MSI K8NGM2 Socket 939 micro ATX
Model K8NGM2Part no. K8NGM2 FID
43 specifications
- Processor manufacturerAMD
- Number of memory slots4
- RAID levels0, 1
- USB 2.0 connectors2
- Motherboard form factormicro ATX
- Width24.4 mm
Overview
- Processor manufacturer
- AMD
- Number of memory slots
- 4
- RAID levels
- 0, 1
- USB 2.0 connectors
- 2
- Motherboard form factor
- micro ATX
- Width
- 24.4 mm
- Brand
- MSI
- Category
- Motherboard
- Model
- K8NGM2
- Part number
- K8NGM2 FID
- Also known as
- MSI K8NGM2 Socket 939 micro ATX
Specifications
43 specifications in 10 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | AMD |
| Processor socket | Socket 939 |
Memory
| Specification | Value |
|---|---|
| Number of memory slots | 4 |
| Maximum internal memory | 4 GB |
Storage controllers
| Specification | Value |
|---|---|
| RAID levels | 0, 1 |
Internal I/O
| Specification | Value |
|---|---|
| USB 2.0 connectors | 2 |
| Number of SATA connectors | 4 |
| Number of Parallel ATA connectors | 0 |
| S/PDIF out connector | Yes |
| Front panel audio connector | Yes |
| CD/AUX audio in | Yes |
| ATX Power connector (24-pin) | Yes |
| Number of EATX power connectors | 0 |
| CPU fan connector | Yes |
| Number of chassis fan connectors | 1 |
| Chassis intrusion connector | Yes |
| Number of COM connectors | No |
| Number of IEEE1394 connectors | 1 |
Rear panel I/O ports
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 1 |
| eSATA ports quantity | 0 |
| PS/2 ports quantity | 2 |
| Firewire (IEEE 1394) ports | 1 |
| VGA (D-Sub) ports quantity | 1 |
| Headphone outputs | 1 |
| Microphone in | Yes |
| Parallel ports quantity | 1 |
| Serial ports quantity | 0 |
| Modem (RJ-11) ports | 0 |
Network
| Specification | Value |
|---|---|
| Networking features | VITESSE VSC8201RX/ Realtek 8201CL, ACPI, PCI v2.2.,10Mb/s, 100Mb/s, 1000Mb/s |
Features
| Specification | Value |
|---|---|
| Motherboard form factor | micro ATX |
| Audio chip | Realtek ALC880 |
| Power source type | ATX |
| Compatible operating systems | Microsoft Windows XP, XP x64 |
Expansion slots
| Specification | Value |
|---|---|
| Expansion slots | -One PCI Express x 16 slots. -One PCI Express x 1 slots. -Two 32-bit Master PCI bus slots (support 3.3v/5v PCI bus interface). |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 24.4 mm |
| Depth | 24.4 mm |
Other features
| Specification | Value |
|---|---|
| Azalia Digital Header (ADH) connector | No |
| EZ plug connector | No |
| Floppy disk drive connector | Yes |
| GAME/MIDI connector | No |
| Special features | -TV-out connector -Clear CMOS button |
| I/O ports | 1 x DVI |
