GIGABYTE GA-Z170X-UD5 TH

GIGABYTE GA-Z170X-UD5 TH

Model GA-Z170X-UD5 THEAN 889523002827

49 specifications
  • Processor manufacturerIntel
  • Supported memory typesDDR4-SDRAM
  • Supported storage drive interfacesSATA
  • Maximum graphics card memory512 MB
  • USB 2.0 connectors5
  • USB 2.0 ports quantity4
See all specifications

Overview

Processor manufacturer
Intel
Supported memory types
DDR4-SDRAM
Supported storage drive interfaces
SATA
Maximum graphics card memory
512 MB
USB 2.0 connectors
5
USB 2.0 ports quantity
4
Brand
GIGABYTE
Category
Motherboard
Model
GA-Z170X-UD5 TH
Part numbers
GA-Z170X-UD5 TH, GA-Z170X-UD5 TH-R1
EAN / UPC
889523002827, 4719331836283, 8809481920645
Also known as
GIGABYTE GA-Z170X-UD5 TH motherboard Intel® Z170 ATX

Specifications

49 specifications in 13 groups

Processor

Processor manufacturerIntel
Compatible processor seriesIntel® Celeron®, Intel® Pentium®

Memory

Supported memory typesDDR4-SDRAM
Memory slots typeDIMM
Supported memory clock speeds2133,2400,2666,2800,3000,3200,3300,3333,3400,3466,3600,3666,3733,3800 MHz

Storage controllers

Supported storage drive interfacesSATA
RAID levels0, 1, 5, 10

Graphics

Maximum graphics card memory512 MB
Graphics card familyAMD, NVIDIA
Number of displays supported3

Internal I/O

USB 2.0 connectors5
USB 3.2 Gen 1 (3.1 Gen 1) connectors8
USB 3.2 Gen 2 (3.1 Gen 2) connectors0
Number of SATA III connectors0
Number of SATA II connectors0
Number of SATA Express connectors3
Number of Parallel ATA connectors0
Serial port headers1
TPM connectorYes

Rear panel I/O ports

USB 2.0 ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity0
Ethernet LAN (RJ-45) ports1
eSATA ports quantity0
PS/2 ports quantity1
Firewire (IEEE 1394) ports0
VGA (D-Sub) ports quantity0
HDMI ports quantity1
DVI-D ports quantity0

Network

Ethernet LANYes
Ethernet interface typeGigabit Ethernet

Features

Component forPC
Motherboard form factorATX
Motherboard chipset familyIntel
Motherboard chipsetIntel® Z170
Audio output channels7.1 channels
Power source typeATX
Windows operating systems supportedWindows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x6

Expansion slots

PCI Express x16 slots1

BIOS

BIOS typeUEFI AMI
BIOS memory size256 Mbit
ACPI version5.0

Weight & dimensions

Width305 mm
Depth244 mm

Packaging content

Cables includedSATA
Drivers includedYes

Other features

Quick installation guideYes
