GA-SBCAP3450 (rev. 1.1)
Model GA-SBCAP3450 (rev. 1.1)Part no. GA-SBCAP3450EAN 4719331803872
51 specifications
- ProcessorN3450
- Processor manufacturerIntel
- Supported memory typesDDR3L-SDRAM
- Parallel processing technology supportNot supported
- USB 2.0 connectors4
- USB 2.0 ports quantity0
Overview
- Processor
- N3450
- Processor manufacturer
- Intel
- Supported memory types
- DDR3L-SDRAM
- Parallel processing technology support
- Not supported
- USB 2.0 connectors
- 4
- USB 2.0 ports quantity
- 0
- Brand
- GIGABYTE
- Category
- Motherboard
- Model
- GA-SBCAP3450 (rev. 1.1)
- Part number
- GA-SBCAP3450
- EAN / UPC
- 4719331803872
- Also known as
- GIGABYTE GA-SBCAP3450 (rev. 1.1)
Specifications
51 specifications in 13 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Compatible processor series | Intel® Celeron® |
| Processor model | N3450 |
Memory
| Specification | Value |
|---|---|
| Supported memory types | DDR3L-SDRAM |
| Number of memory slots | 1 |
| Memory slots type | SO-DIMM |
| Supported memory clock speeds | 1333,1600,1866 MHz |
Graphics
| Specification | Value |
|---|---|
| Parallel processing technology support | Not supported |
Internal I/O
| Specification | Value |
|---|---|
| USB 2.0 connectors | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors | 2 |
| Number of SATA III connectors | 2 |
| Number of SATA II connectors | 0 |
| Power fan connector | Yes |
| CPU fan connector | Yes |
| Number of chassis fan connectors | 2 |
| Chassis intrusion connector | Yes |
| Serial port headers | 4 |
Rear panel I/O ports
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 2 |
| eSATA ports quantity | 0 |
| PS/2 ports quantity | 0 |
| Firewire (IEEE 1394) ports | 0 |
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 1 |
| DVI-D ports quantity | 0 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Wi-Fi | No |
Features
| Specification | Value |
|---|---|
| Component for | PC |
| Motherboard chipset family | Intel |
| Audio chip | Realtek ALC255 |
| Audio output channels | 2.0 channels |
| PC health monitoring | Fan, Temperature, Voltage |
| Windows operating systems supported | Windows 10 x64 |
Expansion slots
| Specification | Value |
|---|---|
| Mini PCI Express slot (half-length) | 1 |
BIOS
| Specification | Value |
|---|---|
| BIOS type | UEFI AMI |
| BIOS memory size | 128 Mbit |
| Clear CMOS jumper | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 146 mm |
| Depth | 102 mm |
Packaging content
| Specification | Value |
|---|---|
| Bundled software | Norton® Internet Security (OEM version) |
Other features
| Specification | Value |
|---|---|
| mSATA ports quantity | 1 |
| BIOS switch button | Yes |
| DualBIOS | Yes |
| Processor family | Intel® Celeron® |
| Processor frequency | 1.1 GHz |
