.0 ports quantity
- 3
- Networking features
- Ethernet/Fast-Ethernet
- Brand
- MSI
- Category
- Motherboard
- Model
- K8NGM2-L
- Part number
- K8NGM2-L
- Also known as
- MSI K8NGM2-L motherboard Socket 939 micro ATX
Specifications
25 specifications in 10 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | AMD |
| Processor socket | Socket 939 |
Memory
| Specification | Value |
|---|---|
| Internal memory | 0.125 GB |
| Maximum internal memory | 4 GB |
Storage controllers
| Specification | Value |
|---|---|
| RAID levels | 0, 1 |
Internal I/O
| Specification | Value |
|---|---|
| USB 2.0 connectors | 4 |
| Number of SATA connectors | 2 |
| Number of Parallel ATA connectors | 2 |
| CD/AUX audio in | Yes |
| ATX Power connector (24-pin) | Yes |
Rear panel I/O ports
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 3 |
| Ethernet LAN (RJ-45) ports | 1 |
| PS/2 ports quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
| DVI-D ports quantity | 1 |
| Parallel ports quantity | 1 |
Network
| Specification | Value |
|---|---|
| Networking features | Ethernet/Fast-Ethernet |
Features
| Specification | Value |
|---|---|
| Motherboard form factor | micro ATX |
| Audio chip | Realtek ALC880 |
| Audio output channels | 7.1 channels |
| Power source type | ATX |
Expansion slots
| Specification | Value |
|---|---|
| Expansion slots | 1 x PCI Express x16 1 x PCI Express x1 2 x 32-bit PCI bus |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 244 mm |
| Depth | 244 mm |
Other features
| Specification | Value |
|---|---|
| Floppy disk drive connector | Yes |
