GIGABYTE X299 AORUS Gaming

Model X299 AORUS GamingPart no. X299 AORUS GAMINGEAN 889523010952

68 specifications

Overview

Brand: GIGABYTE
Category: Motherboard
Model: X299 AORUS Gaming
Part number: X299 AORUS GAMING
EAN / UPC: 889523010952, 4719331801991
Also known as: GIGABYTE X299 AORUS Gaming Intel® X299 LGA 2066 (Socket R4) ATX

68 specifications in 13 groups

Specification	Value
Processor manufacturer	Intel
Processor socket	LGA 2066 (Socket R4)
Compatible processor series	Intel® Core™ i5, Intel® Core™ i7
Maximum number of SMP processors	1
Intel Core i3/i5/i7/i9 series	i5-7xxx, i7-7xxx

Specification	Value
Supported memory types	DDR4-SDRAM
Number of memory slots	4
Memory slots type	DIMM
Memory channels	Dual-channel
ECC сompatibility	Non-ECC
Supported memory clock speeds	2133,2400,2667 MHz
Maximum internal memory	64 GB
Unbuffered memory	Yes

Specification	Value
RAID levels	0, 1, 5, 10

Specification	Value
Parallel processing technology support	2-Way CrossFireX, 2-Way SLI, 3-Way SLI, Quad-GPU CrossFireX, Quad-GPU SLI

Specification	Value
USB 2.0 connectors	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors	2
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
Number of SATA III connectors	8
Number of SATA II connectors	0
Number of Parallel ATA connectors	0
S/PDIF out connector	Yes
Front panel audio connector	Yes
Front panel connector	Yes
ATX Power connector (24-pin)	Yes
Number of EATX power connectors	1
CPU fan connector	Yes
Number of chassis fan connectors	2
12V power connector	Yes
TPM connector	Yes
Thunderbolt headers	1

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
Ethernet LAN (RJ-45) ports	1
eSATA ports quantity	0
PS/2 ports quantity	1
Firewire (IEEE 1394) ports	0
VGA (D-Sub) ports quantity	0
HDMI ports quantity	0
DVI-D ports quantity	0

Specification	Value
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet

Specification	Value
Component for	PC
Motherboard form factor	ATX
Motherboard chipset family	Intel
Motherboard chipset	Intel® X299
Audio chip	Realtek ALC1220
Audio output channels	7.1 channels
PC health monitoring	Fan, Temperature, Voltage
Power source type	ATX
Windows operating systems supported	Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64

Specification	Value
BIOS type	UEFI AMI
BIOS memory size	128 Mbit
ACPI version	5.0
Clear CMOS jumper	Yes
Desktop Management Interface (DMI) version	2.7
Plug and Play	Yes
System Management BIOS (SMBIOS) version	2.7

Specification	Value
Intel Extreme Memory Profile (XMP)	Yes

Specification	Value
Width	305 mm
Depth	244 mm

Specification	Value
Bundled software	Norton Internet Security, cFosSpeed
