MSI K8N Neo-FSR
Model K8N Neo-FSRPart no. 7030-100REAN 4719072034795
35 specifications
- Processor manufacturerAMD
- Number of memory slots2
- RAID levels0, 1, 0+1, JBOD
- USB 2.0 ports quantity4
- Networking featuresGigabit Ethernet
- Motherboard form factorATX
Overview
- Processor manufacturer
- AMD
- Number of memory slots
- 2
- RAID levels
- 0, 1, 0+1, JBOD
- USB 2.0 ports quantity
- 4
- Networking features
- Gigabit Ethernet
- Motherboard form factor
- ATX
- Brand
- MSI
- Category
- Motherboard
- Model
- K8N Neo-FSR
- Part number
- 7030-100R
- EAN / UPC
- 4719072034795
- Also known as
- MSI K8N Neo-FSR Socket 754 ATX
Specifications
35 specifications in 10 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | AMD |
| Processor socket | Socket 754 |
| Compatible processor series | AMD Sempron |
Memory
| Specification | Value |
|---|---|
| Number of memory slots | 2 |
| Maximum internal memory | 2 GB |
Storage controllers
| Specification | Value |
|---|---|
| RAID levels | 0, 1, 0+1, JBOD |
Internal I/O
| Specification | Value |
|---|---|
| USB 2.0 connectors | 2 |
| Number of SATA connectors | 2 |
| Number of Parallel ATA connectors | 2 |
| Front panel audio connector | Yes |
| CD/AUX audio in | Yes |
| ATX Power connector (24-pin) | Yes |
| CPU fan connector | Yes |
| Chassis intrusion connector | Yes |
| Number of COM connectors | 1 |
Rear panel I/O ports
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 1 |
| PS/2 ports quantity | 2 |
| Headphone outputs | 1 |
| Microphone in | Yes |
| Parallel ports quantity | 1 |
| Serial ports quantity | 1 |
Network
| Specification | Value |
|---|---|
| Networking features | Gigabit Ethernet |
Features
| Specification | Value |
|---|---|
| Motherboard form factor | ATX |
| Audio chip | RealTek ALC655 |
| Audio output channels | 5.1 channels |
| Power source type | ATX |
| Compatible operating systems | Windows 2000 |
Expansion slots
| Specification | Value |
|---|---|
| Expansion slots | 1xAGP, 5xPCI |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 305 mm |
| Depth | 220 mm |
Other features
| Specification | Value |
|---|---|
| Controller 2nd interface type | Ultra DMA133/100/66 |
| Controller interface type | SATA |
| Floppy disk drive connector | Yes |
| RAID controller type | SATA |
